Hot Rolled Steel Plate SAE 1045 4 - 120mm CK 45 Untuk Suku Cadang Mesin Umum
Product Details
| Permukaan: | Plat Baja Karbon Gulung Panas | Bahan: | SAE 1045 |
|---|---|---|---|
| Ketebalan: | 5mm-600mm | Lebar: | 200mm-2500mm |
| Berat bundel: | 3MT-6MT | Panjangnya: | 100mm hingga 12000mm |
| Menyoroti |
plat astm a36,plat canai dingin |
||
Product Description
Hot rolled SAE 1045 4-120mm pelat baja CK 45 carben untuk suku cadang mesin umum, pertambangan, pengilangan
Ukuran
Ketebalan: 5-600mm
Lebar: 200-2500mm
Durasi: 100-12000mm
Aplikasi
- Baja karbon AISI 1045 Digunakan untuk membuat die-board, suku cadang mesin umum.
- Bagian komponen untuk kendaraan, poros, busing, poros engkol, batang penghubung dan suku cadang untuk industri pembuatan mesin dan baja untuk kapak, pisau, palu dll.
Kelas Setara
| GB | KERIUHAN | NF | SS | JIS | BS | AISI | ISO |
| 45 # | 1.0503 | C45 | 1650 | S45C | IC45 / 080A47 | 1045 | C45E4 |
Analisis kimia
| TIDAK. | C | M N | Si | Cr | Cu | Ni | P | S | ||||||||
| Aisi 1045 | 0,43 ~ 0,50 | 0,6 ~ 0,9 | 0,10 ~ 0,60 | ≤0,40 | ≤ 0,50 | |||||||||||
| DIN1.0503 | 0.42 ~ 0.48 | 0,6 ~ 0,9 | 0,15 ~ 0,35 | ≤0,15 | ≤0.3 | ≤0.2 | ||||||||||
| JIS S45C | 0,42 ~ 0,50 | 0,5 ~ 0,8 | ≤0,40 | ≤0,40 | ≤ 0,4 | |||||||||||
| GB45 | 0,42 ~ 0,50 | 0,5 ~ 0,8 | 0.17 ~ 0.37 | ≤0,25 | ≤0,25 | ≤0.3 | ≤0.035 | ≤0.035 | ||||||||
Peralatan mekanis
| SEBUAHnnealing | Penempaan | Tempering dan Hardening | Normalisasi | |||||||||||||
|
Anil subkritis: 650 ~ 700 Pelunakan isotermal: 820 ~ 860 |
1100 ~ 850 |
Tempering: 550 ~ 660 Pengerasan: 820 ~ 860 air |
840 ~ 880 | |||||||||||||
Perawatan panas
Anil lembut: panas ke 550-650 ° C, dinginkan perlahan.
Hardness after annealing: Max. Kekerasan setelah anil: Maks. 269HB 269HB
Pengerasan: 820 - 870 ° C
Suhu normalisasi: 840-870 ° C
Product Highlights
Hot rolled SAE 1045 4-120mm pelat baja CK 45 carben untuk suku cadang mesin umum, pertambangan, pengilangan Ukuran Ketebalan: 5-600mm Lebar: 200-2500mm Durasi: 100-12000mm Aplikasi - Baja karbon AISI 1045 Digunakan untuk membuat die-board, suku cadang mesin umum. - Bagian komponen untuk kendaraan, ...
