Tp316l Bahan Stainless Steel Seamless Tube Pickling Annealing Surface
Product Details
| Bahan: | TP316L | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 6.00mm hingga 101.6mm | ketebalan dinding: | 0,5mm hingga 8mm |
| Menyoroti |
tabung baja dilas,ss pipa seamless |
||
Product Description
Tabung Stainless Steel Mulus, ASME SA213 TP316L 19.05 * 2 * 6087 MM, KETEBALAN DINDING MIN
Hua Dong Energy Technology memiliki lebih dari 35 tahun pengalaman untuk tabung penukar panas / tabung boiler / tabung pendingin,
Produk keuntungan: (Boiler & Penukar Panas & Tabung Kondensor):
ASTM A213 (TP304, TP304L, TP304H, TP310S, TP316L, TP316Ti, TP317 / L, TP321 / H, TP347 / H)
ASTM A249 (TP304, TP304L, TP316L, TP321 / H)
ASTM A789 (S31803 (2205), 32750 (2507), S31254 (254MO), S32304)
ASTM B163 / B167 / B444 untuk Tube Baja Nikel
ASTM B677 UNS NO8904 (904L)
ASTM B111 (70400, C70600, C71500, C71640, C68700, C44300)
Standar Lainnya: EN10216-5, DIN 17456, DIN17458, GOST9941-81, JIS-G3459, JIS-G3463
Specifikasi:
ASTM A213 / SA213: Spesifikasi Standar untuk Boiler Baja Seamless Feritik dan Austenitik, Superheater dan Tabung Penukar Panas Stainless Steel.
ASTM A249 / A249M:Spesifikasi Standar untuk Welded Austenitic Steel Boiler, Superheater
Heat-Exchanger, dan Tabung Kondensor.
Standar lainnya:DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463 ...
Kelas bahan:
| Standar Amerika | Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15М3Т, 12 hingga 088 hari, 22, 22, 22, 19, 19, 19, 19, 08, 08, 08, 08, 08, 10 |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Tabung Penukar Panas | 6.00mm hingga 101.6mm | 0,5mm hingga 8mm |
Finishing Akhir
Solusi Anil & Acar/ Bright Annealed.
Jenis tabung:
Bengkok & Lurus.
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tensile | Tarik | Hardness | Kekerasan | Flattening | Meratakan | Flare | Flare | Flange Penghubung jalur pipa |
| Reverse-bend and Re. Reverse-bend dan Re. flat tests tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Eddy Current Testing | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatik 100% dilakukan sesuai dengan ASTM-A 450 norma untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Tekanan Udara Di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui inspeksi visual menyeluruh oleh staf terlatih untuk mendeteksi cacat permukaan & ketidaksempurnaan lainnya. |
Pengujian Tambahan: Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. Terlepas dari tes yang disebutkan di atas, kami juga melakukan pengujian tambahan produk yang diproduksi. The tests conducted under this include: Tes yang dilakukan di bawah ini meliputi:
|
|
|
