TP304L 316l Pipa Stainless Steel / Ss 304 Erw Pipa ASTM A269 ASME SA269
Product Details
| Bahan: | TP304 TP304L TP316 TP316L, 300 Series | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 9.5mm hingga 323.85mm | WT: | 0.8mm hingga 5mm |
| Menyoroti |
pipa las stainless steel,pipa stainless steel 316L |
||
Product Description
ASTM A269 / ASME SA269 ERW Tabung Stainless Steel, TP304L / 316L Untuk Industri Air Panas
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap
year sell more than 5000 tons of stainless steel pipe and tube. tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel. Our client already cover more than 45 Klien kami sudah mencakup lebih dari 45
countries. negara. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
1 . 1. OD ( Outer Diameter ) : OD (Diameter Luar): 9.5mm hingga 323.85mm
2 . 2. WT ( Wall Thickness ) : WT (Ketebalan Dinding): 0.8mm hingga 5mm
3 . 3. Length : Panjangnya : Sesuai dengan kebutuhan pelanggan
4 . 4. Standards : Standar: ASTM A312; ASTM A312; ASTM A269; ASTM A269; ASTM A789; ASTM A789; ASTM A790 etc ASTM A790 dll
5 . 5. Process Method : Metode proses: ERW, EFW dll
Komposisi kimia :
| Bahan | ASTM A269 Komposisi Kimia% Max | ||||||||||
| C | M N | P | S | Si | Cr | Ni | Mo | NB | Nb | Ti | |
| TP304 | 0,08 | 2 | 0,045 | 0,03 | 1 | 18.0-20.0 | 8.0-11.0 | ^ | ^ | ^. | ^ |
| TP304L | 0,035 | 2 | 0,045 | 0,03 | 1 | 18.0-20.0 | 8.0-12.0 | ^ | ^ | ^ | ^ |
| TP316 | 0,08 | 2 | 0,045 | 0,03 | 1 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | ^ | ^ | ^ |
| TP316L | 0,035 D | 2 | 0,045 | 0,03 | 1 | 16.0-18.0 | 10.0-15.0 | 2.00-3.00 | ^ | ^ | ^ |
| TP321 | 0,08 | 2 | 0,045 | 0,03 | 1 | 17.0-19.0 | 9.0-12.0 | ^ | ^ | ^ | 5C -0,70 |
| TP347 | 0,08 | 2 | 0,045 | 0,03 | 1 | 17.0-19.0 | 9.0-12.0 | 10C -1.10 | ^ | ||
Aplikasi:
a) Untuk transportasi fluida dan gas
b) Struktur dan permesinan
c) pipa penukar panas dll
Keuntungan :
a) Permukaan akhir yang unggul
b) Sifat mekanik yang lebih baik
c) Dimensi yang lebih tepat
d) Metode inspeksi sempurna dan peralatan inspeksi
