Astm A213 Tabung Stainless Seamless / Pipa Baja Stainless Seamless 38.1mm - 101.6mm
Product Details
| Bahan: | TP304H, TP310H, TP316H, TP321H, TP347H, ALLOY 800, ALLOY 800H, ALLOY 800HT, ALLOY 825 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 38.1mm hingga 101.6mm | ketebalan dinding: | 0,5mm hingga 8mm |
| Menyoroti |
ss pipa seamless,tabung ketel stainless steel |
||
Product Description
Tabung Boiler Stainless Steel Efisiensi Tinggi, ASME SA213 TP304H, TP310H, TP316H, TP321H, TP347H, 38.1mm hingga 101.6mm, 100% ET & UT & HT
Hua Dong Energy Technology has more than 30 years supply boiler tube , heat exchanger tube , Condenser Tube , Cooling Tube, Material cover : Stainless Steel , Carbon Steel ,Nickel base alloy Steel (Hastelloy, Monel , Inconel , Incoloy), Copper Alloy , ND Steel , our boiler tube and heat exchanger tube already export more than 30 countries, and give our best service for more than 1000 clients. Teknologi Energi Hua Dong memiliki lebih dari 30 tahun memasok tabung ketel, tabung penukar panas, Tabung Kondensor, Tabung Pendingin, Bahan penutup: Stainless Steel, Baja Karbon, Baja paduan dasar nikel (Hastelloy, Monel, Inconel, Incoloy), Paduan Tembaga, ND Steel, tabung boiler dan tabung penukar panas kami sudah mengekspor lebih dari 30 negara, dan memberikan layanan terbaik kami untuk lebih dari 1000 klien. Hua Dong Brand already stands: High Quality , High Efficiency , and Excellent quality ! Hua Dong Brand sudah berdiri: Kualitas Tinggi, Efisiensi Tinggi, dan kualitas Luar Biasa!
Specifikasi:
ASME SA213 / A213 -19: Spesifikasi Standar untuk Seamless Feritik dan Austenitik Paduan-
Boiler Baja, Superheater, dan Tabung Penukar Panas Stainless Steel.
ASTM A213 / A213M -17 :Spesifikasi Standar untuk Boiler Baja Mulus Feritik dan Austenitik, Superheater, dan Tabung Penukar Panas
ASTM A249 / A249M -18a :Spesifikasi Standar untuk Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, dan Tabung Kondensor
ASTM A268 / A268M - 10 (2016) :Spesifikasi Standar untuk Tubing Stainless Steel Seamless dan Feritik dan Martensit untuk Layanan Umum
ASTM A269 / A269M - 15a (2019) :Spesifikasi Standar untuk Tabung Stainless Steel Austenitic Mulus dan Dilas untuk Layanan Umum
Standar lainnya:DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463, ...
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||
| Diameter luar | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Ketebalan dinding mm | |||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inci | Berat kg / m | |||||||
| 6.35 | 1/4 | 0,081 | 0,109 | 0,133 | 0,174 | 0,212 | |||
| 9.53 | 3/8 | 0,126 | 0,157 | 0,193 | 0,257 | 0,356 | 0,429 | ||
| 12.7 | 1/2 | 0,214 | 0,263 | 0,356 | 0,457 | 0,612 | 0,754 | ||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0,995 | ||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0,667 | 0,832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
| Karbon | Chromiun | Suhu rendah | Besi tahan karat | Dupleks | Tembaga & perunggu | Titanium | Ni-Alloy | ||
| SA178-A | SA213-T1 | SA333-Gr.1 | SA213 | TP316L | A789-S31803 | SB111-C70600 | SB338-GR.1 | SB163 | No.200 |
| SA178-C | SA213-T11 | SA333-Gr.3 | SA249 | TP316H | A789-S32205 | SB111-C71500 | SB338-GR.2 | SB167 | NO2201 |
| SA179 | SA213-T12 | SA333-Gr.6 | SA268 | TP316Ti | A789-S32750 | SB111-C71640 | SB338-GR.5 | SB444 | NO8020 |
| SA192 | SA213-T22 | SA333-Gr.7 | SA269 | TP316LN | A789-S32760 | SB111-C68700 | SB338-GR.7 | SB514 | NO6022 |
| SA209-T1 | SA213-T5 | SA333-Gr.8 | SA376 | TP321 | A789-S32707 | SB111-C44300 | SB338-GR.9 | SB619 | N10276 |
| SA209-T1a | SA213-T9 | SA334-Gr.1 | TP304 | TP321H | A789-S32304 | SB338-GR.12 | SB622 | NO4400 | |
| SA209-T1b | SA213-T91 | SA334-Gr.3 | TP304L | TP347 | A789-S31500 | SB626 | NO6600 | ||
| SA210-A1 | SA334-Gr.6 | TP304H | TP347H | S31254 | SB674 | NO6601 | |||
| SA210-C | SA334-Gr.7 | TP304N | TP405 | 254MA | SB677 | NO6625 | |||
| SA214 | SA334-Gr.8 | TP310H | TP409 | 17-4PH | SB704 | NO690 | |||
| SA513 MT 1010 | TP310S | TP410 | 17-7PH | SB705 | NO8800 | ||||
| SA513 MT 1015 | TP309S | TP430 | 15-7PH | N1001 | NO8810 | ||||
| SA513 MT 1020 | TP317 | TP439 | N10665 | NO8811 | |||||
| TP317L | TP444 | N10675 | NO8825 | ||||||
| TP348 | TP446 | TP904L | |||||||
| TP347HFG | |||||||||
Kelas bahan:
| Standar Amerika |
Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15М3Т, 12 hingga 088 hari, 22, 22, 22, 19, 19, 19, 19, 08, 08, 08, 08, 08, 10 |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding | Panjangnya |
| Tabung Penukar Panas | 6.00mm hingga 101.6mm | 0,5mm hingga 8mm | Max. Maks. 32m/pc 32 m / pc |
Finishing Akhir
Solusi Annealed & Acar atau Bright Annealed atau Dipoles.
Jenis tabung:
U-bend & Lurus & Bergelombang & Digulung
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tensile | Tarik | Hardness | Kekerasan | Flattening | Meratakan | Flare | Flare | Flange Penghubung jalur pipa |
| Reverse-bend and Re. Reverse-bend dan Re. flat tests tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Eddy Current Testing | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatik 100% dilakukan sesuai dengan ASTM-A 450 norma untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Tekanan Udara Di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui inspeksi visual menyeluruh oleh staf terlatih untuk mendeteksi cacat permukaan & ketidaksempurnaan lainnya. |
Pengujian Tambahan: Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. Terlepas dari tes yang disebutkan di atas, kami juga melakukan pengujian tambahan produk yang diproduksi. The tests conducted under this include: Tes yang dilakukan di bawah ini meliputi:
|
|
|
