Pipa Stainless Steel Las ASME SA249 ASTM A249 TP304 TP316L TP321 Ujung Polos
Product Details
| Kualitas baja: | TP304 / 304L, TP316 / 316L, TP321 / 321H, TP347 / 347H, TP310S, TP904L | Aplikasi: | Boiler Baja Austenitik, Superheater, Penukar panas, Kondensor |
|---|---|---|---|
| standar: | ASTM A249 / ASME SA249 | Bentuk: | Lurus & U menekuk |
| Menyoroti |
pipa pengawetan stainless steel,pipa tembaga anil |
||
Product Description
ASME SA249 / ASTM A249 TP304 TP316L TP321 Stainless Steel Welded Pipe Bright Annealed Plain End
ASTM A249 / A249M: Spesifikasi Standar untuk Welded Austenitic Steel Boiler, Superheater
Penukar panas, dan kondensor
Standar Lain: DIN 17456, DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463, ...
Kelas bahan:
| Standar Amerika | Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316L, TP316L, TP316H, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301.1.4307.1.4948.1.4541.1.4878.1.4550.1.4401.1.4404.1.4571.1.4438, 1.4841.1.4845.1.4539.1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т, 08Х17Н15Т, 08Х17Н15AJ, 21, 22, 22, 22, 22, 19, 19, 19, 19, 07, 08, 08, 08, 08, 09, 08, 08, 08, 08, 08, 08, 08 |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Pipa Boiler | 6.00mm hingga 630mm | 0,5mm hingga 52mm |
Finishing Akhir
Solusi Annealed & Acar / Bright Annealed.
Jenis Pipa:
Bengkok & Lurus.
Beberapa tes kualitas yang kami lakukan meliputi:
| Uji Korosi | Dilakukan hanya ketika diminta secara khusus oleh klien |
| Analisis kimia | Tes dilakukan sesuai standar kualitas yang disyaratkan |
| Pengujian Merusak / Mekanis | Tarik |Kekerasan |Meratakan |Flare |Penghubung jalur pipa |
| Reverse-bend dan Re.tes datar | Dilakukan dengan kepatuhan penuh dengan standar & norma ASTM A-450 dan A-530 yang relevan, yang memastikan ekspansi, pengelasan & penggunaan bebas masalah di ujung pelanggan |
| Pengujian Arus Eddy | Dilakukan untuk mendeteksi homogenitas di bawah permukaan dengan menggunakan Digital Flaw-mark Testing System |
| Pengujian Hidrostatik | Pengujian Hidrostatis 100% dilakukan sesuai dengan norma ASTM-A 450 untuk memeriksa kebocoran tabung, dan tekanan terbesar kami dapat mendukung 20Mpa / 7s. |
| Uji Tekanan Udara Di Bawah | Untuk memeriksa bukti kebocoran udara |
| Inspeksi visual | Setelah pasif, setiap panjang tabung & pipa harus melalui pemeriksaan visual menyeluruh oleh staf terlatih untuk mendeteksi kekurangan permukaan & ketidaksempurnaan lainnya |
Pengujian Tambahan: Selain pengujian yang disebutkan di atas, kami juga melakukan pengujian tambahan pada produk manufaktur.Tes yang dilakukan di bawah ini meliputi:
|
|
|
