SHot Rolled Plat Baja Gulungan Dingin APH440 Setara dengan JIS G3113 Automobile Struktural
Product Details
| Permukaan: | Hot Rolled & Cold Rolled | Bahan: | SAPH440 |
|---|---|---|---|
| Ketebalan: | 0,5mm-4mm | Lebar: | 100mm-1500mm |
| Panjangnya: | 100mm hingga 12000mm | Aplikasi: | Mobil, Boiler, Mesin |
| Menyoroti |
plat astm a36,plat canai dingin |
||
Product Description
SAPH440 EquivalentJIS G3113 Struktural Automobile Hot Rolled Dan Cold Rolled SAPH440 Steel Sheet dan Plat
APA ITU SAPH440 STEEL?
SAPH440 steel is structural hot-rolled steel in the form of plates, sheets & strips for automobile structural applications. Baja SAPH440 adalah baja hot-rolled struktural dalam bentuk pelat, lembaran & strip untuk aplikasi struktural mobil. SAPH440 is a material grade and designation defined in SAPH440 adalah kelas material dan penunjukan yang didefinisikan dalam JIS G 3113 standard. G 3113 standar. JIS G 3113 is a Japanese material standard for Hot-Rolled steel plates, sheets, strips for automobile structural usage. JIS G 3113 adalah standar bahan Jepang untuk pelat baja, lembaran, strip panas untuk penggunaan struktural mobil. The structural quality hot rolled SAPH440 steel is more reliable in its tensile strength than Baja struktural kualitas panas digulung SAPH440 lebih dapat diandalkan dalam kekuatan tarik daripada Baja SAPH400. . It can be used in automotive applications where more strength is needed & the material does not fail under exceeding loading. Itu dapat digunakan dalam aplikasi otomotif di mana kekuatan lebih dibutuhkan & bahan tidak gagal di bawah pemuatan melebihi.
APA ITU JIS G 3113?
BENTUK SAPH440
| Simbol | Komposisi kimia | |
|
P
maks
|
S
maks
|
|
| SAPH310,SAPH370,SAPH400,SAPH440 | 0,040 | 0,040 |
| Simbol | Perpanjangan (arah putaran)% | Ditekuk | ||||||||
| NO.5 benda uji | Benda uji No.1A | |||||||||
| ≥1,6 <2mm | ≥2.0 <2.5mm |
≥2.5
<3.15mm
|
≥3.15
<4.0mm
|
≥4.0
<6.3mm
|
≥6.3mm | Membungkuk sudut | Di dalam Radius | Benda uji | ||
| <2.0mm |
≥2.0
mm
|
|||||||||
| SAPH310 | 33 | 34 | 36 | 38 | 40 | 26 | 180 ° | Datar sendiri | Ketebalan x 1.0 | No.3 melintang ke arah rolling |
| SAPH370 | 32 | 33 | 35 | 36 | 37 | 25 | 180 ° | -Ketebalan x 0,5 | Ketebalan x 1.0 | |
| SAPH400 | 31 | 32 | 34 | 35 | 36 | 24 | 180 ° | Ketebalan x 1.0 | -Ketebalan x 1.0 | |
| SAPH440 | 29 | 30 | 32 | 33 | 34 | 22 | 180 ° | Ketebalan x 1.0 | Ketebalan x 1,5 | |
| Simbol | Kekuatan tarik N / mm2 min | Titik hasil N / mm2 | ||
| <6 | ≥6 <8mm | ≥8 <14mm | ||
| SAPH310 | 310 | 195 | 195 | 175 |
| SAPH370 | 370 | 225 | 225 | 215 |
| SAPH400 | 400 | 255 | 235 | 235 |
| SAPH440 | 440 | 305 | 295 |
275
|
KARAKTERISTIK DIMENSI DARI BAJA SAPH440
The applicable thickness for this SAPH440 material as defined in the JIS 3113 starts from 2 mm to 14 mm. Ketebalan yang berlaku untuk bahan SAPH440 ini sebagaimana didefinisikan dalam JIS 3113 mulai dari 2 mm hingga 14 mm. However, the width of SAPH440 material ranges to 950 to 2000 mm. Namun, lebar material SAPH440 berkisar antara 950 hingga 2000 mm.
KOMPOSISI KIMIA BAJA SAPH440
JIS G 3113 mendefinisikan komposisi kimia baja SAPH440 seperti di bawah ini:
- Karbon (C) tidak diidentifikasi dalam standar.
- Mangan (Mn) tidak diidentifikasi dalam standar.
- Persentase maksimum Fosfor (P) adalah 0,040 persen.
- Persentase maksimum Belerang (S) adalah 0,040 persen.
Sisa adalah persentase besi (Fe) dan dengan beberapa pengotor yang dapat diabaikan.
SIFAT MEKANIK BAJA SAPH440
- Kekuatan tarik Baja SAPH440 dinyatakan dalam Newton per milimeter dan harus setidaknya 440 N / mm2 (MPa).
- Kekuatan luluh minimum 275 hingga minimum 305 N / mm2 (MPa) tergantung pada ketebalan.
- The elongation property of SAPH440 steel varies with the ranges of thickness. Properti perpanjangan baja SAPH440 bervariasi dengan rentang ketebalan. The minimum percentage ranges for elongation is 29 to 34 minimum. Rentang persentase minimum untuk perpanjangan adalah 29 hingga 34 minimum. Only over 6.5 mm thickness requires 22 minimum percentage elongations. Ketebalan hanya lebih dari 6,5 mm membutuhkan 22 perpanjangan persentase minimum. Higher thickness gauges usually show higher elongation than lower gauges. Alat ukur ketebalan yang lebih tinggi biasanya menunjukkan perpanjangan yang lebih tinggi daripada alat ukur yang lebih rendah.
