Erw Las Pipa Baja Galvanis Struktural L390 X56 L415 X60 0.8mm Sampai 30mm Tebal
Product Details
| Bahan: | Tabung Las Baja Karbon | Selesai: | Anil, Normalisasi, Normalisasi dan Marah |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Sertifikat: | ASME, TUV, SGS, CE, ISO9001, |
| Bentuk: | pipa dilas | ||
| Menyoroti |
cs erw pipa,pipa baja spiral dilas |
||
Product Description
L390 (X56) L415 (X60) Carbon Steel Welded Pipe Steel Tubing Struktural dalam Putaran dan Bentuk
Rincian Produk
| Min. Min. Order / Reference FOB Price Pesanan / Referensi Harga FOB | |
|---|---|
| 20 Ton | US $ 500-500 / Ton |
| Kapasitas produksi: | 100000mt Per Tahun |
|---|---|
| Paket Transportasi: | Diikat dalam Bundel demi Strip |
| Syarat pembayaran: | L / C, T / T, Western Union |
| Tipe: | Lasan |
|---|---|
| Teknik: | ERW |
| Bahan: | Baja karbon |
2. Bahan kelas: Q195, Q235, SS400, A53, A500 Gr.B / Baja sekutu rendah
3. Lesi: OD21mm hingga 720mm
4. Ketebalan dinding: 0.8mm hingga 30mm
5. Sertifikat: SGS, CE, BV, ISO9001-2008
6. Pipa Dilas Packing:
A. Dengan sabuk baja dalam bundel, atau pengepakan massal
B. Diminyaki dan pengepakan dengan sabuk baja
C. Diminyaki dengan film PVC atau kantong plastik tahan air
7. Aplikasi Pipa Dilas: perabot baja (meja, kursi dll), iklan dll
8. pengobatan permukaan: diminyaki dan anti karat
| Dimensi normal pipa baja | |||||
| Square (SHS) | Rectangular (RHS) | Lingkaran (CHS) | |||
| Keluar dia. (mm) |
ketebalan dinding (mm) |
Keluar dia. (mm) |
ketebalan dinding (mm) |
Keluar dia. (mm) |
ketebalan dinding (mm) |
| 10 × 10 | 0,5-1,0 | 10 × 20 | 0.6-1.0 | 10 | 0,5-1,0 |
| 12 × 12 | 0,5-1,0 | 12 × 25 | 0.6-1.0 | 12 | 0.6-1.0 |
| 16 × 16 | 0.6-1.2 | 20 × 40 | 0.6-1.6 | 16 | 0.6-1.0 |
| 19 × 19 | 0.6-1.5 | 25 × 50 | 0.8-2.75 | 19 | 0.6-1.5 |
| 20 × 20 | 0.6-1.6 | 30 × 50 | 0.8-3.0 | 20 | 0.6-1.5 |
| 25 × 25 | 0.8-2.75 | 30 × 60 | 0.8-3.0 | 21.5 | 0.6-1.5 |
| 30 × 30 | 0.8-2.75 | 40 × 60 | 1.0-4.0 | 25 | 0.8-2.75 |
| 32 × 32 | 1.0-3.0 | 40 × 80 | 1.5-4.0 | 27 | 0.8-2.75 |
| 38 × 38 | 1.0-3.0 | 50 × 75 | 1.5-4.0 | 32 | 0.8-3.0 |
| 40 × 40 | 1.0-3.5 | 50 × 100 | 2.0-6.0 | 38.1 | 1.0-3.0 |
| 50 × 50 | 1.0-5.0 | 50 × 125 | 2.0-6.0 | 42.5 | 1.0-3.5 |
| 60 × 60 | 1.0-6.0 | 50 × 150 | 3.0-6.0 | 48.4 | 1.0-5.0 |
| 63.5 × 63.5 | 1.0-6.0 | 60 × 80 | 1.5-6.0 | 50.8 | 1.0-5.0 |
| 70 × 70 | 1.5-6.0 | 60 × 100 | 2.0-6.0 | 63.5 | 1.0-6.0 |
| 75 × 75 | 1.5-6.0 | 60 × 120 | 2.0-6.0 | 68 | 1.2-6.0 |
| 80 × 80 | 2.0-6.0 | 75 × 100 | 2.0-6.0 | 70 | 1.2-6.0 |
| 90 × 90 | 2.0-6.0 | 75 × 125 | 2.0-6.0 | ||
Keuntungan perusahaan
- HDT berdedikasi dalam menyediakan dan mengekspor pipa baja las dan fitting yang kompetitif di berbagai kelas baja.
- Kami adalah produsen penjualan langsung yang mengkhususkan diri dalam penelitian dan pengembangan Pipa Baja Galvanis, Pipa Baja Dilas, Tabung Baja Cerah di dalam dan di luar.
- Perusahaan kami mempertahankan hubungan dosis dengan banyak pemasok strip baja besar dan Baja.
- Kami memastikan bahwa bahan berkualitas terbaik digunakan untuk produk kami.
- Jika Anda tidak yakin dengan apa yang sebenarnya Anda butuhkan - jangan ragu untuk menghubungi kami kapan saja dan dapatkan bantuan profesional dari kami.
- Best Frame. Frame terbaik. Sincerely have an opportunity to cooperate with all customers. Hormat kami memiliki kesempatan untuk bekerja sama dengan semua pelanggan.
- Sangat menyambut dan menantikan untuk bekerja sama dengan Anda yang terhormat!
- Ini sangat superior untuk lokasi dan nyaman untuk transportasi.
