100 ET HT UT Pipa Seamless Stainless Steel Untuk Penukar panas Pendingin Udara Kondensor
Product Details
| Bahan: | TP304 / 304L, TP316L, TP310S, TP316Ti, TP321 / 321H, TP347, TP317 | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, Kondensor, energi, industri petrokimia, pertambangan, gas dan fluida | Bentuk: | Bulat mulus |
| OD: | 6.00mm hingga 850mm | WT: | 0,5mm hingga 68mm |
| Menyoroti |
tabung baja stainless mulus,astm pipa baja stainless |
||
Product Description
Penukar Panas ( Intercambiador de calor ) Pendingin Udara Kondensor Tabung Seamless 100 ET / HT / UT
Sspesifikasi:
ASME SA213/A213: Spesifikasi Standar untuk Seamless Ferritic dan Austenitic Alloy-
Pipa Boiler Baja, Superheater, dan Penukar Panas Stainless Steel.
ASTM A249 / A249M:Spesifikasi Standar untuk Welded Austenitic Steel Boiler, Superheater
Pipa Penukar Panas, dan Kondensor.
ASTM A789/A789M, ASME SA789/SA789M Pipa Stainless Steel Feritik/Austenitik yang Mulus dan Dilas untuk Layanan Umum
Standar lainnya:DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463,...
Kelas Bahan:
| Standar Amerika |
Baja Austenitik: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405,TP409, TP410, TP430, TP439,... |
| Standar Eropa | 1.4301.1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1,4841,1,4845,1,4539,1.4162, 1,4462, 1,4362, 1,4410, 1.4501 |
| Standar Rusia | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х1812,121810,12Х |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Tabung Penukar Panas | 6.00mm hingga 850mm | 0,5mm hingga 68mm |
Penyelesaian Akhir
Solusi Anil & Acar/Anil Cerah.
Jenis pipa:
U-tikungan & Lurus.
Beberapa pengujian kualitas yang kami lakukan antara lain:
| Uji Korosi | Dilakukan hanya jika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang dipersyaratkan |
| Pengujian Destruktif / Mekanik | Tarik |kekerasan |Meratakan |Suar |Penghubung jalur pipa |
| Reverse-bend dan Re.tes datar | Dilakukan dengan kepatuhan penuh terhadap standar yang relevan & norma ASTM A-450 dan A-530, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Pengujian Arus Eddy | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatik 100% dilakukan sesuai dengan norma ASTM-A 450 untuk memeriksa kebocoran tabung, dan tekanan terbesar yang dapat kami dukung 20Mpa/7s. |
| Uji Tekanan Udara di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa diperiksa secara visual oleh staf terlatih untuk mendeteksi cacat permukaan & ketidaksempurnaan lainnya |
Pengujian Tambahan: Selain pengujian yang disebutkan di atas, kami juga melakukan pengujian tambahan pada produk yang diproduksi.Tes yang dilakukan di bawah ini meliputi:
|
|
|
Sertifikasi
