EFW Stainless Steel Bright Annealed Tube Untuk Industri Minyak Bumi OD 15.9mm Sampai 406.4mm
Product Details
| Bahan: | TP304 TP304L TP316 TP316L, 300 Series | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0,89mm hingga 5mm |
| Menyoroti |
pipa las stainless steel,tabung stainless steel duplex |
||
Product Description
EFW Bright Annealed Welded Tabung Stainless Steel Untuk Minyak Industri
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap
year sell more than 5000 tons of stainless steel pipe and tube. tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel. Our client already cover more than 45 Klien kami sudah mencakup lebih dari 45
countries. negara. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
| Barang | Deskripsi | |
| Informasi dasar | Kelas bahan | TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, dll |
| Diameter luar | 15.9mm-406.4mm | |
| Ketebalan dinding | 0.89mm-5mm | |
| Panjangnya | Biasanya tetap 6m panjang, bisa sesuai kebutuhan pelanggan | |
| Standar | ASTM A312; ASTM A312; ASTM A269; ASTM A269; ASTM A789; ASTM A789; ASTM A790 ect. ASTM A790 dll. | |
| Metode proses | ERW, EFW dll | |
Aplikasi:
a) Untuk transportasi fluida dan gas
b) Struktur dan permesinan
c) pipa penukar panas dll
Keuntungan :
a) Permukaan akhir yang unggul
b) Sifat mekanik yang lebih baik
c) Dimensi yang lebih tepat
d) Metode inspeksi sempurna dan peralatan inspeksi
Barang Harga:
FOB, CFR, CIF atau sebagai negosiasi
Pembayaran:
T / T, LC atau sebagai negosiasi
ASTM A249 Standard:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12.7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2 "(50.8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63.5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3 "(76.2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 4 "(101.6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203.2) | 0,109 "(2,77) | +0.061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
