Bahan Kimia Ss Stainless Steel Welded Tubing ASTM A249 ASME SA249 TP304L 1.4306
Product Details
| Bahan: | TP304 TP304L TP316 TP316L | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0,89mm hingga 5mm |
| Menyoroti |
Pipa stainless steel 316L,tabung stainless steel duplex |
||
Product Description
ASTM A249 / ASME SA249 Welded Tube, TP304L / 1.4306 Untuk Area Kimia
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap
year sell more than 5000 tons of stainless steel pipe and tube. tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel. Our client already cover more than 45 Klien kami sudah mencakup lebih dari 45
countries. negara. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
1 . 1. OD ( Outer Diameter ) : OD (Diameter Luar): 15.9mm hingga 406.4mm
2 . 2. WT ( Wall Thickness ) : WT (Ketebalan Dinding): 0,89mm hingga 5mm
3 . 3. Length : Panjangnya : Sesuai dengan kebutuhan pelanggan
4 . 4. Standards : Standar: ASTM A312; ASTM A312; ASTM A269; ASTM A269; ASTM A789; ASTM A789; ASTM A790 etc ASTM A790 dll
5 . 5. Process Method : Metode proses: ERW, EFW dll
ASTM A249 Standard:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12.7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2 "(50.8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63.5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 3 "(76.2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 4 "(101.6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3.18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203.2) | 0,109 "(2,77) | +0.061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
Kelas bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 Dll |
| Standar Eropa | 1.4301, 1.4306, 1.4845, 1.4401, 1.4404, 1.4571, 1.4541, 1.4550, 1.4539, 1.4462 dll. |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
| Aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan permesinan | |
| c) pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang unggul |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi sempurna dan peralatan inspeksi | |
| Barang Harga: | FOB, CFR, CIF atau sebagai negosiasi |
| Pembayaran: | T / T, LC atau sebagai negosiasi |
