Welding Pickling Stainless Steel Boiler Tube Untuk Heat Exchanger
Product Details
| Kualitas baja: | ASME SA213 T1, T11, T12, T2, T22, T23, T5, T9, T91, T92 | Permukaan: | Anneal & Pickling |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Inspeksi pihak ketiga: | BV, SGS |
| Bahan: | Baja Karbon, Baja Tahan Karat | Pelabuhan: | Shanghai |
| Menyoroti |
Tabung Boiler Stainless Steel Pengawetan,Tabung Boiler Penukar Panas Pengawetan,Tabung Boiler Stainless Steel ASTM A269 |
||
Product Description
Welding Pipa Stainless Steel Boiler Bergulir Pipa Untuk Penukar Panas
Pengenalan Produksi
ASTM A335 Pipa Baja Paduan Feritik Seamless Untuk Suhu Tinggi
| Peralatan mekanis | ||||||
| Kelas | Kekuatan tarik (MPa) | Kekuatan luluh (MPa) | Pemanjangan(%) | Energi tumbukan (J) | Kekerasan | |
| P11 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P12 | ≥ 415 | ≥ 220 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P22 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P5 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 187HB | |
| P91 | 585 ~ 760 | ≥ 415 | ≥ 20 | ≥ 35 | ≤ 250HB | |
| P92 | ≥ 620 | ≥ 440 | ≥ 20 | ≥ 35 | 250HB | |
Bahan LAINNYA:
ASTM A199 T9, T11, T22
ASTM A209 T1, T1A, T1B
ASTM A210 C
ASTM A250 T1
ASTM A369 FP1, FP2, FP12, FP22, FP9
ASTM A389 FP5
JIS G3455 STS49
JIS 3456 STPT49
JIS G3458 STPA12, STPA 22, STPA23, STPA24, STPA25, STPA26
JIS G3462 STBA12, 13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26
JIS G3464 STBL39
SEW610 10CrMo910
DIN 1629 St52.4, St52
DIN 17175 15Mo3, 13CrMo44, 12CrMo195
GB9948 16Mn, 15MnV, 16Mo, 12CrMo, 15CrMo, 12Cr1MOV, Cr2Mo, 10MoWVNB, Cr5Mo, Cr9Mo,
GB / T8162 / 8163 Q345, 20Cr, 40Cr, 20CrMo, 25CrMo, 30CrMo, 35CrMo, 34Mn2V, 42CrMo, WB36
(15NICUMOB5) dan 12Cr2MoWVTiB (R102)
GB5310 12CrMoG, 15CrMoG, 12Cr1MoVG
GB / T 17396 27SiMn
GB18248 37Mn, 34Mn2V, 35CrMn, 34CrMo4
Jenis: Mulus dan dilas
Ukuran:
Diameter luar: 6mm ~ 1420mm
Ketebalan dinding: 1mm ~ 60mm
Panjangnya: 12m, 11.8m, 6m, 5.8m atau sebagai persyaratan.Maks .: 25m.pc
Product Highlights
Welding Pipa Stainless Steel Boiler Bergulir Pipa Untuk Penukar Panas Pengenalan Produksi Standar ASTM A269 Permukaan Poles, anil, pengawetan, cerah Bahan 200 seri, 300 seri, 400 seri Ukuran (tabung bulat) Ketebalan dinding: OD 1mm-150mm: 6mm-2500mm Ukuran (tabung persegi) Ketebalan dinding: OD 1mm...
Pengelasan Frekuensi Tinggi Bagian Ketel Uap Berbahan Bakar Batubara Disesuaikan Stack Economizer Coil
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Tabung Sirip Spiral Boiler Pengelasan Frekuensi Tinggi Untuk Perpindahan Panas Economizer
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Heat Exchanger H Type Boiler Parts Tube Untuk Pembangkit Pembangkit Listrik
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Extension Heating Surface Boiler Fin Tube Untuk Boiler Pembangkit Listrik Industri
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
