Tabung Penukar Panas Stainless Steel Bright Annealed Welded ASME SA213
Product Details
| Bahan: | TP304, TP304L, TP304H, TP304LN, 1.4301, 1.4306, 1.4307, 08X18H10 | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 6-630mm | ketebalan dinding: | 0,4-30mm |
| Menyoroti |
ss pipa las,pipa erw stainless steel |
||
Product Description
Tabung Penukar Panas Stainless Steel Terang Annealed Welded ASME SA213
Teknologi Energi Hua Dong memiliki pengalaman lebih dari 35 tahun untuk tabung penukar panas / tabung boiler / tabung pendingin,
ASTM A249 / A249M: Spesifikasi Standar untuk Boiler Baja Austenitik Dilas, Superheater
Heat-Exchanger, dan Kondensor Tubes.
Standar Lain: DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463, ...
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tarik |Kekerasan |Meratakan |Flare |Penghubung jalur pipa |
| Reverse-bend dan Re.tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Pengujian Arus Eddy | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatis 100% dilakukan sesuai dengan norma ASTM-A 450 untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Udara Di Bawah Tekanan | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui pemeriksaan visual menyeluruh oleh staf terlatih untuk mendeteksi kekurangan permukaan & ketidaksempurnaan lainnya |
Pengujian Tambahan: Selain pengujian yang disebutkan di atas, kami juga melakukan pengujian tambahan pada produk manufaktur.Tes yang dilakukan di bawah ini meliputi:
|
|
|
