Baja paduan Tabung Boiler Mulus DIN 1629 St52.4 St52 DIN 17175 15Mo3 13CrMo44 Plain End Permukaan Diminyaki
Product Details
| Kualitas baja: | DIN 1629 St52.4, St52, DIN 17175 15Mo3, 13CrMo44, 12CrMo195 | Permukaan: | Mabuk |
|---|---|---|---|
| Akhir: | LATIHAN, TERPANAS | Aplikasi: | Boiler & penukar panas, energi, industri petrokimia, pertambangan, gas dan fluida |
| Menyoroti |
DIN 1629 St52.4 Boiler Tubes,DIN 17175 15Mo3 Seamless Boiler Tubes,13CrMo44 Seamless Boiler Tubes |
||
Product Description
Tabung Boiler Mulus Baja Paduan DIN 1629 St52.4, St52, DIN 17175 15Mo3, 13CrMo44, 12CrMo195.
Tabung baja paduanadalah sejenis tabung paduan baja dengan elemen lain dalam jumlah
antara 1 dan 50% berat untuk meningkatkan sifat mekaniknya. Paduan
elemen ditambahkan untuk mencapai sifat tertentu dalam bahan.Sebagai pedoman,
elemen paduan ditambahkan dalam persentase yang lebih rendah (kurang dari 5%) untuk meningkatkan
kekuatan atau kemampuan pengerasan atau dalam persentase yang lebih besar (lebih dari 5%) untuk mencapai spesial
sifat, seperti ketahanan korosi atau stabilitas suhu ekstrim.
Bahan utama:
ASTM A335 (Pipa Baja Paduan Feritik Mulus untuk Layanan Suhu Tinggi)
ASTM A335 P1, P2, P5, P9, P12, P11, P22, P91
ASTM 213 (Ketel Baja Paduan Feritik dan Austenitik Seamless, Superheater, dan Tabung Penukar Panas)
ASTM A213 T1, T2, T11, T5, T9, T22, T23, T91, T92
ASTM A335 Seamless Ferritic Alloy Steel Pipe Untuk Suhu Tinggi
| Peralatan mekanis | ||||||
| Grade | Kekuatan tarik (MPa) | Kekuatan hasil (MPa) | Pemanjangan(%) | Energi benturan (J) | Kekerasan | |
| P11 | 415 | 205 | 22 | 35 | 163HB | |
| P12 | 415 | 220 | 22 | 35 | 163HB | |
| P22 | 415 | 205 | 22 | 35 | 163HB | |
| P5 | 415 | 205 | 22 | 35 | 187HB | |
| P91 | 585~760 | 415 | 20 | 35 | 250HB | |
| P92 | 620 | 440 | 20 | 35 | 250HB | |
ASTM A335 Seamless Ferritic Alloy Steel Pipe Untuk Suhu Tinggi
Pipa Baja Paduan ASTM A213 ASME SA213
Bahan LAIN:
ASTM A199 T9, T11, T22
ASTM A209 T1, T1A, T1B
ASTM A210 C
ASTM A250 T1
ASTM A369 FP1, FP2, FP12, FP22, FP9
ASTM A389 FP5
JIS G3455 STS49
JIS 3456 STPT49
JIS G3458 STPA12, STPA 22, STPA23, STPA24, STPA25, STPA26
JIS G3462 STBA12, 13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26
JIS G3464 STBL39
SEW610 10CrMo910
DIN 1629 St52.4, St52
DIN 17175 15Mo3, 13CrMo44, 12CrMo195
GB9948 16Mn, 15MnV, 16Mo, 12CrMo, 15CrMo, 12Cr1MOV, Cr2Mo, 10MoWVNB, Cr5Mo, Cr9Mo,
GB/T8162/8163 Q345, 20Cr, 40Cr, 20CrMo, 25CrMo, 30CrMo, 35CrMo, 34Mn2V, 42CrMo, WB36
(15NICUMOB5) dan 12Cr2MoWVTiB(R102)
GB5310 12CrMoG, 15CrMoG, 12Cr1MoVG
GB/T 17396 27SiMn
GB18248 37Mn, 34Mn2V, 35CrMn, 34CrMo4
Mengetik: Mulus dan dilas
Ukuran:
Diameter luar: 6mm~1420mm
Ketebalan dinding: 1mm~60mm
Panjangnya: 12m, 11,8m, 6m, 5,8m atau sesuai kebutuhan.Maks.:25m.pc
Sertifikasi
