Economizer SA210C Superheater Heat Exchanger Pipe Cold Drawn
Product Details
| Nama Produk: | Pipa Baja Karbon untuk Heat Exchanger SA210C | Aplikasi: | Pipa Boiler |
|---|---|---|---|
| Teknik: | Dingin Ditarik, canai dingin / canai panas, mulus | Pelindung Akhir: | Plaint / bevel diakhiri dengan tutup plastik |
| Ketebalan: | 0,2 - 60 mm | Diameter luar: | 13 - 1000 mm |
| Menyoroti |
Pipa Penukar Panas SA210C,pipa superheater SA210C,tabung economizer sa210c |
||
Product Description
Pipa Baja Karbon untuk Penukar Panas SA210C SA192 untuk Pipa Boiler Superheater Boiler Sedang dan Suhu Tinggi
perkenalan produk
Bahan ASME, pipa baja mulus.Ini terutama digunakan untuk economizer, dinding air dan komponen permukaan pemanas lainnya di bagian tekanan boiler;bahan rumah tangga yang sesuai adalah 20g / gb5310.Suhu penggunaan umumnya lebih rendah dari 450 ℃.
|
Pipa Boiler Dingin Standar & Material |
ASTM A192 / ASME SA192M ASTM A179 / ASME SA179M ASTM A210 / ASME SA210M: Kelas: A1, C ASTM A213 / ASME SA213M: Kelas: T1, T2, T5, T9, T11, T12, T22, T23, T24, T91, T911, T92, T122 GB5310-2013: Kelas: 20G, 25MnG, 15MoG, 15CrMoG, 20MoG, 12CrMoG, 12Cr2MoG, 12Cr1MoVG, 12Cr2MoWVTiB, 10Cr9Mo1VNb, 15CrMoG, 10CrMo910 DIN17175: ST35.8, ST45.8, 15Mo3, 13CrMo44, 10CrMo910, 14MoV63, 12Cr1MoV EN10216-1 / 2: Kelas: P195GH, P235GH, P265GH, 13CrMo4-5, 10CrMo9-10, 16Mo3, 10CrMo5-5, X10CrMoVNb9-1 BS 3059: 320, 360, 440, 620-460, 629-590, 762 |
| Ukuran | OD: 10-76mm |
| Ketebalan: 0.8-12mm | |
| Panjang: 5.8mtr, 6mtr, 12 mtr atau sesuai kebutuhan Anda | |
| Pengobatan permukaan | Diminyaki, dipernis, dicat hitam |
ASTM A 192 Cold Drawn Boiler Tube Material Komposisi Kimia
| Komposisi kimia % | |||||||
| C | Si | M N | P. | S | Kr | Ni | Cu |
| 0,06-0,18 | ≤0.25 | 0,27-0,63 | ≤0.035 | ≤0.035 | / | / | / |
ASTM A 192 Properti Mekanik Baja
| Peralatan mekanis | ||
|
Yield Point (Mpa) |
Titik Tarik (Mpa) |
Pemanjangan (%) |
| ≥180 | ≥325 | ≥35 |
Product Highlights
Pipa Baja Karbon untuk Penukar Panas SA210C SA192 untuk Pipa Boiler Superheater Boiler Sedang dan Suhu Tinggi perkenalan produk Bahan ASME, pipa baja mulus.Ini terutama digunakan untuk economizer, dinding air dan komponen permukaan pemanas lainnya di bagian tekanan boiler;bahan rumah tangga yang ...
