Carbon Steel / Cold Drawing Dan Cold Rolling Sa210 A1 Seamless Boiler Tube
Product Details
| Kualitas baja: | ASTM, SA192 | Permukaan: | Hitam Cerah |
|---|---|---|---|
| Aplikasi: | Boiler & penukar panas, Superheater, Reheater, Air preheater, Economizer, drum uap, manifold hea | OD: | 6-630mm |
| WT: | 1-60mm | Panjangnya: | 6000mm |
| Menyoroti |
Tabung Baja Presisi ASTM A192,Tabung Baja Presisi 630mm,Tabung Baja Presisi 6000mm |
||
Product Description
Round Boiler Seamless Precision Steel Tube Cold Drawn ASTM A192 Standard
Tabung Baja Seamless Bulat Boiler Dan Pipa ASTM A192
Aplikasi:
Untuk Boiler, Superheater,
Penukar panas,
Boiler bertekanan tinggi,
Ketel Uap
Kondensor Dingin dan Layanan Tekanan Tinggi,
Layanan Suhu Tinggi untuk Konstruksi Boiler
Memproduksi Mothod:
Tabung diproduksi dengan proses yang mulus dan dapat diterapkan dengan hasil akhir panas dan dingin. boiler pipa dan pipa baja seamless adalah kekuatan kami di pasar dunia untuk USA, Middile East Market.
Perawatan panas:
Tabung yang sudah jadi panas tidak perlu diberi perlakuan panas.Tabung Selesai Dingin diberi perlakuan panas setelah pelepasan akhir dingin akhir pada suhu 1200 ℉ (650 ℃) atau lebih tinggi
Kelas baja SA192 Komposisi Kimia & Sifat Mekanik
|
C
|
M N
|
P.
|
S
|
Si
|
Kekuatan tarik
|
Poin Yeild
|
Pemanjangan
|
|
0,06-0,18
|
0,27-0,63
|
0,035Maks
|
0,035Maks
|
0,25Maks
|
min ksi [Mpa] 47 [325]
|
min ksi [Mpa] 26 [180]
|
≥35%
|
Kekerasan
|
Kekerasan Brinell
|
Nomor Kekerasan Rockwell
|
|
WT≥0.200in (5.1mm)
|
WT <0,200 inci (5,1 mm)
|
|
137HRB
|
77HRB
|
KONTROL KUALITAS
1 ~ Inspeksi Bahan Baku Masuk
2 ~ Pemisahan Bahan Baku untuk menghindari campuran kelas baja
3 ~ Pemanasan dan Hammering End untuk Cold Drawing
4 ~ Gambar Dingin dan Penggulungan Dingin, inspeksi online
5 ~ Perlakuan Panas, + A, + SRA, + LC, + N, Q + T
6 ~ Penegakan-Pemotongan ke Panjang yang ditentukan-Pemeriksaan Pengukuran Selesai
7 ~ Pengujian Machanical di laboratorium sendiri dengan Kekuatan Tarik, Kekuatan Hasil, Perpanjangan, Kekerasan, Dampak, Mictrostruture dll
8 ~ Packing dan Stocking.
Teknologi Energi Hua Dong adalah salah satu pemasok terpercaya dan paling terkemuka ASTM A192 bahan baja untuk berbagai aplikasi Anda.Hubungi kami untuk penawaran atau pertanyaan teknis apa pun.Kami ingin mendengar pendapat Anda.
