ASTM A213 ASME SA213 Alloy Pipa Stainless Steel Seamless Untuk Penukar Panas Boiler
Product Details
| Kualitas baja: | ASTM A213 / ASME SA213 T11, T22, T1, T23, T5, T9.T91, T92 | Permukaan: | Bright Annealed |
|---|---|---|---|
| Standar: | ASTM A213 / SMES SA213 | Aplikasi: | Boiler & penukar panas, Superheater, Reheater, Air preheater, Economizer |
| OD: | 1/4 '' TO 5 '' | NDT: | ET / UT / HT |
| Menyoroti |
asme pipa mulus,erw tabung ketel |
||
Product Description
ASTM A213 / ASME SA213 T9 T91 T92 Tabung Baja Paduan Seamless untuk Boiler, Superheater, aplikasi penukar panas
Teknologi Energi Hua Dongdapat menyediakan qty besar Cr-Mo Alloy pipa dan tabung mulus, dan mengekspor lebih dari 30 negara.Tabung mulus paduan kami lebar digunakan dalam boiler dan pemanas.
Teknologi Energi Hua Dongmengontrol seluruh proses manufaktur dari bahan mentah hingga produk jadi, Titik inspeksi ditempatkan dalam proses manufaktur untuk memastikan semua produk memenuhi semua persyaratan.Dalam sistem kontrol kualitas tersebut, kesalahan dideteksi pada tahap proses produksi sedini mungkin untuk menghilangkan risiko penolakan pada pemeriksaan akhir.Kami telah melakukan upaya berkelanjutan untuk mengurangi masalah di seluruh sistem jaminan kualitas total termasuk kontrol ketertelusuran,Teknologi Energi Hua Dongtidak hanya memeriksa sendiri, juga melalui TPI seperti BV, SGS, DNV, ABS, MOODY, IBR, sehingga saat ini kualitas produk kami jelas diakui oleh klien kami.
| Karbon | kromiun | Suhu rendah | Besi tahan karat | Rangkap | Tembaga & Perunggu | Titanium | Paduan Ni | ||
| SA178-A | SA213-T1 | SA333-Gr.1 | SA213 | TP316L | A789-S31803 | SB111-C70600 | SB338-GR.1 | SB163 | NO2200 |
| SA178-C | SA213-T11 | SA333-Gr.3 | SA249 | TP316H | A789-S32205 | SB111-C71500 | SB338-GR.2 | SB167 | NO2201 |
| SA179 | SA213-T12 | SA333-Gr.6 | SA268 | TP316Ti | A789-S32750 | SB111-C71640 | SB338-GR.5 | SB444 | NO8020 |
| SA192 | SA213-T22 | SA333-Gr.7 | SA269 | TP316LN | A789-S32760 | SB111-C68700 | SB338-GR.7 | SB514 | NO6022 |
| SA209-T1 | SA213-T5 | SA333-Gr.8 | SA376 | TP321 | A789-S32707 | SB111-C44300 | SB338-GR.9 | SB619 | N10276 |
| SA209-T1a | SA213-T9 | SA334-Gr.1 | TP304 | TP321H | A789-S32304 | SB338-GR.12 | SB622 | NO4400 | |
| SA209-T1b | SA213-T91 | SA334-Gr.3 | TP304L | TP347 | A789-S31500 | SB626 | NO6600 | ||
| SA210-A1 | SA334-Gr.6 | TP304H | TP347H | S31254 | SB674 | NO6601 | |||
| SA210-C | SA334-Gr.7 | TP304N | TP405 | 254MA | SB677 | NO6625 | |||
| SA214 | SA334-Gr.8 | TP310H | TP409 | 17-4PH | SB704 | NO690 | |||
| SA513 MT 1010 | TP310S | TP410 | 17-7PH | SB705 | NO8800 | ||||
| SA513 MT 1015 | TP309S | TP430 | 15-7PH | N1001 | NO8810 | ||||
| SA513 MT 1020 | TP317 | TP439 | N10665 | NO8811 | |||||
| TP317L | TP444 | N10675 | NO8825 | ||||||
| TP348 | TP446 | TP904L | |||||||
| TP347HFG | |||||||||
| Ukuran Tabung untuk Penukar Panas & Kondensor & Boiler | |||||||||
| Diameter luar | BWG | ||||||||
| 25 | 22 | 20 | 18 | 16 | 14 | 12 | 10 | ||
| Tebal Dinding mm | |||||||||
| 0,508 | 0,71 | 0,89 | 1.24 | 1.65 | 2.11 | 2.77 | 3.40 | ||
| mm | inci | Berat kg/m | |||||||
| 6.35 | 1/4 | 0,081 | 0.109 | 0,133 | 0,174 | 0.212 | |||
