ASTM A179 ASME SA179 Tabung Boiler Seamless Gr A Gr C Oil Dip Surface Treat
Product Details
| Nama Produk: | Tabung Boiler Baja Karbon Seamless | Aplikasi: | Untuk ketel bertekanan tinggi dan menengah, dan tujuan tekanan |
|---|---|---|---|
| Standar: | A192, SA192 | Teknik: | Mulus |
| Bentuk bagian: | Bulat | Bahan: | Baja karbon |
| Menyoroti |
ASME SA179 Oil Dip Tubes,ASME SA179 Seamless Boiler Tubes,ASTM A179 Oil Dip Boiler Tubes |
||
Product Description
ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tubing / tabung / tabung, Gr.A, GR.C e
ASTM A179 ASME SA179 Seamless Carbon Steel Boiler Tubing / tabung / tabung, Gr.A, GR.C e
Aplikasi: Untuk boiler bertekanan tinggi, menengah, rendah dan tujuan tekanan
Standar Produksi, Grade, Baja No:
ASTM A178 Kelas A, C, D
ASTM A179 Kelas A, C, D
ASTM A192
ASTM A210 KelasA-1, C.
BS3059-Ⅰ 320 CFS
BS3059-Ⅱ 360, 440, 243, 620-460, 622-490, S1, S2, TC1, TC2
EN10216-1 P195TR1 / TR2, P235TR1 / TR2, P265TR1 / TR2
EN10216-2 P195GH, P235GH, P265GH, TC1, TC2
DIN17175 ST35.8, ST45.8
DIN1629 ST37.0, ST44.0, ST50.0
JIS G3454 STPG370, STPG410
JIS G3461 STB340, STB410, STB440
GB5310 20G, 15MoG, 12CrMoG, 12Cr2MoG, 15CrMoG, 12Cr1MoVG, 12Cr2MoWVTiB
GB9948 10, 20, 12CrMo, 15CMo
GB3087 10, 20
Kondisi pengiriman:Anil, Normalisasi, Normalisasi dan Tempered
Inspeksi dan Tes:
Pemeriksaan Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Luluh,
Pemanjangan, Pembakaran, Perataan, Pembengkokan, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Tanpa Perusakan, Uji Hidrostatis.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||||
| Diameter luar | BWG | ||||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||||
| Ketebalan Dinding mm | |||||||||||
| 0,508 | 0.71 | 0.89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||||
| mm | inci | Berat kg / m | |||||||||
| 6.35 | 1/4 | 0,081 | 0.109 | 0.133 | 0.174 | 0.212 | |||||
| 9.53 | 3/8 | 0.126 | 0.157 | 0.193 | 0.257 | 0,356 | 0.429 | ||||
| 12.7 | 1/2 | 0.214 | 0.263 | 0,356 | 0.457 | 0,612 | 0,754 | ||||
| 15.88 | 5/8 | 0.271 | 0,334 | 0.455 | 0,588 | 0.796 | 0,995 | ||||
| 19.05 | 3/4 | 0,327 | 0.405 | 0,553 | 0.729 | 0.895 | 1.236 | ||||
| 25.4 | 1 | 0.44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |||
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |||
| 38.1 | 1 1/2 | 0,667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |||
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||||
Bentuk Tube: Lurus & U-bend & Bersirip & Coiled
