600mm Heat Exchanger A269 Tabung Stainless Steel Mulus
Product Details
| Bahan: | TP304, TP304L, TP304H, TP304N, TP309S, TP310S, TP310H, TP316H, TP316H, TP316Ti, TP317L, TP321H, TP34 | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | Penukar panas, Boiler, Kondensor, energi, pertambangan | Bentuk: | U menekuk, lurus |
| OD: | 6.00mm hingga 600mm | WT: | 0,5mm hingga 50mm |
| Menyoroti |
A269 seamless stainless steel tubing,600mm seamless stainless steel tubing,600mm seamless heat exchanger tubing |
||
Product Description
Pipa Seamless Stainless Steel, Acar, Padat, Anil ASTM A269 TP304, ASME SA269 TP304L
NOS ENCANTARíA APOYARLES EN LENGUA ESPAÑOLA SI TIENEN CUALQUIER REQUERIMIENTO RELATIVO!
Teknologi Energi Hua Dongmemiliki pengalaman lebih dari 35 tahun untuk pipa heat exchanger / pipa boiler,
Produk utama kami: Pipa Paduan Stainless / Nikel:
1>. A:Tahan karat Kelas Baja: TP304 / 304L / 304H, TP310S / 310H, TP316 / 316L / 316Ti / 316H, TP317L / 317LN, TP321 / 321H, TP347 / 347H, NO8904 (904L),
B:PH Stainless Baja: 17-4PH (1.4542), 17-7PH (1.4568), 15-7PH (1.4532)
C:Paduan Nikel Kualitas baja:Hestalloy:C-276, C-4, C-22, C-2000, X, B-2, B-3, G-30, G-35. Monel:400.401, 404, R-405, K500.
Inconel:600, 601, 617, 625, 690, 718, 740, X-750. Incoloy:800, 800H, 800HT, 825, 840.
Nikel Murni:Ni-200, Ni-201, Ni-270. Paduan NS:Ns 1101, NS1102, NS1103, NS3105.
2>.Standar: ASTM A213, A249, A269, A312, A789, A790, B163, B167, B444, B677, ... dan ASME, DIN, EN, JIS, BS, GOST, ...
3>.Kisaran ukuran diameter luar: 0,5mm ~ 650mm.Ketebalan dinding: 0.05mm ~ 60mm.Max.panjangnya di bawah 26 meter / PC.
4>.Mulus & dilas, Pengawetan Solusi / Terang Anil / Dipoles.
Produk Keuntungan: (Boiler & Heat Exchanger & Pipa Kondensor):
ASTM A213 (TP304, TP304L, TP304H, TP310S, TP316L, TP316Ti, TP317 / L, TP321 / H, TP347 / H)
ASTM A249 (TP304, TP304L, TP316L, TP321 / H)
ASTM A789 (S31803 (2205), 32750 (2507), S31254 (254MO), S32304)
ASTM B163 / B167 / B444 untuk Pipa Baja Paduan Nikel
ASTM B677 UNS NO8904 (904L)
ASTM B111 (70400, C70600, C71500, C71640, C68700, C44300)
Standar Lainnya: EN10216-5, DIN 17456, DIN17458, GOST9941-81, JIS-G3459, JIS-G3463
| Kelas | Bahan jumlah |
C | Si | M N | P. | S | N | Kr | Mo | Ni | Ti | orang lain |
| Baja feritik atau martensitik | ||||||||||||
| X2CrTi12 | 1.4512 | 0,030 |
1.00 | 1.00 | 0,040 | 0,015 | 10,50 hingga 12,50 | 6 × (C + N) sampai0.65 | ||||
| X6CrAl13 | 1.4002 | 0,08 |
1.00 | 1.00 | 0,040 | 0,015 | 12.00 hingga 14.00 | 0.10 hingga0.30Al | ||||
| X6Cr17 | 1.4016 | 0,08 |
1.00 | 1.00 | 0,040 | 0,015 | 16.00 hingga 18.00 | |||||
| X3CrTi17 | 1.4510 | 0,05 |
1.00 | 1.00 | 0,040 | 0,015 | 16.00 hingga 18.00 | 4 × (C + N) +0,15 hingga 0,80 | ||||
| X12Cr13 | 1.4006 | 0,08 hingga 0,15 | 1.00 | 1.50 | 0,040 | 0,015 | 11,50 hingga 13,50 | 0,75 |
