Superheater Boiler Steel Tube / Tabung Penukar Panas ASTM A213 ASME SA213 T1 T11 T12
Product Details
| nama porduct: | Tabung baja paduan mulus | Aplikasi: | Penukar Panas Boiler, Superheater |
|---|---|---|---|
| standar: | ASTM A213 / ASME SA213 | Kelas: | T1, T11, T12 |
| Menyoroti |
tabung paduan nikel,tabung baja canai panas |
||
Product Description
Baja paduan tabung mulus untuk Boiler, Superheater, Aplikasi penukar panas ASTM A213 / ASME SA213 T1 T11 T12
ASTM A213 / ASME SA213 T1 T11 T12 Baja Paduan tabung Mulus untuk Boiler, Superheater, aplikasi penukar panas
HDT memasok pipa dan tabung mulus Cr-Mo Alloy dalam jumlah besar, dan mengekspor lebih dari 35 negara.Tabung mulus paduan kami menjadi lebar digunakan dalam boiler dan pemanas.
HDT mengontrol seluruh proses manufaktur dari bahan baku hingga produk jadi, titik inspeksi dilokalkan dalam proses manufaktur untuk memastikan semua produk memenuhi semua persyaratan.Dalam sistem kontrol kualitas tersebut, kesalahan terdeteksi pada tahap sedini mungkin dari proses produksi untuk menghilangkan risiko penolakan pada inspeksi akhir.Kami telah melakukan upaya terus menerus untuk mengurangi masalah di seluruh sistem jaminan kualitas total termasuk kontrol penelusuran, YUHONG tidak hanya memeriksa sendiri, juga melalui TPI seperti BV, SGS, DNV, ABS, MOODY, IBR, sehingga saat ini kualitas produk kami jelas diakui oleh klien kami.
| Karbon | Chromiun | Suhu rendah | Besi tahan karat | Rangkap | Tembaga & perunggu | Titanium | Ni-Alloy | ||
| SA178-A | SA213-T1 | SA333-Gr.1 | SA213 | TP316L | A789-S31803 | SB111-C70600 | SB338-GR.1 | SB163 | No.200 |
| SA178-C | SA213-T11 | SA333-Gr.3 | SA249 | TP316H | A789-S32205 | SB111-C71500 | SB338-GR.2 | SB167 | NO2201 |
| SA179 | SA213-T12 | SA333-Gr.6 | SA268 | TP316Ti | A789-S32750 | SB111-C71640 | SB338-GR.5 | SB444 | NO8020 |
| SA192 | SA213-T22 | SA333-Gr.7 | SA269 | TP316LN | A789-S32760 | SB111-C68700 | SB338-GR.7 | SB514 | NO6022 |
| SA209-T1 | SA213-T5 | SA333-Gr.8 | SA376 | TP321 | A789-S32707 | SB111-C44300 | SB338-GR.9 | SB619 | N10276 |
| SA209-T1a | SA213-T9 | SA334-Gr.1 | TP304 | TP321H | A789-S32304 | SB338-GR.12 | SB622 | NO4400 | |
| SA209-T1b | SA213-T91 | SA334-Gr.3 | TP304L | TP347 | A789-S31500 | SB626 | NO6600 | ||
| SA210-A1 | SA334-Gr.6 | TP304H | TP347H | S31254 | SB674 | NO6601 | |||
| SA210-C | SA334-Gr.7 | TP304N | TP405 | 254MA | SB677 | NO6625 | |||
| SA214 | SA334-Gr.8 | TP310H | TP409 | 17-4PH | SB704 | NO690 | |||
| SA513 MT 1010 | TP310S | TP410 | 17-7PH | SB705 | NO8800 | ||||
| SA513 MT 1015 | TP309S | TP430 | 15-7PH | N1001 | NO8810 | ||||
| SA513 MT 1020 | TP317 | TP439 | N10665 | NO8811 | |||||
| TP317L | TP444 | N10675 | NO8825 | ||||||
| TP348 | TP446 | TP904L | |||||||
| TP347HFG | |||||||||
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||
