Square Ss 316 Sheet DIN1 4404 Pelat Logam Laser Cutting Bending Pengolahan Makanan
Product Details
| produk: | 316L Plat Stainless Steel DIN1.4404 Pelat Logam Laser Cutting dan Bending | Kualitas baja: | 201, 202, 304, 304L, 316L, 309S, 310S, 430, 409L, 410, 444, 2205, 904LASTM / AISI: 201, 202, 301, 30 |
|---|---|---|---|
| Ukuran / ketebalan: | 0,5-1.2mm Atau Disesuaikan, 1,5-3 Mm Atau Disesuaikan | Permukaan akhir: | Selesai No.1 |
| Lebar: | 1000mm --- 2000mm | Panjangnya: | 2000-6000mm |
| Menyoroti |
ss 304 lembar,lembaran stainless dipoles |
||
Product Description
Hua Dong Energy Technology berurusan dengan pipa dan tabung baja anti karat yang sudah lebih dari 10 tahun, setiap
year sell more than 5000 tons of stainless steel pipe and tube. tahun menjual lebih dari 5000 ton pipa dan tabung stainless steel. Our client already cover more than 45 Klien kami sudah mencakup lebih dari 45
countries. negara. Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Pipa dan tabung mulus stainless steel kami lebar digunakan dalam Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Fluida dll.
316L Plat Stainless Steel DIN1.4404 Pelat Logam Laser Cutting dan Bending
16 / 316L are austenitic stainless steels that contain molybdenum, which increases their resistance to many chemical corrodents and marine environments. 16 / 316L adalah baja tahan karat austenitik yang mengandung molibdenum, yang meningkatkan ketahanannya terhadap banyak korosi kimia dan lingkungan laut. 316L is an extra low carbon version of 316 stainless steel. 316L adalah versi karbon ekstra rendah dari 316 stainless steel. These materials are more resistant to general corrosion and pitting/crevices than conventional austenitic stainless steels. Bahan-bahan ini lebih tahan terhadap korosi umum dan lubang / celah daripada baja tahan karat konvensional austenitik. They also offer higher creep, stress-to-rupture and tensile strength at elevated temperatures, excellent corrosion resistance and strength properties, and they are well suited for fabricated or formed applications. Mereka juga menawarkan creep yang lebih tinggi, tegangan-untuk-pecah dan kekuatan tarik pada suhu tinggi, ketahanan korosi dan sifat kekuatan yang sangat baik, dan mereka sangat cocok untuk aplikasi yang dibuat atau dibuat.
- AMS 5507
- UNS S31600
- UNS S31603
- ASTM A 167
- ASTM A 240
- ASTM F 138
- ASTM F 899
- PWA-LCS
- GE-S400 / 1000
- RR sabre Edition 2
- Sesuai dengan DFARS
- SAE AMS 5507
Nama Perdagangan Umum
- ATI 316L (™ Allegheny Technologies)
- ATI 316 (™ Allegheny Technologies)
Rentang Ukuran Persediaan
- Lembar: 0,018 "- 0,130"
- Bilah Bulat Stainless Steel: 0,125 "- 3.000"
Silakan hubungi kami untuk lebih jelasnya.
The technical data provided is for information only and not for design purposes. Data teknis yang disediakan hanya untuk informasi dan bukan untuk tujuan desain. It is not warranted or guaranteed. Itu tidak dijamin atau dijamin.
Untuk pemahaman yang lebih dalam tentang perbedaan antara 304 dan 316, minta kertas putih kami pada topik.
| Elemen | Persen menurut Berat | |
|---|---|---|
| 316 Stainless | ||
| C | Karbon | Maks 0,08 |
| M N | Mangan | 2,00 maks |
| Si | Silikon | 0,75 maks |
| Cr | Chromium | 16.00 - 18.00 |
| Ni | Nikel | 10.00 - 14.00 |
| Mo | Molibdenum | 2,00 - 3,00 |
| P | Fosfor | Maks 0,045 |
| S | Belerang | Maks 0,030 |
| N | Nitrogen | 0,10 maks |
| Fe | Besi | Bal. |
| Elemen | Persen menurut Berat | |
|---|---|---|
| Stainless 316L | ||
| C | Karbon | Maks 0,030 |
| M N | Mangan | 2,00 maks |
| Si | Silikon | 0,75 maks |
| Cr | Chromium | 16.00 - 18.00 |
| Ni | Nikel | 10.00 - 14.00 |
| Mo | Molibdenum | 2,00 - 3,00 |
| P | Fosfor | Maks 0,045 |
| S | Belerang | Maks 0,030 |
| N | Nitrogen | 0,10 maks |
| Fe | Besi | Bal. |
Aplikasi Umum dari 316 / 316L Stainless Steel
- Peralatan penyulingan minyak & minyak bumi
- Struktur Aerospace
- Pelat dasar
- Peralatan pengolahan makanan
- Peralatan pengolahan pulp dan kertas
- Peralatan penanganan sabun dan fotografi
- Peralatan Industri Tekstil
- Arsitektur
- Peralatan pengolahan farmasi
Sifat Fisik 316 / 316L
- Kisaran lebur: 2540-2630 ° F (1390-1440 ° C)
- Kepadatan: 0,29 lb / in³ (8,027 g / cm³)
- Modulus Elastisitas dalam Ketegangan: 29 x 106 psi (200 GPa)
- Modulus Geser: 11,9 x 106 psi (82 Gpa)
| Kisaran suhu | Berarti Koefisien Ekspansi Termal | ||
|---|---|---|---|
| ° C | ° F | cm / cm / ° C | di / in / ° F |
| 20 - 100 | 68-212 | 16.5 · 10-6 | 9.2 · 10-6 |
| 20 - 500 | 68-932 | 18.2 · 10-6 | 10.1 · 10-6 |
| 20 - 1000 | 68-1832 | 19.5 · 10-6 | 10.8 · 10-6 |
| Kisaran suhu | W / m · K | Btu / (hr / ft² / in / ° F) | |
|---|---|---|---|
| ° C | ° F | ||
| 20-100 | 68-212 | 14.6 | 100.8 |
| ° C | ° F | J / kg ° K | Btu / lb / ° F |
|---|---|---|---|
| 20 | 68 | 450 | 0,108 |
| 93 | 200 | 450 | 0,116 |
Permeabilitas Magnetik
- H / m Annealed
- 1.02 Max @ 200 H
| Tipe | Nilai pada 68 ° F (20 ° C) | |
|---|---|---|
| Microhm-cm | MIcrohm-in. | |
| 316 | 29.1 | 74.0 |
Sifat Mekanik dan Kekuatan Hasil 316 / 316L
| Properti | Tipe 316 (S31600) | Tipe 316L (S31603) | Tipe 317 (S31700) | Tipe 317L (S31703) |
|---|---|---|---|---|
| Kekuatan luluh 0,2% Offset psi MPa |
30.000 205 |
25.000 170 |
30.000 205 |
30.000 205 |
| Kekuatan tekanan maksimum psi MPa |
75.000 515 |
70.000 485 |
75.000 515 |
75.000 515 |
| Persen Pemanjangan dalam 2 in. Atau 51mm | 40.0 | 40.0 | 35.0 | 40.0 |
| Kekerasan, Max. Brinell BPR |
217 95 |
217 95 |
217 95 |
217 95 |
