Pipa Las Stainless Steel ASTM A312 TP304H TP321 ASTM A790 S31803 SCH10 SCH40,6M 11,8M
Product Details
| Bahan: | TP304, TP304L, TP304H, TP321, TP316L, S31803, SUS304, SUS304L, SUH304H, SUS321, SUS316L, SUS329J3L | Selesai: | Annealed & Acar / Bright Annealed |
|---|---|---|---|
| Aplikasi: | boiler, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan fluida | Bentuk: | Bulat mulus |
| Diameter luar: | 6.00mm hingga 830mm | ketebalan dinding: | 0,5mm hingga 48mm |
| Menyoroti |
ss pipa las,pipa erw stainless steel |
||
Product Description
Pipa Las Stainless Steel ASTM A312 TP304 TP304L TP304H TP321 TP316L ASTM A790 S31803, SCH10, SCH40,6M 11,8M
Hua Dong Energy Technology memiliki lebih dari 35 tahun pengalaman untuk tabung penukar panas / tabung boiler / tabung pendingin,
Spesifikasi standar:
ASTM A249 / A249M - 10a Spesifikasi standar untuk Welded Austenitic Steel Boiler, Superheater,
Heat-Exchanger, dan Tabung Kondensor
ASTM A269 - 10: Spesifikasi Standar untuk Tabung Stainless Steel Austenitic Seamless dan Welded
untuk Layanan Umum
ASTM A312 / A312M - 12: Spesifikasi Standar untuk Bekerja Seamless, Welded, dan Heavily Cold
Pipa Stainless Steel Austenitik
ASTM A358 / A358M-08a: Spesifikasi Standar untuk Austenitic Elektrik-Fusion-Dilas
ASTM A778 - 01 (2009) e1: Spesifikasi Standar untuk Welded, Austenitic Stainless Unannealed
Produk Baja Tubular
ASTM A789 / A789M - 10a: Spesifikasi Standar untuk Pipa Stainless Steel Feritik Austenitic Mulus dan Dilas untuk Layanan Umum
ASTM A790 / A790M - 11: Spesifikasi Standar untuk Pipa Stainless Steel Feritik Austenitic Seamless dan Welded
Lainnya seperti BS, JIS, DIN, EN, GOST standar yang kami semua dapat sediakan.
Kelas bahan:
| Standar Amerika | Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15М3Т, 12 hingga 088 hari, 22, 22, 22, 19, 19, 19, 19, 08, 08, 08, 08, 08, 10 |
Penunjukan: A312 / A312M-04a / ASTM A790 / A790M - 11:
Spesifikasi standar untuk Austenitic yang dilas, dan sangat dingin bekerja
Pipa Stainless Steel
Jika klien memiliki persyaratan inspeksi, kami dapat menerima inspeksi berikut:
| Proses pembuatan | ERW Welded (ELD) Pipe |
Pengecekan kualitas |
|
Persyaratan Mekanik |
Grade UNS Penunjukan Kekuatan Tarik Kekuatan Min Ks i [M pa] Min Ks i [M pa] TP304 S30400 75 [515] 30 [205] TP304L S30403 70 [485] 25 [170] TP309S S30908 75 [515] 30 [205] TP310S S31008 75 [515] 30 [205] TP316L S31603 70 [485] 25 [170] .... .... ..... .... |
|
|
|
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa Las | 6.00mm hingga 830mm | 0,5mm hingga 48mm |
Final Finishing:
Solusi Anil & Acar
Product Highlights
Pipa Las Stainless Steel ASTM A312 TP304 TP304L TP304H TP321 TP316L ASTM A790 S31803, SCH10, SCH40,6M 11,8M Hua Dong Energy Technology memiliki lebih dari 35 tahun pengalaman untuk tabung penukar panas / tabung boiler / tabung pendingin, Spesifikasi standar: ASTM A249 / A249M - 10a Spesifikasi ...
