ASTM A210 Carbon Steel Seamless Tube / Pembangkit Listrik Cs Seamless Pipe
Product Details
| Nama Produk: | Pipa Besi Seamless | Aplikasi: | Boiler Pembangkit Listrik |
|---|---|---|---|
| standar: | ANSI, ASTM, GB, DIN, API, JIS, ASME, EN | Kemasan rincian: | Ply-wooden Case / Iron Case / Bundle dengan Cap plastik |
| Menyoroti |
pipa galvanis cs,pipa seamless baja hitam |
||
Product Description
ASTM A210 Ketel Ketel Tembok Baja Karbon Ketebalan Dinding 0.8mm - 15mm
ASTM A210 Tabung Baja Karbon Mulus, Ketebalan Dinding Pipa Baja Boiler 0.8mm - 15mm
Detail Cepat:
Standar: ASTM A210 / A210M (ASME SA210 / SA210M)
Boiler Baja Medium-Carbon Seamless dan Tabung Superheater
Ukuran: (mm)
Dimensi Keluar: 12.7mm-114.3mm
Ketebalan dinding: 0.8mm-15mm
Panjangnya: 5-25mm
Aplikasi:
It is used for boiler and boiler flue tubes. Ini digunakan untuk boiler dan tabung buang boiler. Including safe end, vault and supporting tube and super heater min wall thickness seamless medium--carbon steel tube Termasuk ujung yang aman, lemari besi dan tabung pendukung dan ketebalan dinding min pemanas super mulus tabung baja karbon sedang
Persyaratan Kimia:
| STANDAR | KELAS | KOMPOSISI KIMIA | |||||||||
| C | Si | M N | P | S | Cr | Mo | Cu | Ni | V | ||
| ASTM A210 | A-1 | ≤0,27 | ≥0,10 | ≤0,93 | ≤0.035 | ≤0.035 | |||||
| C | ≤0,35 | ≥0,10 | 0.291.06 | ≤0.035 | ≤0.035 | ||||||
Peralatan mekanis:
| Kelas | Kekuatan luluh (mpa) | Kekuatan Tarik (Mpa) | Perpanjangan (%) |
| A-1 | ≥255 | ≥415 | 30 |
| C | ≥275 | ≥485 | 30 |
Toleransi Ketebalan Dinding
ASME SA-210 |
OD | WT | Toleransi WT |
| <= 38.1 | / | +20%, - 0% | |
| > 38.1 | / | +20%, - 0% |
Deskripsi:
ASTM A210 is the standard covers seamless medium-carbon steel boiler and superheater tubes.ASTM A210 also covers minimum-wall-thickness, tubing sizes, boiler flues including safe ends, arch and stay tubes. ASTM A210 adalah standar yang mencakup boiler baja karbon menengah dan tabung superheater mulus .ASTM A210 juga mencakup ketebalan dinding minimum, ukuran tubing, cerobong boiler termasuk ujung yang aman, lengkungan dan tabung tetap. ASTM A210 provides tensile and hardness properties but only applicable to certain size limitations. ASTM A210 memberikan sifat tarik dan kekerasan tetapi hanya berlaku untuk batasan ukuran tertentu. Material manufacturing shall be killed. Pembuatan material harus dibunuh. Tubes shall be made by seamless process, marked as either hot-finished or cold-finished. Tabung harus dibuat dengan proses yang mulus, ditandai sebagai panas-selesai atau dingin-selesai. Surface condition shall be specifically stated in the order. Kondisi permukaan harus secara khusus dinyatakan dalam urutan. Chemical composition shall conform to the requirements. Komposisi kimia harus sesuai dengan persyaratan. Elemental composition other than listed here shall not be permitted. Komposisi unsur selain yang tercantum di sini tidak diizinkan. Tension test, flattening test, flaring test, hardness test, hydrostatic or nondestructive electric test shall be made on specimens. Uji tegangan, uji perataan, uji nyala, uji kekerasan, uji listrik hidrostatik atau tidak rusak harus dilakukan pada spesimen. Superheater tubes shall be formed without defects and shall withstand expansion, beading, forging, welding, and bending. Tabung superheater harus dibentuk tanpa cacat dan harus tahan ekspansi, manik-manik, penempaan, pengelasan, dan tekukan.
ASTM A210 / A210M Tabung Boiler Baja Medium-Carbon Seamless
Boiler Baja Medium-Carbon Seamless dan Tabung Superheater
Baja Grde:
Grade A1; Kelas A1; Grade C Kelas C
Pengepakan:
Lukisan miring / hitam / tutup plastik / dalam bundel / strip baja / perlindungan kayu
Inspeksi dan Tes:
Inspeksi Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Hasil, Pemanjangan, Pembakaran, Perataan, Bending, Kekerasan, Uji Impak), Uji Permukaan dan Dimensi, Uji Nodestructive, Uji Hidrostatik.
Pengobatan permukaan:
Celupkan minyak, Pernis, Pasifasiasi, Fosfat, Shot Blasting
Menandai:
Seperti yang diminta.
Kondisi pengiriman:
Anil, Normalisasi, Normalisasi dan Marah
