Ss Seamless Welded Stainless Steel Pipe ASTM Standard TP304, TP304L, TP316L
Product Details
| Bahan: | TP304, TP304L, TP316L,, SUS304, SUS304L, SUS316L, 1.4301.1.4307.1.4404 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 6.00mm hingga 1016mm | ketebalan dinding: | 1mm hingga 35mm |
| Menyoroti |
ss pipa las,pipa erw stainless steel |
||
Product Description
Ss Seamless Welded Stainless Steel Pipe ASTM Standard TP304, TP304L, TP316L
Teknologi Energi Hua Dong memiliki pengalaman lebih dari 35 tahun untuk tabung penukar panas / tabung boiler / tabung pendingin,
| Produk: | Pipa Stainless Steel Sanitasi |
| Proses Manufaktur: | Ditarik dingin, Acar, Anil |
| Standar: | ASTM A270 |
| Kelas Bahan: | TP316 / 316L / 316Ti ... |
| Diameter luar. | Φ 6,00 mm - Φ 1016 mm;1 "NB sampai 12" NB |
| Ketebalan: | 1mm - 35mm;SCH5 / 10/40/80/120 |
Deskripsi:
Standar Amerika:
ASTM A 270 Spesifikasi Seamless dan Welded Austenitic dan Ferritic / Austenitic Stainless Steel Sanitary Tubing
Detail ukuran:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa stainless steel sanitasi | 6,00 mm hingga 1016 mm | 1 mm sampai 35 mm |
Toleransi Dimensi:
semua dimensi dalam inci (mm)
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12,7) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,005 (0,13) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 1 - 1/2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,008 "(0,20) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 2 "(50,8) | 0,065 "(1,65) /0,049" (1,25) | + / - 0,008 "(0,20) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 2 - 1/2 "(63,5) | 0,065 "(1,65) | + / - 0,010 "(0,25) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 3 "(76,2) | 0,065 "(1,65) | + / - 0,010 "(0,25) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 4 "(101,6) | 0,083 "(2,11) | + / - 0,015 "(0,38) | +1/8 "(3,18) - 0 | + / - 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | + / - 0,030 "(0,76) | +1 "(25,4) - 0 | + / - 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | + / - 0,030 "(0,76) | +1 "(25,4) - 0 | + / - 10,0% |
| 8 "(203,2) | 0,109 "(2,77) | +0,061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | + / - 10,0% |
Aplikasi:
Produk diterapkan untuk perdagangan seperti pembuatan kertas, industri kimia, pembuatan kapal, minyak bumi, listrik, makanan,
farmasi, gas alam, metalurgi, arsitektur, pembuangan limbah, perlindungan lingkungan, dirgantara, penukar panas, dll.
