Tabung Stainless Bulat Seamless / Acar Tabung Anil EN10216 5 1.4301 1.4307 1.4401
Product Details
| Bahan: | 1.4301 1.4307 1.4401 1.4404 1.4571 1.4438 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Bulat mulus |
| OD: | 6.00mm hingga 101.6mm | WT: | 0,5mm hingga 8mm |
| Menyoroti |
ss pipa seamless,tabung ketel stainless steel |
||
Product Description
EN10216-5 1.4301 1.4307 1.4401 1.4404 1.4571 1.4438, Tabung Stainless Steel Seamless, Acar dan Padat dan Dianil.
Teknologi Energi Hua Dong memiliki lebih dari 35 tahun pengalaman untuk penukar panas tabung/tabung boiler/tabung pendingin,
Produk utama kami: Pipa / Tabung Stainless / Karbon / Paduan Nikel:
1>.A:Tahan karat Kelas Baja: TP304/304L/304H, TP310S/310H, TP316/316L/316Ti/316H, TP317L/317LN, TP321/321H, TP347/347H, NO8904(904L),
B:tahan karat PH Baja: 17-4PH(1.4542), 17-7PH(1.4568),15-7PH(1.4532)
C:Baja karbon: Q235B.
D:Paduan Nikel Kualitas baja:Hestalloy:C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel:400.401, 404, R-405, K500.
Inkonel:600, 601, 617, 625, 690, 718, 740, X-750. Incoloy:800, 800H, 800HT, 825, 840.
Nikel Murni:Ni-200, Ni-201, Ni-270. Paduan NS:Ns 1101, NS1102, NS1103, NS3105.
2>. Standar: ASTM A213, A249, A269, A312, A789, A790, B163, B167, B444, B677,... dan ASME, DIN, EN, JIS, BS, GOST,...
3>. Kisaran ukuran diameter luar: 0.5mm ~ 650mm.Ketebalan dinding: 0,05mm ~ 60mm.Maks.panjang di bawah 26 meter/PC.
4>. Mulus & dilas, Solution Pickling / Bright Annealed / Dipoles.
Produk Keuntungan: (Boiler & Penukar Panas & Tabung Kondensor):
ASTM A213 (TP304, TP304L, TP304H, TP310S, TP316L, TP316Ti, TP317/L, TP321/H, TP347/H)
ASTM A249 (TP304, TP304L, TP316L, TP321 / H)
ASTM A789(S31803(2205), 32750(2507), S31254(254MO),S32304)
ASTM B163 / B167 / B444 untuk Tabung Baja Paduan Nikel
ASTM B677 UNS NO8904(904L)
ASTM B111 (70400, C70600, C71500, C71640, C68700, C44300)
Standar Lainnya: EN10216-5, DIN 17456, DIN17458, GOST9941-81, JIS-G3459, JIS-G3463
| Kelas | Bahan jumlah |
C | Si | M N | P | S | tidak | Cr | Mo | Ni | Ti | orang lain |
| Baja feritik atau martensit | ||||||||||||
| X2CrTi12 | 1.4512 | 0,030 |
1.00 | 1.00 | 0,040 | 0,015 | 10.50 hingga 12.50 | 6×(C+N) hingga 0,65 | ||||
| X6CrAl13 | 1.4002 | 0,08 |
1.00 | 1.00 | 0,040 | 0,015 | 12.00 hingga 14.00 | 0.10to0.30Al | ||||
| X6Cr17 | 1.4016 | 0,08 |
1.00 | 1.00 | 0,040 | 0,015 | 16.00 hingga 18.00 | |||||
| X3CrTi17 | 1.4510 | 0,05 |
1.00 | 1.00 | 0,040 | 0,015 | 16.00 hingga 18.00 | 4×(C+N)+0,15 hingga 0,80 | ||||
| X12Cr13 | 1.4006 | 0,08 hingga 0,15 | 1.00 | 1.50 | 0,040 | 0,015 | 11.50 hingga 13.50 | 0,75 |
||||
| Baja Austenitik | ||||||||||||
| X5CrNi18-10 | 1.4301 | 0,07 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
17.00 hingga 19.50 | 8.00 hingga 10.50 | |||
| X2CrNi19-11 | 1.4306 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
18.00 hingga 20.00 | 10.00 sampai 12.00 | |||
| X2CrNiN18-10 | 1.4311 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.12 hingga 0.22 | 17.00 hingga 19.50 | 8.50 hingga 11.50 | |||
| X6CrNiTi18-10 | 1.4541 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 17.00 hingga 19.00 | 9.00 hingga 12.00 | 5 × C hingga 0,70 | |||
| X6CrNiNb18-10 | 1.4550 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 17.00 hingga 19.00 | 9.00 hingga 12.00 | 10×Cto1.00Nb | |||
| X5CrNiMo17-12-2 | 1.4401 | 0,07 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16.50 hingga 18.50 | 2,00 hingga 2,50 | 10.00-13.00 | ||
| X2CrNiMo17-12-2 | 1.4404 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16.50 hingga 18.50 | 2,00 hingga 2,50 | 10.00-13.00 | ||
| X6CrNiMoTi17-12-2 | 1.4571 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 16.50 hingga 18.50 | 2,00 hingga 2,50 | 10.50 hingga 13.50 | 5 × C hingga 0,70 | ||
| X2CrNiMoN17-13-3 | 1.4429 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.12 hingga 0.22 | 16.50 hingga 18.50 | 2.50 hingga 3.00 | 11.00 sampai 14.00 | ||
| X2CrNiMo18-14-3 | 1.4435 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
17.00 hingga 19.00 | 2.50 hingga 3.00 | 12.50 hingga 15.00 | ||
| X3CrNiMo17-13-3 | 1.4436 | 0,05 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16.50 hingga 18.50 | 2.50 hingga 3.00 | 10.50 hingga 13.00 | ||
| X2CrNiMoN17-13-5 | 1.4439 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.12 hingga 0.22 | 16.50 hingga 18.50 | 4.00 sampai 5.00 | 12.50 hingga 14.50 | ||
Sspesifikasi:
ASME SA213/A213: Spesifikasi Standar untuk Seamless Ferritic dan Austenitic Alloy-
Steel Boiler, Superheater dan Tabung Penukar Panas Stainless Steel.
ASTM A249 / A249M:Spesifikasi Standar untuk Welded Austenitic Steel Boiler, SuperheaterPenukar Panas, dan Tabung Kondensor.
Standar lainnya:DIN 17456 , DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463,...
Kelas Bahan:
| Standar Amerika |
Baja Austenitik: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405,TP409, TP410, TP430, TP439,... |
| Standar Eropa | 1.4301.1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1,4462, 1,4362, 1,4410, 1.4501 |
| Standar Rusia | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х1812,121810,12Х |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Tabung Penukar Panas | 6.00mm hingga 101.6mm | 0,5mm hingga 8mm |
Penyelesaian Akhir
Solusi Anil & Acar/Anil Cerah.
Jenis Tabung:
U-tikungan & Lurus.
Sertifikasi
