ASME Carbon Steel ASTM A179 Seamless Boiler Tubes
Product Details
| Standar: | JIS, AISI, ASTM, GB, DIN, EN | Bahan: | TP304L |
|---|---|---|---|
| Spesifikasi: | Tabung Boiler seamless baja karbon, tabung ditarik dingin, ASTM A179 / tabung boiler seamless / pipa | Paket: | Paket Standar Layak Laut |
| Pengolahan: | Bending, Welding, Decoiling, Punching, Cutting, Moulding | Bentuk: | Bulat |
| Menyoroti |
ASTM A179 Seamless Boiler Tubes,astm a179 boiler tube,ASME Seamless Boiler Tubes |
||
Product Description
Deskripsi
HDT memasok pipa dan tabung mulus Cr-Mo Alloy dalam jumlah besar, dan mengekspor lebih dari 35 negara.Tabung mulus paduan kami lebar digunakan dalam boiler dan pemanas.
HDT mengontrol seluruh proses manufaktur dari bahan mentah hingga produk jadi, Titik inspeksi ditempatkan dalam proses manufaktur untuk memastikan semua produk memenuhi semua persyaratan.Dalam sistem kontrol kualitas tersebut, kesalahan dideteksi pada tahap proses produksi sedini mungkin untuk menghilangkan risiko penolakan pada pemeriksaan akhir.Kami telah melakukan upaya terus menerus untuk mengurangi masalah di seluruh sistem jaminan kualitas total termasuk kontrol ketertelusuran, HDT tidak hanya memeriksa sendiri, juga melalui TPI seperti BV, SGS, DNV, ABS, MOODY, IBR, sehingga hari ini kualitas produk kami jelas diakui oleh klien kami.
Komposisi Kimia:
C,% | M N, % | P, % | S, % |
0,06-0,18 | 0,27-0,63 | 0,035 maks | 0,035 maks |
Peralatan mekanis:
Kekuatan Tarik, MPa | Kekuatan Hasil, MPa | Perpanjangan, % | Kekerasan, HRB |
325 menit | 180 menit | 35 menit | 72 maks |
Diameter & Toleransi Luar
Diameter Luar, mm | Toleransi, mm |
3.2≤OD＜25.4 | ±0,10 |
25.4≤OD≤38.1 | ± 0,15 |
38.1＜OD＜50.8 | ±0,20 |
50.8≤OD＜63.5 | ±0,25 |
63.5≤OD＜76.2 | ±0,30 |
76.2 | ±0,38 |
Ketebalan & Toleransi dinding
Diameter Luar, mm | Toleransi, % |
| 3.2≤OD＜38.1 | +20/-0 |
38.1≤OD≤76.2 | +22/-0 |
Industri Aplikasi
- Perusahaan Pengeboran Minyak Lepas Pantai
- Pembangkit listrik
- Petrokimia
- Pemrosesan Gas
- Bahan Kimia Khusus
- Farmasi
- Peralatan Farmasi
- Peralatan Kimia
- Peralatan Air Laut
- Penukar panas
- Kondensor
