Bagian Boiler Tabung Baja Karbon Tekanan Tinggi sebagai Reheater Superheater di Pembangkit Listrik
Product Details
| Nama Produk: | Tabung Boiler | standar: | GB5310 Cina |
|---|---|---|---|
| Aplikasi: | pipa pemanas, wadah, dan alat pemanas batu bara superheater dan reheater | Kelas pipa baja utama: | 20G 、 25MnG 、 15MoG 、 15CrMoG 、 12Cr2MoG 、 12Cr1MoVG |
| Menyoroti |
cs seamless pipe,cs galvanized pipefunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en' |
||
Product Description
Tabung Baja Seamless untuk Boiler Tekanan Tinggi di Pembangkit Listrik
Pengenalan Perusahaan
Zhangjiagang Hua Dong Energy Technology Co., Ltd. is a high-tech enterprise specialized in producing all kinds of stainless, carbon and alloy steel tubes and pipes, steel plates which are widely used in the field of boiler&heat exchanger, energy, petrochemical, mining, food, paper, gas and fluid industry. Zhangjiagang Hua Dong Energy Technology Co, Ltd adalah perusahaan teknologi tinggi yang mengkhususkan diri dalam memproduksi semua jenis stainless, karbon dan tabung baja paduan dan pipa, pelat baja yang banyak digunakan di bidang boiler & penukar panas, energi, petrokimia, pertambangan , industri makanan, kertas, gas dan fluida. And we have passed the attestations including ASME, TUV, Grade A, ISO9001, EN12952, EN10216, SO3834. Dan kami telah melewati pengesahan termasuk ASME, TUV, Grade A, ISO9001, EN12952, EN10216, SO3834.
Rincian Produk
Standar: Bahasa Cina GB5310
Aplikasi: Digunakan untuk memanaskan saluran pipa, wadah, alat penghemat panas batu bara, dan pemanas ulang dari boiler bertekanan tinggi (P> 9.8Mpa, 450 ℃ <T <650 ℃)
Kelas pipa baja utama: 20G, 25MnG, 15MoG, 15CrMoG, 12Cr2MoG, 12Cr1MoVG (Kelas lainnya juga bisa dinegosiasikan.)
Komposisi Kimia & Propertise Mekanik:
| Standar | Kelas | Komposisi kimia(%) | ||||||
| C | M N | Si | V | Cr | Mo | PS | ||
| GB5310 | 20G | 0.17 ~ 0.24 | 035 ~ 0,65 | 0.17 ~ 0.37 | / | / | / | ≤ 0,030 |
| 25MnG | 0,22 ~ 0,30 | 0,70 ~ 1,00 | 0.17 ~ 0.37 | / | / | / | ≤ 0,030 | |
| 15MoG | 0,12 ~ 0,20 | 0,40 ~ 0,80 | 0.17 ~ 0.37 | / | / | 0,25 ~ 0,35 | ≤ 0,030 | |
| 15CrMoG | 0,12 ~ 0,18 | 0,40 ~ 0,70 | 0.17 ~ 0.37 | / | 0,80 ~ 1,10 | 0,40 ~ 0,55 | ≤ 0,030 | |
| 12Cr2MoG | 0,08 ~ 0,15 | 0,40 ~ 0,70 | ≤ 0,50 | / | 2.00 ~ 2.50 | 0,90 ~ 1,20 | ≤ 0,030 | |
| 12Cr1MoVG | 0,08 ~ 0,15 | 0,40 ~ 0,70 | 0.17 ~ 0.37 | 0,15 ~ 0,30 | 0,90 ~ 1,20 | 0,25 ~ 0,35 | ≤ 0,030 | |
| Propertise Mekanis | Kekuatan Tarik (Mpa) | Kekuatan luluh (mpa) | Pemanjangan(%) | |||||
| 20G | 410 ~ 550 | ≥ 245 | ≥ 24 | |||||
| 25MnG | ≥ 415 | ≥ 240 | ≥ 22 | |||||
| 15MoG | 450 ~ 600 | ≥ 270 | ≥ 22 | |||||
| 15CrMoG | 440 ~ 640 | ≥ 235 | ≥ 21 | |||||
| 12Cr2MoG | 450 ~ 600 | ≥ 280 | ≥ 20 | |||||
| 12Cr1MoVG | 470 ~ 640 | ≥ 255 | ≥ 21 | |||||
Product Highlights
