ASME SA213 TP310S Stainless Steel Pipa Mulus / Boiler Steel Tube 25.4 * 2.11MM
Product Details
| Bahan: | TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H | Selesai: | Anil & Acar |
|---|---|---|---|
| Aplikasi: | Boiler, Penambangan, Pipa gas | Bentuk: | Mulus |
| OD: | 6.00mm-850mm | WT: | 0,5mm-68mm |
| Menyoroti |
ss tabung mulus,tabung baja stainless mulus |
||
Product Description
Pipa Stainless Steel Mulus, BOILER / TABUNG PENUKAR PANAS, ASTM A213 / A213M, ASME SA213 TP310S, 25,4 * 2.11MM.
Spesifikasi:
ASME SA213 / A213: Spesifikasi Standar untuk Seamless Feritik dan Austenitik Paduan-
Boiler Baja, Superheater, dan pipa Penukar Panas Stainless Steel.
Kelas bahan:
| Standar Amerika |
Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15AJ, 21, 22, 22, 22, 22, 19, 19, 19, 19, 07, 08, 08, 08, 08, 09, 08, 08, 08, 08, 08, 08, 08 |
Rentang ukuran:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa Boiler | 6.00mm-850mm | 0,5mm-68mm |
Finishing Akhir
Solusi Annealed & Acar / Bright Annealed.
Jenis pipa:
Bengkok atau Lurus.
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tarik |Kekerasan |Meratakan |Flare |Penghubung jalur pipa |
| Reverse-bend dan Re.tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Eddy Current Testing | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatik 100% dilakukan sesuai dengan ASTM-A 450 norma untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Tekanan Udara Di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui inspeksi visual menyeluruh oleh staf terlatih untuk mendeteksi cacat permukaan & ketidaksempurnaan lainnya. |
Pengujian Tambahan: Terlepas dari tes yang disebutkan di atas, kami juga melakukan pengujian tambahan produk yang diproduksi.Tes yang dilakukan di bawah ini meliputi:
|
|
|