||||
| Baja Austenitik | ||||||||||||
| X5CrNi18-10 | 1.4301 | 0,07 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
17.00 hingga 19.50 | 8.00 hingga 10.50 | |||
| X2CrNi19-11 | 1.4306 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
18.00 hingga 20.00 | 10.00 hingga 12.00 | |||
| X2CrNiN18-10 | 1.4311 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0,12 hingga 0,22 | 17.00 hingga 19.50 | 8,50 hingga 11,50 | |||
| X6CrNiTi18-10 | 1.4541 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 17.00 hingga 19.00 | 9.00 hingga 12.00 | 5 × C sampai 0,70 | |||
| X6CrNiNb18-10 | 1.4550 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 17.00 hingga 19.00 | 9.00 hingga 12.00 | 10 × Cto1.00Nb | |||
| X5CrNiMo17-12-2 | 1.4401 | 0,07 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16,50 hingga 18,50 | 2.00 hingga 2.50 | 10.00 hingga 13.00 | ||
| X2CrNiMo17-12-2 | 1.4404 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16,50 hingga 18,50 | 2.00 hingga 2.50 | 10.00 hingga 13.00 | ||
| X6CrNiMoTi17-12-2 | 1.4571 | 0,08 |
1.00 | 2.00 | 0,045 | 0,015 | 16,50 hingga 18,50 | 2.00 hingga 2.50 | 10,50 hingga 13,50 | 5 × C sampai 0,70 | ||
| X2CrNiMoN17-13-3 | 1.4429 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0,12 hingga 0,22 | 16,50 hingga 18,50 | 2,50 hingga 3,00 | 11.00 hingga 14.00 | ||
| X2CrNiMo18-14-3 | 1.4435 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
17.00 hingga 19.00 | 2,50 hingga 3,00 | 12.50 hingga 15.00 | ||
| X3CrNiMo17-13-3 | 1.4436 | 0,05 |
1.00 | 2.00 | 0,045 | 0,015 | 0.11 |
16,50 hingga 18,50 | 2,50 hingga 3,00 | 10.50 hingga 13.00 | ||
| X2CrNiMoN17-13-5 | 1.4439 | 0,030 |
1.00 | 2.00 | 0,045 | 0,015 | 0,12 hingga 0,22 | 16,50 hingga 18,50 | 4.00 hingga5.00 | 12,50 hingga 14,50 | ||
Specifikasi:
ASME SA213/ A213: Spesifikasi Standar untuk Paduan Feritik dan Austenitik Seamless-
Pipa Boiler, Superheater dan Heat Exchanger Stainless Steel.
ASTM A249 / A249M: Spesifikasi Standar untuk Boiler Baja Austenitik Dilas, SuperheaterHeat-Exchanger, dan Pipa Kondensor.
Kelas Bahan:
| Standar Amerika |
Baja Austenitik: TP304, TP304L, TP304H, TP304N, TP310S, TP316, TP316L, TP316Ti, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, 904L… Lainnya:TP405, TP409, TP410, TP430, TP439, ... |
| Standar Europen | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
| Standar Rusia | 08Х17Т, 08Х13,12Х13,12Х17,15Х25Т, 04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т, 10Х23Н18.08Х18Н10.08Х18Н10Т, 08Х18Н12Т, 08Х17Н15М3Т1218НН10Т, 12Х18НН10Т, 12Х18НН |
Ukuran Jarak:
| Produksi | Diameter luar | Ketebalan dinding |
| Tabung Penukar Panas | 6.00mm hingga 600mm | 0,5 mm hingga 50 mm |
Penyelesaian Akhir
Solusi Anil & Acar/ Terang Anil.
Jenis Tabung:
Coil, U-bend & Lurus.
