Bentuk Bulat Tabung Stainless Seamless ASTM A213 TP304 TP304L 6M Min WT 16BWG
Product Details
| Bahan: | TP304, TP304L, TP316L, SUS04, SUS304L, SUS316L, 1.4404.1.4307.1.4301 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Bulat mulus |
| OD: | 6.00MM-101.6MM | WT: | 0,5MM-8MM |
| Menyoroti |
ss pipa seamless,tabung ketel stainless steel |
||
Product Description
Tabung Mulus Stainless Steel, ASTM A213, ASME SA213 -2015 TP310, 310S, TP316Ti, TP347, 904L, TP347H, 254Mo
0Cr18Ni12Mo2Ti, TP 316Ti=UNS S31635=1.4571, This is one of the family of 17%Cr12-13%Ni steels containing Mo of 2,0-2,4% stabilized with Ti which minimizes chromium carbide precipitation and improves resistance to intergranular corrosion. 0Cr18Ni12Mo2Ti, TP 316Ti = UNS S31635 = 1.4571, Ini adalah salah satu keluarga 17% Cr12-13% Baja Ni yang mengandung Mo sebesar 2,0-2,4% yang distabilkan dengan Ti yang meminimalkan presipitasi kromium karbida dan meningkatkan ketahanan terhadap korosi intergranular . In the damp industrial or coastal atmospheres of Europe, they perform better than TP 304/304L and ferritic grades. Di atmosfer industri atau pesisir yang lembab di Eropa, mereka berkinerja lebih baik daripada TP 304 / 304L dan kadar feritik. In low temperature seawater they offer limited resistance to pitting but are susceptible to crevice attack. Dalam air laut suhu rendah, mereka menawarkan ketahanan terbatas terhadap lubang tetapi rentan terhadap serangan celah. Their short- and long-time properties at elevated temperatures are also superior to those of comparable TP 304/304L grades. Sifatnya yang pendek dan lama pada suhu yang tinggi juga lebih unggul dibandingkan dengan kelas TP 304 / 304L yang sebanding.
Specifikasi:
ASME SA213/ A213: Spesifikasi Standar untuk Seamless Feritik dan Austenitik Paduan-
Boiler Baja, Superheater, dan Tabung Penukar Panas Stainless Steel.
ASTM A249 / A249M: Spesifikasi Standar untuk Welded Austenitic Steel Boiler, Superheater
Heat-Exchanger, dan Tabung Kondensor.
Standar lainnya:DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463 ...
Kelas bahan:
| Standar Amerika | Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15М3Т, 12 hingga 088 hari, 22, 22, 22, 19, 19, 19, 19, 08, 08, 08, 08, 08, 10 |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Tabung Penukar Panas | 6.00mm hingga 101.6mm | 0,5mm hingga 8mm |
Finishing Akhir
Solusi Anil & Acar/ Bright Annealed.
Jenis tabung:
Bengkok & Lurus.
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tensile | Tarik | Hardness | Kekerasan | Flattening | Meratakan | Flare | Flare | Flange Penghubung jalur pipa |
| Reverse-bend and Re. Reverse-bend dan Re. flat tests tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Eddy Current Testing | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatik 100% dilakukan sesuai dengan ASTM-A 450 norma untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Tekanan Udara Di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui inspeksi visual menyeluruh oleh staf terlatih untuk mendeteksi cacat permukaan & ketidaksempurnaan lainnya. |
Pengujian Tambahan: Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. Terlepas dari tes yang disebutkan di atas, kami juga melakukan pengujian tambahan produk yang diproduksi. The tests conducted under this include: Tes yang dilakukan di bawah ini meliputi:
|
|
|