| Diameter luar | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Ketebalan dinding mm | |||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inci | Berat kg / m | |||||||
| 6.35 | 1/4 | 0,081 | 0,109 | 0,133 | 0,174 | 0,212 | |||
| 9.53 | 3/8 | 0,126 | 0,157 | 0,193 | 0,257 | 0,356 | 0,429 | ||
| 12.7 | 1/2 | 0,214 | 0,263 | 0,356 | 0,457 | 0,612 | 0,754 | ||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0,995 | ||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0,667 | 0,832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
ASTM A213 / ASME SA213 T2, T11, T12, T22, T91, T92 Komposisi Kimia dan Sifat Mekanik
| Kelas | Komposisi kimia% | ||||||||
| C | Si | M N | P, S Max | Cr | Mo | Ni Max | V | Al Max | |
| T2 | 0,10 ~ 0,20 | 0,10 ~ 0,30 | 0,30 ~ 0,61 | 0,025 | 0,50 ~ 0,81 | 0.44 ~ 0.65 | - | - | - |
| T11 | 0,05 ~ 0,15 | 0,50 ~ 1,00 | 0,30 ~ 0,60 | 0,025 | 1,00 ~ 1,50 | 0.44 ~ 0.65 | - | - | - |
| T12 | 0,05 ~ 0,15 | Max 0,5 | 0,30 ~ 0,61 | 0,025 | 0,80 ~ 1,25 | 0.44 ~ 0.65 | - | - | - |
| T22 | 0,05 ~ 0,15 | Max 0,5 | 0,30 ~ 0,60 | 0,025 | 1.90 ~ 2.60 | 0.87 ~ 1.13 | - | - | - |
| T91 | 0,07 ~ 0,14 | 0,20 ~ 0,50 | 0,30 ~ 0,60 | 0,02 | 8.0 ~ 9.5 | 0.85 ~ 1.05 | 0,4 | 0,18 ~ 0,25 | 0,015 |
| T92 | 0,07 ~ 0,13 | Max 0,5 | 0,30 ~ 0,60 | 0,02 | 8.5 ~ 9.5 | 0,30 ~ 0,60 | 0,4 | 0,15 ~ 0,25 | 0,015 |
| Kelas | Komposisi kimia% | Peralatan mekanis | |||||||
| W | B | Nb | N | T. S | Y. P | Pemanjangan | Kekerasan | ||
| T2 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T11 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T12 | - | - | - | - | ≥ 415MPa | ≥ 220MPa | ≥ 30% | 163HBW (85HRB) | |
| T22 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T91 | - | - | 0,06 ~ 0,10 | 0,03 ~ 0,07 | ≥ 585MPa | ≥ 415MPa | ≥ 20% | 250HBW (25HRB) | |
| T92 | 1.50 ~ 2.00 | 0,001 ~ 0,006 | 0,04 ~ 0,09 | 0,03 ~ 0,07 | ≥ 620MPa | ≥ 440MPa | ≥ 20% | 250HBW (25HRB) | |
ASTM A213 / ASME SA213 T2, T11, T12, T22, T91, T92 Toleransi
| Diameter luar | Toleransi OD | Toleransi WT | Toleransi Ovalitas | Toleransi Panjang Potong |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15% | - | + 3, 18 mm, - 0 mm |
| 12, 7 mm <OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10% | maks, 1, 65 mm | + 3, 18 mm, - 0 mm |
| 38, 1 mm <OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10% | maks, 2, 41 mm | + 4, 76 mm, - 0 mm |
- SA213 T11 Alloy Steel Tube digunakan dalam Industri Petrokimia
- SA213 T11 Alloy Steel Tube digunakan dalam Industri Kimia
- SA213 T11 Alloy Steel Tube digunakan dalam Industri Pembangkit Listrik Tenaga Nuklir
- SA213 T11 Alloy Steel Tube digunakan dalam Industri Minyak dan Gas
- SA213 T11 Alloy Steel Tube digunakan dalam Penelitian & Pengembangan
- SA213 T11 Alloy Steel Tube digunakan dalam Proyek Mega & Industri Pertahanan & Pengembangan
- SA213 T11 Alloy Steel Tube digunakan dalam Pulp & Paper Indusry
