Putaran Ss Seamless Tube Hollow Bar A511 TP304 304 TP310 310S Kelas Ganda
Product Details
| Bahan: | TP304 / 304L, TP309 / 309S, TP310 / 310S, TP310 / 310H, TP316 / 316L, TP317 / 317L, TP321 / 321H, TP | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, Kondensor, energi, industri petrokimia, pertambangan, gas dan fluida | Bentuk: | Bulat mulus |
| OD: | 6.00mm hingga 830mm | WT: | 0,5mm hingga 52mm |
| Menyoroti |
ss tabung mulus,astm pipa stainless steel |
||
Product Description
Pipa Mulus Stainless Steel, Hollow Bar, A511 TP304 / 304L, TP310 / 310S, TP316 / 316L, TP321 / 321H Kelas Ganda
UKURAN: 1/8 "NB - 24" NB
ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30S, SCH 60S, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS
LULUS: TP304 / 304L / 304N / 304H, TP310S / 310H, TP316 / 316L / 316Ti / TP316H / 316H / 316LN, TP317 / 317L, TP317LN, TP321 / 321H, TP347 / 347H.
Seamless stainless steel pipe is fully softened & descaled. Pipa stainless steel yang mulus sepenuhnya dilembutkan & dikeringkan. In 5-7 metre random lengths. Dalam panjang acak 5-7 meter. Tolerances & testing to ASTM A 312/ASME SA312-A530. Toleransi & pengujian ke ASTM A 312 / ASME SA312-A530. Conforming to NACE Standard MR-01-75(Latest Revision) Certificate to DIN 50049-3.1.B./EN 10 204-3.1.B. Sesuai dengan NACE Standard MR-01-75 (Revisi Terbaru) Sertifikat ke DIN 50049-3.1.B./EN 10 204-3.1.B.
PIPA DUPLEX SEAMLESS DAN WELDED / PIPA SUPER DUPLEX SEAMLESS
UKURAN: 1/2 "NB - 8" NB (Dupleks Mulus / Dupleks Super)
UKURAN: 6 "NB - 24" NB (Dupleks Dilas)
Duplex Grade. Kelas Dupleks. Seamless Ferritic/Austenitic Stainless Steel Pipe to ASTM A790 UNS S31803 (Duplex) UNS S32760 (Super Duplex) and ASTM A928 UNS S31803 (Welded Duplex), . Pipa Stainless Steel Ferritic / Austenitic Seamless ke ASTM A790 UNS S31803 (Duplex) UNS S32760 (Super Duplex) dan ASTM A928 UNS S31803 (Welded Duplex),. Cold/Hot finished, solution annealed & descaled in random lengths 5-7.5 metres. Cold / Hot selesai, solusi anil & descaled dalam panjang acak 5-7,5 meter. Conforming to NACE Standard MR-0175(Latest Revision) Sesuai dengan NACE Standard MR-0175 (Revisi Terbaru)
NILAI LAINNYA
Enquiries are welcome on grades such as 904L, 316TI, 347H, 304H and 6 Moly, 310 and 317L. Pertanyaan diterima di kelas seperti 904L, 316TI, 347H, 304H dan 6 Moly, 310 dan 317L. We are also able to offer other grades on application including Duplex Fittings and Super Duplex Fittings. Kami juga dapat menawarkan nilai lain pada aplikasi termasuk Duplex Fittings dan Super Duplex Fittings.
Spesifikasi standar:
ASTM A213 / A213M - 11a: Spesifikasi Standar untuk Boiler Baja Mulus Feritik dan Austenitik, Superheater, dan Tabung Penukar Panas
ASTM A269 - 10: Spesifikasi Standar untuk Tabung Stainless Steel Austenitic Mulus dan Dilas untuk Layanan Umum
ASTM A312 / A312M - 12: Spesifikasi Standar untuk Pipa Stainless Steel Austenitic Seamless, Welded, dan Heavily Cold
ASTM A511 / A511M - 12: Spesifikasi Standar untuk Pipa Mekanik Stainless Steel Seamless
ASTM A789 / A789M - 10a: Spesifikasi Standar untuk Pipa Stainless Steel Seamless dan Feritik / Austenitik untuk Layanan Umum
ASTM A790 / A790M - 11: Spesifikasi Standar untuk Pipa Stainless Steel Feritik / Austenitic Seamless dan Welded
DIN 17456-2010: PIPA STAINLESS STEEL PUROSE UMUM.
DIN 17458-2010: Melingkar Seamless dari Pipa Stainless Steel Austenitic
EN10216-5 CT 1/2 : Pipa Seamless Stainless Steel
GOST 9941-81: PIPA DINGIN YANG MULAT DINGIN DAN KERJA YANG DIBUAT DARI BAJA TAHAN KOROSI.
Yang lain seperti BS, standar JIS juga bisa kami supply
Kelas bahan:
| Standar Amerika | Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15М3Т, 12 hingga 088 hari, 22, 22, 22, 19, 19, 19, 19, 08, 08, 08, 08, 08, 10 |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa seamless | 6.00mm hingga 830mm | 0,5mm hingga 52mm |
Final Finishing:
Solusi Anil & Acar
Aplikasi:
- Peralatan pengolahan makanan, khususnya dalam pembuatan bir, pengolahan susu & pembuatan anggur.
- Bangku dapur, wastafel, bak, peralatan dan peralatan
- Panel arsitektur, pagar & trim
- Wadah kimia, termasuk untuk transportasi
- Penukar panas
- Layar anyaman atau dilas untuk penambangan, penggalian & penyaringan air
- Pengencang berulir
- Mata air
- Lainnya
