TP316 316L Ss Stainless Steel Dilas Tubing Untuk Tujuan Struktur Mekanik
Product Details
| Bahan: | Besi tahan karat | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 9.5mm hingga 406.4mm | WT: | 0.8mm hingga 8mm |
| Menyoroti |
Pipa stainless steel 316L,tabung stainless steel duplex |
||
Product Description
Tabung Las Stainless Steel TP316 / 316L Untuk Tujuan Mekanik Dan Struktur
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap tahunnya
tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel.Klien kami sudah mencakup lebih dari 45
negara.Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
1.OD (Diameter Luar): 9.5mm hingga 406.4mm
2.WT (Ketebalan Dinding): 0.8mm hingga 8mm
3.Panjangnya : Sesuai dengan kebutuhan pelanggan
4.Standar:ASTM A312;ASTM A269;ASTM A789;ASTM A790 dll.
5.Metode proses:ERW, EFW dll
Kelas bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 Dll |
| Standar Eropa | 1.4301, 1.4306, 1.4845, 1.4401, 1.4404, 1.4571, 1.4541, 1.4550, 1.4539, 1.4462 dll. |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
| Aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan permesinan | |
| c) pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang unggul |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi sempurna dan peralatan inspeksi |
ASTM A269 Komposisi Kimia:
| Elemen | 304L (% berat) S30403 | 304 (% berat) S30400 | 316L (wt%) S31603 | 316 (wt%) S31600 |
| (C) Karbon, maks | 0,035 | 0,08 | 0,035 | 0,08 |
| (Mn) Mangan, maks | 2 | 2 | 2 | 2 |
| (P) Fosfor, maks | 0,045 | 0,045 | 0,045 | 0,045 |
| (S) Belerang, maks | 0,03 | 0,03 | 0,03 | 0,03 |
| (Si) Silikon, maks | 1 | 1 | 1 | 1 |
| (Ni) Nikel | 8.0 - 12.0 | 8.0 - 11.0 | 10.0 - 14.0 | 10.0 - 14.0 |
| (Cr) Chromium | 18.0 - 20.0 | 18.0 - 20.0 | 16.0 - 18.0 | 16.0 - 18.0 |
| (Mo) Molybdenum | T / A | T / A | 2.0 - 3.0 | 2.0 - 3.0 |
| (Fe) Besi | Bal. | Bal. | Bal. | Bal. |
| (Cu) Tembaga | T / A | T / A | T / A | T / A |
| (N) Nitrogen | T / A | T / A | T / A | T / A |
