Annealed Alloy Steel Seamless Pipe Untuk Boiler Superheater ASTM A213 ASME SA213 T1 T11 T12
Product Details
| Kualitas baja: | T1, T11, T12 | Aplikasi: | Boiler, penukar panas, pemanas super & pemanas ulang |
|---|---|---|---|
| standar: | ASTM A213 / ASME SA213 | Permukaan: | Anil |
| Inspeksi pihak ketiga: | BV, SGS | Ukuran: | 3/4 "(19.05), 1" (25.4), 1-1 / 4 "(31.75), 1-1 / 2" (38.1), 2 "(50.8), 2-1 |
| Menyoroti |
tabung anil terang,pipa tembaga anil |
||
Product Description
Anil, Pipa Baja Paduan Seamless untuk Boiler, Superheater, ASTM A213 / ASME SA213 T1 T11 T12
Teknologi Energi Hua Dongcan supply huge qty of Cr-Mo Alloy seamless pipe and tube , and export more than 30 countries . dapat memasok pipa dan tabung mulus Cr-Mo Alloy dalam jumlah besar, dan mengekspor lebih dari 30 negara. Our alloy seamless tube be width used in boiler and heating. Tabung seamless alloy kami berukuran lebar digunakan dalam boiler dan pemanas.
Teknologi Energi Hua Dongcontrols the entire manufacturing process from raw material to finished products, Inspection points are localed in the manufacturing process to ensure all products meet all requirements. mengontrol seluruh proses manufaktur dari bahan baku hingga produk jadi, titik inspeksi dilokalkan dalam proses manufaktur untuk memastikan semua produk memenuhi semua persyaratan. In such quality control system, faults are detected at the earliest possible stage of the production process in order to eliminate the risk of rejection at final inspection. Dalam sistem kontrol kualitas seperti itu, kesalahan terdeteksi pada tahap sedini mungkin dari proses produksi untuk menghilangkan risiko penolakan pada inspeksi akhir. We have made continuous efforts to reduce the problem throughout total quality assurance system including traceability control, HUA DONG not only inspects by ourself , also through TPI like BV, SGS, DNV, ABS, MOODY, IBR, so that today the quality of our productsis clearly recognized by our client. Kami telah melakukan upaya terus menerus untuk mengurangi masalah di seluruh sistem jaminan kualitas total termasuk kontrol penelusuran, HUA DONG tidak hanya memeriksa sendiri, juga melalui TPI seperti BV, SGS, DNV, ABS, MOODY, IBR, sehingga saat ini kualitas produk kami diakui dengan jelas oleh klien kami.
| Karbon | Chromiun | Suhu rendah | Besi tahan karat | Dupleks | Tembaga & perunggu | Titanium | Ni-Alloy | ||
| SA178-A | SA213-T1 | SA333-Gr.1 | SA213 | TP316L | A789-S31803 | SB111-C70600 | SB338-GR.1 | SB163 | No.200 |
| SA178-C | SA213-T11 | SA333-Gr.3 | SA249 | TP316H | A789-S32205 | SB111-C71500 | SB338-GR.2 | SB167 | NO2201 |
| SA179 | SA213-T12 | SA333-Gr.6 | SA268 | TP316Ti | A789-S32750 | SB111-C71640 | SB338-GR.5 | SB444 | NO8020 |
| SA192 | SA213-T22 | SA333-Gr.7 | SA269 | TP316LN | A789-S32760 | SB111-C68700 | SB338-GR.7 | SB514 | NO6022 |
| SA209-T1 | SA213-T5 | SA333-Gr.8 | SA376 | TP321 | A789-S32707 | SB111-C44300 | SB338-GR.9 | SB619 | N10276 |
| SA209-T1a | SA213-T9 | SA334-Gr.1 | TP304 | TP321H | A789-S32304 | SB338-GR.12 | SB622 | NO4400 | |
| SA209-T1b | SA213-T91 | SA334-Gr.3 | TP304L | TP347 | A789-S31500 | SB626 | NO6600 | ||
| SA210-A1 | SA334-Gr.6 | TP304H | TP347H | S31254 | SB674 | NO6601 | |||
| SA210-C | SA334-Gr.7 | TP304N | TP405 | 254MA | SB677 | NO6625 | |||
| SA214 | SA334-Gr.8 | TP310H | TP409 | 17-4PH | SB704 | NO690 | |||
