ASTM A210A1 Carbon Steel Seamless Tube Tebal 0.8mm - 16mm
Product Details
| Nama Produk: | Tube Seamless untuk Boiler | Aplikasi: | Pembangkit listrik |
|---|---|---|---|
| Diameter luar: | 10 - 168 mm | Standar: | AISI, ASTM, DIN, EN, GB, JIS |
| Menyoroti |
ASTM A210A1 Carbon Seamless Tube,0.8mm Carbon Steel Seamless Tube,Tabung Seamless Carbon Steel 16mm |
||
Product Description
Detail Cepat:
Standar: ASTM A210 / A210M (ASME SA210 / SA210M)
Boiler Baja Karbon Menengah dan Tabung Superheater
Ukuran: (mm)
Dimensi Keluar: 12.7mm-114.3mm
Ketebalan Dinding: 0.8mm-15mm
Panjang: 5-25mm
Aplikasi:
Ini digunakan untuk tabung asap boiler dan boiler.Termasuk ujung yang aman, lemari besi dan tabung pendukung dan pemanas super dengan ketebalan dinding minimal tabung baja karbon medium mulus
Persyaratan Kimia:
| STANDAR | KELAS | KOMPOSISI KIMIA | |||||||||
| C | Si | M N | P. | S | Kr | Mo | Cu | Ni | V. | ||
| ASTM A210 | A-1 | ≤0.27 | ≥0.10 | ≤0.93 | ≤0.035 | ≤0.035 | |||||
| C | ≤0.35 | ≥0.10 | 0.291.06 | ≤0.035 | ≤0.035 | ||||||
Peralatan mekanis:
| Kelas | Kekuatan Hasil (Mpa) | Kekuatan Tarik (Mpa) | Perpanjangan (%) |
| A-1 | ≥255 | ≥415 | 30 |
| C | ≥275 | ≥485 | 30 |
Toleransi Ketebalan Dinding
ASME SA-210 |
OD | WT | Toleransi WT |
| <= 38.1 | / | +20%, - 0% | |
| > 38.1 | / | +20%, - 0% |
Deskripsi:
ASTM A210 adalah penutup standar boiler baja karbon menengah mulus dan tabung superheater. ASTM A210 juga mencakup ketebalan dinding minimum, ukuran tabung, cerobong ketel termasuk ujung yang aman, lengkungan dan tabung penahan.ASTM A210 memberikan sifat tarik dan kekerasan tetapi hanya berlaku untuk batasan ukuran tertentu.Pembuatan material harus dimatikan.Tabung harus dibuat dengan proses yang mulus, ditandai sebagai selesai panas atau dingin.Kondisi permukaan harus disebutkan secara spesifik dalam pesanan.Komposisi kimiawi harus sesuai dengan persyaratan.Komposisi unsur selain yang tercantum di sini tidak diizinkan.Uji tegangan, uji perataan, uji pembakaran, uji kekerasan, uji hidrostatis atau uji listrik nondestruktif harus dilakukan pada spesimen.Tabung superheater harus dibentuk tanpa cacat dan harus tahan terhadap ekspansi, manik-manik, penempaan, pengelasan, dan pembengkokan.
ASTM A210 / A210M Seamless Medium-Carbon Steel Boiler Tubes
Boiler Baja Karbon Menengah dan Tabung Superheater
Baja grde:
Kelas A1;Kelas C
Pengepakan:
Miring / lukisan hitam / tutup plastik / dalam bundel / strip baja / pelindung kayu
Inspeksi dan Tes:
Pemeriksaan Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Luluh, Perpanjangan, Pembakaran, Perataan, Pembengkokan, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Nodestruktif, Uji Hidrostatis.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
