ASTM A53 A192 Tabung Boiler Baja Karbon ERW Ringan
Product Details
| Bahan: | Astm A335 P5 P9 Alloy Carbon Steel Pipa Las | Selesai: | Anil, Normalisasi, Normalisasi dan Marah |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Sertifikat: | ASME, TUV, SGS, CE, ISO9001, |
| Bentuk: | pipa dilas | Teknik: | Hot Rolled, ERW, Cold Drawn |
| Menyoroti |
Tabung boiler baja karbon A53,tabung boiler baja karbon A192,tabung boiler baja karbon ERW |
||
Product Description
ASTM A53 A192 Boiler Tubes Cs Carbon Steel Welded Tube / Pipa Karbon Ringan
Deskripsi Produk Terperinci
| STANDAR | ASTM, DIN, JIS, GB, SUS, TP | BAHAN | Sediakan sesuai dengan kebutuhan dan kegunaan pelanggan |
| TEKNIK | Digulung panas / Digulung dingin | PENGEMASAN | Standar pengepakan ekspor |
| PEMBAYARAN | TT (T / T) | UCAPAN | Terima produk yang disesuaikan |
| Berakhir | 1) Biasa 2) Miring 3) Ulir dengan Coupling atau cap 4) Membungkuk |
Pengobatan permukaan | 1) Dipamerkan 2) Dicat Hitam atau warna lain dicat (lapisan pernis) 3) Galvanis 4) Dengan Diminyaki 5) 3 PE, FBE, lapisan tahan korosi |
| Pengiriman | Kontainer & kargo Massal | Pelindung ujung | 1) Tutup pipa plastik 2) Pelindung besi |
ERW Square / Tabung persegi panjang:
ASTM A500, API, BS, JIS, GB, DIN16219 / 10210.Gr.A, Gr.B, Gr.C
BS1387-85 PIPA BAJA KARBON HITAM / PIPA BAJA ERW, seri ringan
Standar Pipa Casing: pipa minyak APL 5CT
Pipa Casing Diameter luar: 73mm hingga 339.7mm (2-7 / 8 "-13-3 / 8")
panjang: R1, R2, R3
Jenis ujung akhir di Casing Pipe: LTC, STC, BTC, ujung polos
Casing Pipe Packing: dibundel dengan strip baja
Aplikasi Pipa Casing: Pipa Casing Steel berfungsi sebagai dinding tubing pada bidang pengeboran minyak.
Ketebalan Pipa Casing: 5.51mm hingga 13.84mm (0.217 "-1")
Kelas Pipa Casing: K55 J55 N80
Standar Pipa Casing: pipa minyak APL 5CT
Pipa Casing Diameter luar: 73mm hingga 339.7mm (2-7 / 8 "-13-3 / 8")
Ketebalan Pipa Casing: 5.51mm sampai 13.84mm (0.217 "-1")
Kelas Pipa Casing: K55 J55 N80
panjang: R1, R2, R3
Jenis ujung akhir di Casing Pipe: LTC, STC, BTC, ujung polos
Casing Pipe Packing: dibundel dengan strip baja
Aplikasi Pipa Casing: Pipa Casing Steel berfungsi sebagai dinding tubing pada bidang pengeboran minyak.
| PIPA BAJA ERW | |||||
| OD | Toleransi OD | WT | Toleransi Ketebalan | ||
| 21,34—406,4 mm | ± 0,03 | 0,6—30 mm | ± 0,02 | ||
| Panjangnya | 2—16m, sesuai dengan kebutuhan pelanggan | ||||
| Standar internasional | ISO9001-2000 | ||||
| Standar | ASTM A53 / BS 1387-1985 | ||||
| Bahan | Q195 / Q215 / Q235 / Q345 / GR.B, GR.C | ||||
| Kategori Produk | Matalurgi, Mineral & Energi | ||||
| Teknik | Lasan | ||||
| Pengepakan | Dalam bundel atau sesuai permintaan pelanggan | ||||
| Pemakaian |
1 Untuk pengiriman cairan bertekanan rendah seperti air, gas dan minyak 2 Untuk konstruksi, misalnya membangun rumah kaca |
||||
| Pasar utama |
Timur Tengah, Afrika, Amerika Utara dan Selatan, Timur dan Barat Eropa, Selatan dan |
||||
| Kode HS | 73063090 | ||||
| Produktifitas | 12000ton / bulan | ||||
| Teknologi pemrosesan tersedia | Threading, kopling dan dengan tutup plastik dilindungi | ||||
| Catatan | 1) Jangka waktu pembayaran: T / T 2) Istilah Perdagangan: FOB / CFR / CIF 3) Jumlah pesanan minimum: 10 MT 4) Jangka waktu pengiriman: 10 hingga 30 Hari |
||||
Sifat Mekanik (MPa) (PSL1):
Standar |
Kelas | (MPa) | (MPa) | SEBUAH% | ||
| API SPEC 5L |
PSL1 | |||||
| ≥ | ||||||
| psi | MPa | psi | MPa | MIN (%) | ||
| B | 35.000 | 241 | 60.000 | 414 | 21 ~ 27 | |
| X42 | 42.000 | 290 | 60.000 | 414 | 21 ~ 27 | |
| X46 | 46.000 | 317 | 63.000 | 434 | 20 ~ 26 | |
| X52 | 52.000 | 359 | 66.000 | 455 | 20 ~ 24 | |
Grade dan Komposisi Kimia (%)
Standar |
Kelas | (MPa) | (MPa) | SEBUAH% | (J) | ||
| API SPEC 5L |
PSL2 | ||||||
| Min | Max | Min | Max | Min | |||
| B | 241 | 448 | 414 | 758 | 21 ~ 27 | 41 (27) | |
| X42 | 290 | 496 | 414 | 758 | 21 ~ 27 | 41 (27) | |
| X46 | 317 | 524 | 434 | 758 | 20 ~ 26 | 41 (27) | |
| X52 | 359 | 531 | 455 | 758 | 20 ~ 24 | 41 (27) | |
Sifat Mekanik (MPa) (PSL2):
Standar |
Kelas | Komposisi kimia(%) | ||||
| C | M N | TI | P. | S | ||
| B | ≤0.24 | ≤1.20 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X42 | ≤0.24 | ≤1.30 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X46, X52 | ≤0.24 | ≤1.40 | ≤0.04 | ≤0.025 | ≤0.015 | |
Product Highlights
