A179 / A192 T5 T11 T22 ASTM Tabung Boiler Baja Karbon
Product Details
| Nama Produk: | Tabung Penukar Panas Baja Karbon Tabung Seamless | Tipe: | Mulus |
|---|---|---|---|
| Standar: | ASME / ASTM | Teknis: | Dingin Diambil |
| Menyoroti |
T22 Carbon Steel Boiler Tubes,T11 Carbon Steel Boiler Tubes,astm a 179 Steel Boiler Tubes |
||
Product Description
A179 / A192 T5 T11 T22 Seamless Steel Boiler Pipe / Tube ASTM
SA179 / SA192 KOMPONEN KIMIA DAN MEKANIK:
| ASTM A179 / (ASME SA179) | |
| Heat Exchanger Dan Conderser Tabung Baja Karbon Rendah Dingin Yang Ditarik | |
| Aplikasi: | Untuk penukar panas tubular, kondensor, dan peralatan perpindahan panas serupa. |
| Ukuran (mm): | OD: 6.0 ~ 114.0 WT: 1 ~ 15 L: maks 12000 |
Grade dan Komposisi Kimia (%)
| Komposisi kimia | C | M N | P≤ | S≤ | Si≤ |
| 0,06-0,18 | 0,27-0,63 | 0,035 | 0,035 | 0.25 |
Toleransi (SA-450 / SA-450M):
| OD Dalam (mm) | + | - | WT Dalam (mm) | + | - |
| <1 (25,4) | 0.10 | 0.10 | ≤1.1 / 2 (38.1) | 20% | 0 |
| 1 ~ 1.1 / 2 (25.4 ~ 38.1) | 0.15 | 0.15 | > 1.1 / 2 (38.1) | 22% | 0 |
| > 1.1 / 2 ~ <2 (38.1 ~ 50.8) | 0.20 | 0.20 | |||
| 2 ~ <2.1 / 2 (50.8 ~ 63.5) | 0.25 | 0.25 | |||
| 2.1 / 2 ~ <3 (63.5 ~ 76.2) | 0.30 | 0.30 | |||
| 3 ~ 4 (76,2 ~ 101,6) | 0.38 | 0.38 | |||
| > 4 ~ 7.1 / 2 (101.6 ~ 190.5) | 0.38 | 0.64 | |||
| > 7.1 / 2 ~ 9 (190.5 ~ 228.6) | 0.38 | 1.14 |
ASTM A192 / A192M-02 |
|
| Tabung Bolier Baja Karbon Seamless untuk Tekanan Tinggi | |
| Aplikasi: | Untuk bolier baja karbon mulus dan tabung superheater untuk layanan tekanan tinggi |
| Ukuran (mm): | OD: 6.0 ~ 114.0 WT: 1 ~ 15 L: maks 12000 |
Grade dan Komposisi Kimia (%)
| Komposisi kimia | C | M N | P≤ | S≤ | Si≤ |
| 0,06-0,18 | 0,27-0,63 | 0,035 | 0,035 | 0.25 |
Toleransi (SA-450 / SA-450M):
| OD Dalam (mm) | + | - | WT Dalam (mm) | + | - |
| <1 (25,4) | 0.10 | 0.10 | ≤1.1 / 2 (38.1) | 20% | 0 |
| 1 ~ 1.1 / 2 (25.4 ~ 38.1) | 0.15 | 0.15 | > 1.1 / 2 (38.1) | 22% | 0 |
| > 1.1 / 2 ~ <2 (38.1 ~ 50.8) | 0.20 | 0.20 | |||
| 2 ~ <2.1 / 2 (50.8 ~ 63.5) | 0.25 | 0.25 | |||
| 2.1 / 2 ~ <3 (63.5 ~ 76.2) | 0.30 | 0.30 | |||
| 3 ~ 4 (76,2 ~ 101,6) | 0.38 | 0.38 | |||
| > 4 ~ 7.1 / 2 (101.6 ~ 190.5) | 0.38 | 0.64 | |||
| > 7.1 / 2 ~ 9 (190.5 ~ 228.6) | 0.38 | 1.14 |
Aplikasi:
1, Untuk evaporator, penukar panas, kondensor, peralatan perpindahan panas dan pipa serupa.
2, Banyak digunakan di bidang perawatan mekanik, industri petrokimia, transportasi dan bidang konstruksi
3, Tujuan struktural biasa dan tujuan struktural mekanik, misalnya di bidang konstruksi, bantalan tumpu dll;
4, Pengangkutan cairan dalam proyek dan peralatan besar, misalnya transportasi air, minyak, gas dll
5, Dapat digunakan dalam boiler bertekanan rendah dan sedang untuk pengangkutan cairan, misalnya tabung uap, tabung asap besar, tabung asap kecil, tabung pembangkit dll
