Dipoles Ss Stainless Steel Welded Tubing / Stainless Steel Welded Pipe
Product Details
| Bahan: | Seri Stainless Steel / 300 | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 5.80mm hingga 2032mm | WT: | 0,25mm hingga 28mm |
| Menyoroti |
pipa las stainless steel,tabung stainless steel duplex |
||
Product Description
Tabung Las Stainless Steel Dipoles Dan Digiling, Panjang Lurus
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap
year sell more than 5000 tons of stainless steel pipe and tube. tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel. Our client already cover more than 45 Klien kami sudah mencakup lebih dari 45
countries. negara. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
Kelas bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 Dll |
| Standar Eropa | 1.4301, 1.4306, 1.4845, 1.4401, 1.4404, 1.4571, 1.4541, 1.4550, 1.4539, 1.4462 dll. |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
1 . 1. OD ( Outer Diameter ) : OD (Diameter Luar): 5.80mm hingga 2032mm (0,23 inci hingga 80 inci)
2 . 2. WT ( Wall Thickness ) : WT (Ketebalan Dinding): 0,25mm hingga 28mm (0,01 inci hingga 1,125 inci)
3 . 3. Length : Panjangnya : Sesuai dengan kebutuhan pelanggan
4 . 4. Standards : Standar: ASTM A312; ASTM A312; ASTM A269; ASTM A269; ASTM A789; ASTM A789; ASTM A790 ect ASTM A790 dll
5 . 5. Process Method : Metode proses: ERW, EFW dll
| Aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan permesinan | |
| c) pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang unggul |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi sempurna dan peralatan inspeksi | |
| Barang Harga: | FOB, CFR, CIF atau sebagai negosiasi |
| Pembayaran: | T / T, LC atau sebagai negosiasi |
Komposisi kimia——Bahan Baku Dasar
| ASTM / UNS | C (maks) | Si (maks) | Mn (maks) | P (maks) | S (maks) | Cr | Ni | Mo | Ti |
| TP304 / S30400 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L / S30403 | 0,035 | 1,00 | 2,00 | 0,045 | 0,03 | 18.0-20.0 | 8.0-13.0 | ||
| TP304H / S30409 | 0,04-0,10 | 1,00 | 2,00 | 0,045 | 0,03 | 18.0-20.0 | 8.0-11.0 | ||
| TP316 / S31600 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |
| TP316L / S31603 | 0,035 | 1,00 | 2,00 | 0,045 | 0,03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP316Ti / S31635 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0,7> 5x (C + N) |
| TP321 / S32100 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 17.0-19.0 | 9.0-12.0 | 0,7> 5x (C + N) | |
| TP317L / S31703 | 0,035 | 1,00 | 2,00 | 0,045 | 0,03 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 | |
| TP347H / S34709 | 0,04-0,10 | 1,00 | 2,00 | 0,045 | 0,03 | 17.0-19.0 | 9.0-13.0 | ||
| TP309S / S30908 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 22.0-24.0 | 12.0-15.0 | 0,75 | |
| TP310S / S31008 | 0,080 | 1,00 | 2,00 | 0,045 | 0,03 | 24.0-26.0 | 19.0-22.0 | 0,75 |