| 9.53 | 3/8 | 0,126 | 0,157 | 0.193 | 0.257 | 0,356 | 0,429 | ||
| 12,7 | 1/2 | 0.214 | 0,263 | 0,356 | 0,457 | 0.612 | 0,754 | ||
| 15.88 | 5/8 | 0,271 | 0,334 | 0,455 | 0,588 | 0,796 | 0.995 | ||
| 19.05 | 3/4 | 0,327 | 0,405 | 0,553 | 0,729 | 0,895 | 1.236 | ||
| 25.4 | 1 | 0,44 | 0,546 | 0,75 | 0,981 | 1.234 | 1.574 | 2.05 | |
| 31.75 | 1 1/4 | 0,554 | 0,688 | 0,947 | 1.244 | 1.574 | 2.014 | 2.641 | |
| 38.1 | 1 1/2 | 0,667 | 0.832 | 1.144 | 1.514 | 1.904 | 2.454 | 3.233 | |
| 44.5 | 1 3/4 | 1.342 | 1.774 | 2.244 | 2.894 | 3.5 | |||
| 50.8 | 2 | 1.549 | 2.034 | 2.574 | 3.334 | 4.03 | |||
| 63.5 | 2 1/2 | 1.949 | 2.554 | 3.244 | 4.214 | 5.13 | |||
| 76.2 | 3 | 2.345 | 3.084 | 3.914 | 5.094 | 6.19 | |||
| 88.9 | 3 1/2 | 2,729 | 3.609 | 4.584 | 5.974 | 7.27 | |||
| 101.6 | 4 | 4.134 | 5.254 | 6.854 | 8.35 | ||||
| 114.3 | 4 1/2 | 4.654 | 5.924 | 7.734 | 9.43 | ||||
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Komposisi Kimia dan Sifat Mekanik
| Nilai | Komposisi kimia% | ||||||||
| C | Si | M N | P, S Maks | Cr | Mo | Ni Max | V | Al Max | |
| T2 | 0,10~0,20 | 0,10~0,30 | 0,30~0,61 | 0,025 | 0,50~0,81 | 0,44~0,65 | - | - | - |
| T11 | 0,05~0,15 | 0.50~1.00 | 0,30~0,60 | 0,025 | 1,00~1,50 | 0,44~0,65 | - | - | - |
| T12 | 0,05~0,15 | Maks 0,5 | 0,30~0,61 | 0,025 | 0,80~1,25 | 0,44~0,65 | - | - | - |
| T22 | 0,05~0,15 | Maks 0,5 | 0,30~0,60 | 0,025 | 1,90~2,60 | 0,87~1,13 | - | - | - |
| T91 | 0,07~0,14 | 0,20~0,50 | 0,30~0,60 | 0,02 | 8.0~9.5 | 0,85~1,05 | 0.4 | 0.18~0.25 | 0,015 |
| T92 | 0,07~0,13 | Maks 0,5 | 0,30~0,60 | 0,02 | 8.5~9.5 | 0,30~0,60 | 0.4 | 0,15~0,25 | 0,015 |
| Nilai | Komposisi kimia% | Peralatan mekanis | |||||||
| W | B | Nb | n | T. S | Y.P | Pemanjangan | Kekerasan | ||
| T2 | - | - | - | - | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T11 | - | - | - | - | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T12 | - | - | - | - | 415MPa | 220MPa | 30% | 163HBW (85HRB) | |
| T22 | - | - | - | - | 415MPa | 205MPa | 30% | 163HBW (85HRB) | |
| T91 | - | - | 0,06~0,10 | 0,03~0,07 | 585MPa | 415MPa | 20% | 250HBW(25HRB) | |
| T92 | 1.50~2.00 | 0,001~0,006 | 0,04~0,09 | 0,03~0,07 | 620MPa | 440MPa | 20% | 250HBW(25HRB) | |
ASTM A213/ASME SA213 T2, T11, T12, T22, T91, T92 Toleransi
| Diameter luar | Toleransi OD | Toleransi WT | Toleransi Ovalitas | Toleransi Panjang Potong |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15% | - | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD 38, 1 mm | ± 0, 13 mm | ± 10% | maks, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD 88, 9 mm | ± 0, 25 mm | ± 10% | maks, 2, 41 mm | + 4, 76 mm, – 0 mm |
- T11 Alloy Steel Tube untuk pembangkit listrik, minyak bumi, dan layanan suhu tinggi lainnya
- T22 Alloy Steel Tube untuk pembangkit listrik, minyak bumi, dan layanan suhu tinggi lainnya
- Tabung Baja Paduan T5 untuk minyak bumi
- Tabung Baja Paduan T9 untuk minyak bumi
- T91 Alloy Steel Tube untuk pembangkit listrik
- T92 Alloy Steel Tube untuk pembangkit listrik
- T1 Alloy Steel Tube untuk penggantian dan perbaikan boiler
- Tabung SA209 T1 untuk Boiler Manufaktur
- ASTM A213 / ASME SA213 T5 Tabung Baja Paduan untuk Superheater
- ASTM A213 / ASME SA213 T5 Tabung Baja Paduan untuk Penukar Panas
