OD 15.9mm Sampai 406.4mm Ss Stainless Steel Welded Tubing untuk boiler pembangkit listrik
Product Details
| Bahan: | TP304 TP304L TP316 TP316L, 300 Series | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & heat exchanger, energi, gas dan industri fluida | Bentuk: | Tabung dilas |
| OD: | 15.9mm hingga 406.4mm | WT: | 0,89mm hingga 5mm |
| Menyoroti |
OD 15.9mm SS Welded Tubing,pipa las stainless steel 15.9mm,pipa las stainless steel 406.4mm |
||
Product Description
OD 15.9mm Sampai 406.4mm Ss Stainless Steel Welded Tubing untuk boiler pembangkit listrik
Teknologi Energi Hua Dong menangani pipa dan tabung baja tahan karat selama lebih dari 10 tahun, masing-masing
tahun menjual lebih dari 15.000 ton pipa dan tabung stainless steel.Klien kami sudah mencakup lebih dari 30
negara.Pipa dan tabung seamless stainless steel kami banyak digunakan di bidang Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Cairan dll.
| Barang | Deskripsi | |
| Informasi dasar | Kelas Material | TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, dll |
| Diameter luar | 15.9mm-406.4mm | |
| Ketebalan dinding | 0.89mm-5mm | |
| Panjangnya | Panjang biasanya tetap 6m, bisa sesuai kebutuhan pelanggan | |
| Standar | ASTM A312;ASTM A269;ASTM A789;ASTM A790 dll. | |
| Metode Proses | ERW, EFW dll | |
Aplikasi
a) Minyak Bumi
b) Industri kimia
c) Instrumen
d) Transportasi industri
e) Industri struktur mekanik
f) Membutuhkan industri pipa berkemampuan korosi tinggi, seperti industri lepas pantai dll
Keuntungan
a) Permukaan akhir yang superior,
b) Sifat mekanik yang lebih baik
c) Dimensi yang lebih tepat
d) Metode inspeksi dan peralatan inspeksi yang sempurna
Item harga:
FOB, CFR, CIF atau sebagai negosiasi
Pembayaran:
T / T, LC atau sebagai negosiasi
Standar ASTM A249:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12,7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2 "(50,8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63,5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3 "(76,2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 4 "(101,6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203,2) | 0,109 "(2,77) | +0,061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
