Pelat Lembaran Logam Baja Paduan Boiler Q235 Q345 B C D E AISI ASTM Standar
Product Details
| Nama Produk: | Plat Baja Paduan | standar: | AISI, ASTM, BS, DIN, JIS |
|---|---|---|---|
| Aplikasi: | Piring Kapal | Ketenangan: | 6 - 80mm |
| Menyoroti |
pelat bejana tekan,pelat ketel |
||
Product Description
Q235 Q345 BCDE Cold Rolled / Hot Rolled Alloy Steel Plate untuk Aplikasi Plat Kapal
Q345B / C / D / E
1) Standar: GB
2) Ketebalan: 6-80mm
3) Lebar: 1600-3200mm
4) Panjang: 6000-14000mm
5)) Kualitas tinggi harga rendah
Kemakmuran Mekanis
| ketebalan | suhu uji (° c) | Pemanjangan(%) | bukti stres (Mpa) | Tarik tarik (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470-630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470-630 |
| Q345C | 16-35 | 0 | 22 | ≥325 | 470-630 |
| Q345D | 35-50 | -20 | 22 | ≥295 | 470-630 |
| Q345E | 50-100 | -40 | 22 | ≥275 | 470-630 |
Produk kita
| Seri Produk | Standar Eksekutif | Kelas | Kelas | Ketebalan (mm) |
Pengiriman Negara |
| Baja struktural paduan rendah | GB / T 1591-2008GB / T 3274-2007 | Q345 | A, B | 6 ~ 150 | AR |
| CD | 6 ~ 150 | CR | |||
| E | 6 ~ 150 | TMCP | |||
| Q390 | A, B, C, D, E | 6 ~ 150 | CR | ||
| Q420 | 6 ~ 150 | TMCP | |||
| Q500 | 6 ~ 100 | TMCP | |||
| Q550 | 6 ~ 100 | ||||
| Q620 | 6 ~ 80 | ||||
| Q690 | 6 ~ 80 | ||||
| GB / T 28410-2012 | Q235FT | B, C, D, E | 5 ~ 150 | AR, CR | |
| Q275FT | C, D, E, F | 5 ~ 150 | AR, CR | ||
| Q345FT | C, D, E, F | 5 ~ 150 | AR, CR | ||
| Q420FT | C, D, E, F | 5 ~ 150 | AR, CR | ||
| Q460FT | C, D, E, F | 5 ~ 150 | AR, CR | ||
| EN 10025-4: 2004 | S275M / ML | - | 6 ~ 60 | TMCP | |
| S355M / ML | |||||
| S420M / ML | |||||
| S460M / ML | |||||
| JIS G3106: 2008 |
SM400 SM490 |
A, B, C | 6 ~ 150 | AR | |
| A, B, C | 6 ~ 150 | CR | |||
| YA, YB | |||||
| SM520 | B, C | 6 ~ 80 | TMCP | ||
| SM570 | 6 ~ 80 | ||||
| ASTM A572 / A572M-12 | Gr42 | - | 6 ~ 150 | AR | |
| Gr50 | - | 6 ~ 100 | CR | ||
| Gr55 | - | 6 ~ 100 | |||
| Gr60 | - | 6 ~ 80 |
TMCP |
Konstituen Kimia (WT%)
| C | Si | M N | P | S | V | Nb | Al | Ti | |
| Q345A | ≤0.20 | ≤0,55 | 1,00-1,60 | ≤0,045 | ≤0,045 | 0,02-0,15 | 0,015-0.060 | - | 0,02-0,20 |
| Q345B | ≤0.20 | ≤0,55 | 1,00-1,60 | ≤0,040 | ≤0,040 | 0,02-0,15 | 0,015-0.060 | - | 0,02-0,20 |
| Q345C | ≤0.20 | ≤0,55 | 1,00-1,60 | ≤0.035 | ≤0.035 | 0,02-0,15 | 0,015-0.060 | ≥0.015 | 0,02-0,20 |
| Q345D | ≤0,18 | ≤0,55 | 1,00-1,60 | ≤0.030 | ≤0.030 | 0,02-0,15 | 0,015-0.060 | ≥0.015 | 0,02-0,20 |
| Q345E | ≤0,18 | ≤0,55 | 1,00-1,60 | ≤0.025 | ≤0.025 | 0,02-0,15 | 0,015-0.060 | ≥0.015 | 0,02-0,20 |
Product Highlights
Q235 Q345 BCDE Cold Rolled / Hot Rolled Alloy Steel Plate untuk Aplikasi Plat Kapal Q345B / C / D / E 1) Standar: GB 2) Ketebalan: 6-80mm 3) Lebar: 1600-3200mm 4) Panjang: 6000-14000mm 5)) Kualitas tinggi harga rendah Kemakmuran Mekanis ketebalan suhu uji (° c) Pemanjangan(%) bukti stres (Mpa) Tarik ...
