Pipa Las Stainless Steel ASTM A270 TP304 TP304L TP316L SUS304 SUS304L SUS316L 1.4301 1.4307 1.4404 6M
Product Details
| Bahan: | TP304, TP304L, TP316L,, SUS304, SUS304L, SUS316L, 1.4301.1.4307.1.4404 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 6.00mm hingga 101.6mm | ketebalan dinding: | 1mm hingga 35mm |
| Menyoroti |
pipa dilas ss,tabung dilas ss |
||
Product Description
Pipa Las Stainless Steel ASTM A270 TP304 TP304L TP316L SUS304 SUS304L SUS316L 1.4301 1.4307 1.4404 6M
Teknologi Energi Hua Dong memiliki pengalaman lebih dari 35 tahun untuk tabung penukar panas / tabung boiler / tabung pendingin,
| Produk: | Pipa Stainless Steel Sanitasi |
| Proses Manufaktur: | Ditarik dingin, Acar, Anil |
| Standar: | ASTM A270 |
| Kelas Bahan: | TP316 / 316L / 316Ti ... |
| Diameter luar. | Φ 6,00 mm - Φ 1016 mm;1 "NB sampai 12" NB |
| Ketebalan: | 1mm - 35mm;SCH5 / 10/40/80/120 |
Deskripsi:
Standar Amerika:
ASTM A 270 Spesifikasi untuk Tabung Sanitasi Austenitik dan Feritik / Austenitik Stainless Steel Seamless dan Welded
Detail ukuran:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa stainless steel sanitasi | 6,00 mm hingga 1016 mm | 1 mm sampai 35 mm |
Toleransi Dimensi:
semua dimensi dalam inci (mm)
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12,7) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 1 - 1/2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,008 "(0,20) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 2 "(50,8) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,008 "(0,20) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 2 - 1/2 "(63,5) | 0,065 "(1,65) | + / - 0,010 "(0,25) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 3 "(76,2) | 0,065 "(1,65) | + / - 0,010 "(0,25) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 4 "(101,6) | 0,083 "(2,11) | + / - 0,015 "(0,38) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | + / - 0,030 "(0,76) | +1 "(25,4) - 0 | + / - 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | + / - 0,030 "(0,76) | +1 "(25,4) - 0 | + / - 10,0% |
| 8 "(203,2) | 0,109 "(2,77) | +0,061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | + / - 10,0% |
Aplikasi:
Produk diterapkan untuk perdagangan seperti pembuatan kertas, industri kimia, pembuatan kapal, minyak bumi, listrik, makanan,
farmasi, gas alam, metalurgi, arsitektur, pembuangan limbah, perlindungan lingkungan, ruang angkasa, penukar panas, dll. Secara ekstensif.
