Bright Annealed Tube ASTM A213 ASME SA213-17 TP304L 60.3x4.5 M / W X12820MM
Product Details
| Kualitas baja: | TP304 / 304L / 304H, TP310S / 310H, TP316L / 316H / 316Ti, TP317 / 317L, TP321 / 321H, TP347 / 347H | Aplikasi: | Pengolahan gas buang, instrumen dan peralatan presisi, produk elektronik dan elektronik, pemintalan, |
|---|---|---|---|
| Selesai: | Solusi Annealed & Acar / Bright Annealed | Bentuk: | Lurus & Coil |
| OD: | 1/4 "= 6.35MM, 3/8" = 9.52MM, 1/2 "= 12.7MM, 5/8" = 15.88, 3/4 "= 19.05mm, | Panjangnya: | 12ft (3657.6), 15ft (4572), 16ft (4876.8), 6m, 20ft (6096), 24ft (7315.2), 30ft (9144) |
| Menyoroti |
pipa pengawetan stainless steel,pipa tembaga anil |
||
Product Description
Pipa Stainless Steel Annealing Cerah ASTM A213 / ASME SA213-17 TP304L 60.3x4.5 (M / W) X12820MM Untuk Penukar Panas.
Ciri: Dengan cold press (terutama cold rolling), gas melindungi perlakuan panas, dengan presisi tinggi:
ID: Ra≤0.4μm, OD: Ra≤0.8μm ； Terutama untuk instrumen presisi, sistem tekanan hidrolik, gas buang
sistem dll.
Standar: ASTM / ASME A / SA213, A / SA269, DIN17458 / 17457, EN10216-5 / 10217-7.Setelah negosiasi, kita bisa
memasok pipa dengan kebutuhan pelanggan.
Kelas bahan: TP304, TP304L, TP316, TP316L, TP316Ti, dan TP321 dll juga tersedia DIN / EN,
kelas lain juga dapat diberikan setelah berkonsultasi dengan pelanggan.
Kisaran Ukuran: Pipa Baja Stainless (OD: Φ6mm-Φ76mm WT: 0.15mm-4.0mm, Panjang: Maks. 500M / pc)
| Standar | EN10305 | |||||
| Kelas bahan | 1.4301, 1.4306, 1.4404, 1.4539 | |||||
| Diameter luar | 0.6mm - 76mm | |||||
| Ketebalan | 0,15mm - 4mm | |||||
| Panjangnya | 2440mm, 3050mm, 5800mm, 6000mm, 6100mm atau sebagai permintaan pelanggan | |||||
|
Toleransi |
a) Diameter Luar: +/- 0,02mm | |||||
| b) Ketebalan: +/- 5% ATAU sebagai permintaan pelanggan | ||||||
| c) Panjang: +/- 10mm | ||||||
| Permukaan |
Satin / Garis Rambut: 180 #, 320 # Polandia: 400 #, 600 #, 800 # atau Permukaan cermin |
|||||
| Keuntungan | Permukaan bagian dalam halus tanpa minyak dan oli, Toleransi presisi tinggi | |||||
| PENGEPAKAN | Kantong plastik / anyaman kemasan (silakan kirim detail pengepakan kepada kami jika Anda memiliki persyaratan lain) | |||||
Aplikasi:
Pipa baja seamless dan dilas dengan baja anil terang banyak digunakan dalam pembuatan produk militer, semikonduktor, obat biologis, instrumen presisi dan meter, komponen hidrolik dan banyak produk industri lainnya.
Product Highlights
Pipa Stainless Steel Annealing Cerah ASTM A213 / ASME SA213-17 TP304L 60.3x4.5 (M / W) X12820MM Untuk Penukar Panas. Ciri: Dengan cold press (terutama cold rolling), gas melindungi perlakuan panas, dengan presisi tinggi: ID: Ra≤0.4μm, OD: Ra≤0.8μm ； Terutama untuk instrumen presisi, sistem tekanan ...
