ASTM A249 C 1.4306 Ss Stainless Steel Welded Tubing diproduksi oleh mesin canggih, perlakuan panas
Product Details
| Bahan: | TP304 TP304L TP316 TP316L | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Bentuk: | Tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0.89mm hingga 6mm |
| Menyoroti |
ASTM A249 ss Welded Tubing,ASTM A249 ss Welded Tubing,1.4306 ss Welded Tubing |
||
Product Description
ASTM A249 / ASME SA249 Welded Tube, TP304L / 1.4306 diproduksi dengan jalur produksi lanjutan
Teknologi Energi Hua Dong menangani pipa dan tabung baja tahan karat selama lebih dari 10 tahun, masing-masing
tahun menjual lebih dari 15.000 ton pipa dan tabung stainless steel.Klien kami sudah mencakup lebih dari 30
negara.Pipa dan tabung seamless stainless steel kami banyak digunakan di Penambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Cairan dll.
1.OD (Diameter Luar): 15.9mm hingga 406.4mm
2.WT (Ketebalan Dinding): 0.89mm hingga 6mm
3.Panjangnya : Sesuai dengan kebutuhan pelanggan
4.Standar:ASTM A312;ASTM A269;ASTM A789;ASTM A790 dll
5.Metode Proses:ERW, EFW dll
Standar ASTM A249:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12,7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2 "(50,8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63,5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3 "(76,2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 4 "(101,6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203,2) | 0,109 "(2,77) | +0,061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
Kelas Bahan:
| Standar Amerika | TP304, TP304L, TP310S, TP316, TP316L, TP316Ti, TP321, TP347, 904L, S31803 dll |
| Standar Eropa | 1.4301, 1.4306, 1.4845, 1.4401, 1.4404, 1.4571, 1.4541, 1.4550, 1.4539, 1.4462 dll |
| Standar Jerman | X5CrNi18-10, X2CrNi19-11, X12CrNi25-21, X5CrNi17-12-2, X5CrNi17-12-3, X2CrNiMo18-14-3, X6CrNiTi18-10, X6CrNiTb18-10 Dll |
| Aplikasi: | a) Untuk transportasi fluida dan gas |
| b) Struktur dan pemesinan | |
| c) Pipa penukar panas dll | |
| Keuntungan : | a) Permukaan akhir yang superior |
| b) Sifat mekanik yang lebih baik | |
| c) Dimensi yang lebih tepat | |
| d) Metode inspeksi dan peralatan inspeksi yang sempurna | |
| Item harga: | FOB, CFR, CIF atau sebagai negosiasi |
| Pembayaran: | T / T, LC atau sebagai negosiasi |
Product Highlights
ASTM A249 / ASME SA249 Welded Tube, TP304L / 1.4306 diproduksi dengan jalur produksi lanjutan Teknologi Energi Hua Dong menangani pipa dan tabung baja tahan karat selama lebih dari 10 tahun, masing-masingtahun menjual lebih dari 15.000 ton pipa dan tabung stainless steel.Klien kami sudah mencakup ...
