Tabung Boam Seamless DIN17175 ST35.8 38 X 3.2 X 2000 MM Dengan Permukaan Lapisan Hitam Bevelled End
Product Details
| Nama Produk: | Tabung Boiler Seamless Baja Karbon | Aplikasi: | Untuk ketel bertekanan tinggi dan menengah, dan tujuan tekanan |
|---|---|---|---|
| Standar: | DIN17175 | Bahan: | ST35.8 |
| Menyoroti |
DIN17175 Seamless Boiler Tube,ST35.8 heat exchanger tube,DIN17175 ST35.8 Boiler Tube |
||
Product Description
Tabung Boiler Seamless Baja Karbon DIN17175 ST35.8 38 x 3.2 x 2000MM dengan permukaan lapisan hitam ujung miring
Tabung Boiler Seamless Baja Karbon DIN17175 ST35.8 38 x 3.2 x 2000MM dengan permukaan lapisan hitam ujung miring.
ASTM A192 ASME SA192 Tabung Boiler Seamless Baja Karbon, DIN17175 ST35.8, ST45.8.
Aplikasi: Untuk boiler bertekanan tinggi, sedang, dan bertekanan rendah
Standar Produksi, Kelas, Baja No:
ASTM A178 Kelas A, C, D
ASTM A179 Kelas A, C, D
ASTM A192
ASTM A210 GradeA-1, C
BS3059-Ⅰ 320 CFS
BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2
EN10216-1 P195TR1/TR2, P235TR1/TR2, P265TR1/TR2
EN10216-2 P195GH, P235GH, P265GH, TC1, TC2
DIN17175 ST35.8, ST45.8
DIN1629 ST37.0, ST44.0, ST50.0
JIS G3454 STPG370, STPG410
JIS G3461 STB340, STB410, STB440
GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB
GB9948 10, 20, 12CrMo, 15CMo
GB3087 10, 20
Kondisi pengiriman:Anil, Normalisasi, Normalisasi, dan Tempered
Inspeksi dan Uji:
Inspeksi Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Hasil,
Perpanjangan, Pembakaran, Perataan, Tekuk, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Tidak Merusak, Uji Hidrostatik.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||||
| Diameter luar | BWG | ||||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||||
| Tebal Dinding mm Wall | |||||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||||
| mm | inci | Berat kg/m | |||||||||
| 6.35 | 1/4 | 0,081 | 0.109 | 0,133 | 0,174 | 0.212 | |||||
| 9.53 | 3/8 | 0,126 | 0,157 | 0.193 | 0.257 | 0,356 | 0,429 | ||||
| 12,7 | 1/2 | 0.214 | 0,26326 | 0,356 | 0,457 | 0.612 | 0,754 | ||||
| 15.88 | 5/8 | 0,2712 | 0,334 | 0,455 | 0,588 | 0,796 | 0.995 | ||||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |||
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |||
| 38.1 | 1 1/2 | 0,667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |||
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||||
| 88.9 | 3 1/2 | 2,729 | 3.609 | 4.584 | 5.974 | 7.27 | |||||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||||
| Bentuk Tabung: Lurus & U-tikungan & Bersirip & Melingkar | |||||||||||
| Tabung Baja Tahan Karat: A/SA213, A/SA249, A/SA268, A/SA269, A/SA789, EN10216-5, A/SA688, B/SB163, JIS-G3463, GOST9941-81. | |||||||||||
| Tabung Baja Karbon & Paduan: A/SA178, A/SA179, A/SA192, A/SA209, A/SA210, A/SA213, A.SA214 |
|||||||||||
Sertifikasi
