TP321 321H ERW Ss Stainless Steel Welded Tubin Untuk Teknik Pembuangan Limbah
Product Details
| Bahan: | TP304 TP304L TP316 TP316L | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0,89mm hingga 5mm |
| Menyoroti |
Pipa stainless steel 316L,tabung stainless steel duplex |
||
Product Description
TP321 / 321H ERW Stainless Steel Welded Tube Untuk Teknik Sewage
ASTM A249 Standard:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12.7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2 "(50.8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63.5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3 "(76.2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 4 "(101.6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203.2) | 0,109 "(2,77) | +0.061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
Kelas bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 Dll |
| Standar Eropa | 1.4301, 1.4306, 1.4845, 1.4401, 1.4404, 1.4571, 1.4541, 1.4550, 1.4539, 1.4462 dll. |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
1 . 1. OD ( Outer Diameter ) : OD (Diameter Luar): 15.9mm hingga 406.4mm
2 . 2. WT ( Wall Thickness ) : WT (Ketebalan Dinding): 0,89mm hingga 5mm
3 . 3. Length : Panjangnya : Sesuai dengan kebutuhan pelanggan
4 . 4. Standards : Standar: ASTM A312; ASTM A312; ASTM A269; ASTM A269; ASTM A789; ASTM A789; ASTM A790 ect ASTM A790 dll
5 . 5. Process Method : Metode proses: ERW, EFW dll
| aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan permesinan | |
| c) pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang unggul |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi sempurna dan peralatan inspeksi | |
| Barang Harga: | FOB, CFR, CIF atau sebagai negosiasi |
| Pembayaran: | T / T, LC atau sebagai negosiasi |
