ASTM A210 Cold Drawn Superheater Seamless Boiler Tubes
Product Details
| Kualitas baja: | ASTM, SA192 | Teknik: | Dingin Diambil |
|---|---|---|---|
| Aplikasi: | Pipa Boiler | OD: | 20-1020mm |
| WT: | 0,6-250mm | Panjangnya: | 2-20Meter |
| Menyoroti |
Superheater Seamless Boiler Tubes,astm a210 Boiler Tubes,astm a210 superheater tube |
||
Product Description
ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Steel Boiler dan Superheater Tubes
PENGENDALIAN MUTU dari bahan mentah hingga produk jadi
Kami dapat menyediakan bar bulat / billet MTC, dan Semua Catatan Uji Terkait selama produksi hingga produk akhir!Pastikan semua produk baru diproduksi sesuai kontrak.
Kapasitas produksi hingga 8.000 ton per bulan memastikan PENGIRIMAN CEPAT
Empat mesin penusuk, 20 set meja gambar dingin, DUA tungku perlakuan panas gas alam 150mtr, 12 tangki untuk Pengawetan / Pencucian / Fosfat, DUA Arus Eddy dan SATU Ultrasonik untuk NDT, fasilitas uji Kimia dan Mekanik yang Canggih, dll.
|
C |
M N |
P. |
S |
Si |
Kekuatan tarik |
Poin Yeild |
Pemanjangan |
|
0,06-0,18 |
0,27-0,63 |
0,035Maks |
0,035Maks |
0,25Maks |
min ksi [Mpa] 47 [325] |
min ksi [Mpa] 26 [180] |
≥35% |
Spesifikasi
| Pipa Boiler Dingin Standar & Material |
ASTM A192 / ASME SA192M ASTM A179 / ASME SA179M ASTM A210 / ASME SA210M: Kelas: A1, C ASTM A213 / ASME SA213M: Kelas: T1, T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 GB5310-2013: Kelas: 20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 DIN17175: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, 12Cr1MoV EN10216-1 / 2: Kelas: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 BS 3059: 320, 360, 440, 620-460, 629-590, 762 |
| Ukuran | OD: 10-76mm |
| Ketebalan: 0.8-12mm | |
| Panjang: 5.8mtr, 6mtr, 12 mtr atau sesuai kebutuhan Anda | |
| Pengobatan permukaan | Diminyaki, dipernis, dicat hitam |
ASTM A210 / A210M / ASME SA-210 / SA-210M
ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Steel Boiler dan Superheater Tubes
| Komposisi kimia % | ||||||||
| Garde | C | Si | M N | P. | S | Kr | Ni | Cu |
| A-1 | ≤0.27 | ≥0.10 | 0.29-1.06 | ≤0.035 | ≤0.035 | / | / | / |
| C | ≤0.35 | ≥0.10 | ≤0.93 | ≤0.035 | ≤0.035 | / | / | / |
ASTM A 210 Cold Drawn Seamless Medium-Carbon Steel Steel Boiler dan Superheater Tubes Mechanical Property
| Peralatan mekanis | |||
| Kelas | Yield Point (Mpa) |
Titik Tarik (Mpa) |
Pemanjangan (%) |
| A-1 | ≥255 | ≥415 | ≥30 |
| C | ≥275 | ≥485 |
≥30
|
Kelas baja SA192 Komposisi Kimia & Sifat Mekanik
Kekerasan
|
Kekerasan Brinell |
Nomor Kekerasan Rockwell |
|
WT≥0.200in (5.1mm) |
WT <0,200 inci (5,1 mm) |
|
137HRB |
77HRB |
KONTROL KUALITAS
1 ~ Inspeksi Bahan Baku Masuk
2 ~ Pemisahan Bahan Baku untuk menghindari campuran kelas baja
3 ~ Pemanasan dan Hammering End untuk Cold Drawing
4 ~ Gambar Dingin dan Penggulungan Dingin, inspeksi on line
5 ~ Perlakuan Panas, + A, + SRA, + LC, + N, Q + T
6 ~ Penegakan-Pemotongan ke Panjang yang ditentukan-Pemeriksaan Pengukuran Selesai
7 ~ Pengujian Machanical di laboratorium sendiri dengan Kekuatan Tarik, Kekuatan Hasil, Perpanjangan, Kekerasan, Dampak, Mictrostruture dll
8 ~ Packing dan Stocking.