| SA513 MT 1010 | TP310S | TP410 | 17-7PH | SB705 | NO8800 | ||||
| SA513 MT 1015 | TP309S | TP430 | 15-7PH | N1001 | NO8810 | ||||
| SA513 MT 1020 | TP317 | TP439 | N10665 | NO8811 | |||||
| TP317L | TP444 | N10675 | NO8825 | ||||||
| TP348 | TP446 | TP904L | |||||||
| TP347HFG | |||||||||
| Ukuran Pipa untuk Penukar Panas & Kondensor & Boiler | |||||||||
| Diameter luar | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Ketebalan dinding mm | |||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inci | Berat kg / m | |||||||
| 6.35 | 1/4 | 0,081 | 0,109 | 0,133 | 0,174 | 0,212 | |||
| 9.53 | 3/8 | 0,126 | 0,157 | 0,193 | 0,257 | 0,356 | 0,429 | ||
| 12.7 | 1/2 | 0,214 | 0,263 | 0,356 | 0,457 | 0,612 | 0,754 | ||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0,995 | ||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0,667 | 0,832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2.729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
ASTM A213 / ASME SA213 T2, T11, T12, T22, T91, T92 Komposisi Kimia dan Sifat Mekanik
| Kelas | Komposisi kimia% | ||||||||
| C | Si | M N | P, S Max | Cr | Mo | Ni Max | V | Al Max | |
| T2 | 0,10 ~ 0,20 | 0,10 ~ 0,30 | 0,30 ~ 0,61 | 0,025 | 0,50 ~ 0,81 | 0.44 ~ 0.65 | - | - | - |
| T11 | 0,05 ~ 0,15 | 0,50 ~ 1,00 | 0,30 ~ 0,60 | 0,025 | 1,00 ~ 1,50 | 0.44 ~ 0.65 | - | - | - |
| T12 | 0,05 ~ 0,15 | Max 0,5 | 0,30 ~ 0,61 | 0,025 | 0,80 ~ 1,25 | 0.44 ~ 0.65 | - | - | - |
| T22 | 0,05 ~ 0,15 | Max 0,5 | 0,30 ~ 0,60 | 0,025 | 1.90 ~ 2.60 | 0.87 ~ 1.13 | - | - | - |
| T91 | 0,07 ~ 0,14 | 0,20 ~ 0,50 | 0,30 ~ 0,60 | 0,02 | 8.0 ~ 9.5 | 0.85 ~ 1.05 | 0,4 | 0,18 ~ 0,25 | 0,015 |
| T92 | 0,07 ~ 0,13 | Max 0,5 | 0,30 ~ 0,60 | 0,02 | 8.5 ~ 9.5 | 0,30 ~ 0,60 | 0,4 | 0,15 ~ 0,25 | 0,015 |
| Kelas | Komposisi kimia% | Peralatan mekanis | |||||||
| W | B | Nb | N | T. S | Y. P | Pemanjangan | Kekerasan | ||
| T2 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T11 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T12 | - | - | - | - | ≥ 415MPa | ≥ 220MPa | ≥ 30% | 163HBW (85HRB) | |
| T22 | - | - | - | - | ≥ 415MPa | ≥ 205MPa | ≥ 30% | 163HBW (85HRB) | |
| T91 | - | - | 0,06 ~ 0,10 | 0,03 ~ 0,07 | ≥ 585MPa | ≥ 415MPa | ≥ 20% | 250HBW (25HRB) | |
| T92 | 1.50 ~ 2.00 | 0,001 ~ 0,006 | 0,04 ~ 0,09 | 0,03 ~ 0,07 | ≥ 620MPa | ≥ 440MPa | ≥ 20% | 250HBW (25HRB) | |
ASTM A213 / ASME SA213 T2, T11, T12, T22, T91, T92 Toleransi
| Diameter luar | Toleransi OD | Toleransi WT | Toleransi Ovalitas | Toleransi Panjang Potong |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15% | - | + 3, 18 mm, - 0 mm |
| 12, 7 mm <OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10% | maks, 1, 65 mm | + 3, 18 mm, - 0 mm |
| 38, 1 mm <OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10% | maks, 2, 41 mm | + 4, 76 mm, - 0 mm |
- SA213 T11 Alloy Steel Pipe digunakan dalam Industri Petrokimia
- SA213 T11 Alloy Steel Pipa digunakan dalam Industri Kimia
- SA213 T11 Alloy Steel Pipa digunakan dalam Industri Pembangkit Listrik Tenaga Nuklir
- SA213 T11 Alloy Steel Pipa digunakan dalam Industri Minyak dan Gas
- SA213 T11 Alloy Steel Pipa digunakan dalam Penelitian & Pengembangan
- SA213 T11 Alloy Steel Pipa digunakan dalam Proyek Mega & Industri Pertahanan & Pengembangan
- SA213 T11 Alloy Steel Pipa digunakan dalam Pulp & Paper Indusry
