OD2500mm 310S Pipa Dilas Stainless Steel Dengan Bending Welding
Product Details
| Bahan: | TP304 TP304L TP316 TP316L, 300 Seri | Menyelesaikan: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, petrokimia, pertambangan, makanan, kertas, gas dan industri cair | Membentuk: | tabung dilas |
| OD: | 10mm hingga 2500mm | WT: | 0,5mm hingga 35mm |
| Menyoroti |
310S Stainless Welded Pipe,OD2500mm Stainless Welded Pipe,0.5mm WT Stainless Welded Pipe |
||
Product Description
304/316/321/310S Tabung Dilas Stainless Steel Dengan Pengelasan Bending
HDT adalah perusahaan teknologi tinggi yang mengkhususkan diri dalam memproduksi semua jenis tabung dan pipa baja tahan karat, karbon dan paduan, pelat baja dan alat kelengkapan pipa.Produk HDT telah banyak diterapkan di industri seperti minyak bumi, kimia, metalurgi, pembuatan kapal, mesin, listrik, mobil, penerbangan, kertas, makanan dan farmasi, dll. Kapasitas produksi tahunan pipa baja seamless, pipa las dan alat kelengkapan pipa adalah 30.000 ton , 20,000t dan 5,000t masing-masing.HDT memiliki kapasitas pasokan yang kuat, memiliki lebih dari 50.000㎡ gudang di area penyimpanan, terutama untuk pengemasan, penyimpanan, dan transportasi produk kami.
| Nilai | ASTME/ASME: TP304,TP304L,TP304H,TP316,TP316L,TP321,TP321H,TP310S,TP310H, TP317, TP317L, TP347, TP347H, N08904, S31803, S32205, S32750, S32760 | |
| GB/HG:12Cr18Ni9, 06Cr19Ni10, 07Cr19Ni10, 06Cr23Ni13, 06Cr25Ni20, 06Cr17Ni12Mo2, 022Cr17Ni13Mo3, 06Cr18Ni11Ti, 06Cr18Ni11Nb, 07Cr18Ni11Nb, 022Cr22NiMo3N, 022NCr23Nib | ||
| EN:1.4301,1.4306,1.4307,1.4401,1.4404,1.4410,1.4429,1.4462,1.4541,1.4571,1.4539,1.4550 | ||
| Spesifikasi | Garis Kontinu |
OD:10.00mm-219.08mm (HINGGA 8") WT: 0.5mm-10.00mm (SCH5S, 10S, 40S, STD) L:3.00m-18.00m (pemotongan online) |
| Garis Tekuk |
OD: 219.08mm-2500.00mm WT:3.00mm-35.00mm (SCH5S-80S,SCH5-160,STD) L:1,50m, 2,00m, 6,00m |
|
| Standar | ASTM: A249, A269, A312, A358, A688, A778, A789, A790, A928 | |
| ASME: SA312, SA249, SA269, SA358, SA688, SA778, SA789, SA790 | ||
| GB/T: GB/T12771, GB/T12770, GB/T21832, GB/T24593 | ||
| HG: HG20537.1, HG20537.2, HG20537.3, HG20537.4 | ||
| EN: EN10217-7 Lainnya: API 5LC | ||
| Sertifikasi | ISO9001: 2008, PED, ASME, TS, Sertifikat yang memenuhi syarat untuk produksi pembersihan | |
HDT sangat mementingkan peralatan dan teknologi canggih.Kami telah memperkenalkan:
Kapasitas:
10000MT per bulan untuk tabung dan pipa.
5000MT per bulan untuk pelat baja.
Aplikasi:
a) Untuk transportasi fluida dan gas
b) Struktur dan permesinan
c) Pipa penukar panas dll
Keuntungan :
a) Permukaan akhir yang superior
b) Sifat mekanik yang lebih baik
c) Dimensi yang lebih tepat
d) Metode inspeksi dan peralatan inspeksi yang sempurna
