405mm ERW Acar Stainless Steel Welded Tubes untuk Superheater
Product Details
| Bahan: | TP304 TP304L TP316 TP316L | Selesai: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | Boiler & Heat exchanger, Superheater & Reheater, Air Preheater, Economizer | Bentuk: | Tabung dilas |
| OD: | 8mm hingga 405mm | WT: | 1mm hingga 50mm |
| Menyoroti |
405mm ERW stainless steel dilas tabung,ERW Acar stainless steel dilas tabung,405mm Acar tabung baja erw |
||
Product Description
ERW Stainless Steel Welded Tube Acar Untuk Superheater & Reheater OD 8mm Sampai 405mm
Teknologi Energi Hua Dong berurusan dengan pipa dan tabung baja tahan karat yang sudah lebih dari 10 tahun, masing-masing
tahun menjual lebih dari 5.000 ton pipa dan tabung stainless steel.Klien kami sudah mencakup lebih dari 30
negara.Pipa dan tabung seamless stainless steel kami banyak digunakan di bidang Pertambangan, Energi, Petrokimia,
Industri Kimia, Pabrik Makanan, Pabrik Kertas, Industri Gas dan Cairan dll.
| Barang | Deskripsi | |
| Informasi dasar | Kelas Material | TP304, TP304L, TP304H, TP316, TP316L, TP316Ti, TP309S, TP310S, TP321, TP321H, TP347, TP347H, dll |
| Diameter luar | 8mm-406.4mm | |
| Ketebalan dinding | 1mm-50mm | |
| Panjangnya | Biasanya panjang tetap 6m, bisa sesuai kebutuhan pelanggan | |
| Standar | ASTM A312;ASTM A269;ASTM A789;ASTM A790 dll. | |
| Metode Proses | ERW, EFW dll | |
Aplikasi:
a) Untuk transportasi fluida dan gas
b) Struktur dan pemesinan
c) Pipa penukar panas dll
Keuntungan :
a) Permukaan akhir yang superior
b) Sifat mekanik yang lebih baik
c) Dimensi yang lebih tepat
d) Metode inspeksi dan peralatan inspeksi yang sempurna
Item harga:
FOB, CFR, CIF atau sebagai negosiasi
Pembayaran:
T / T, LC atau sebagai negosiasi
Standar ASTM A249:
| Ukuran OD | Dinding Nominal | Diameter luar | Panjangnya | Dinding |
| 1/2 "(12,7) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3/4 "(19.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1 "(25,4) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,005 (0,13) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 1-1 / 2 "(38.1) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2 "(50,8) | 0,065 "(1,65) /0,049" (1,25) | +/- 0,008 "(0,20) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 2-1 / 2 "(63,5) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 3 "(76,2) | 0,065 "(1,65) | +/- 0,010 "(0,25) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 4 "(101,6) | 0,083 "(2,11) | +/- 0,015 "(0,38) | +1/8 "(3,18) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,083 "(2,11) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 6 "(152,4) | 0,109 "(2,77) | +/- 0,030 "(0,76) | +1 "(25,4) - 0 | +/- 10,0% |
| 8 "(203,2) | 0,109 "(2,77) | +0,061 "(1,55) / - 0,031" (0,79) | +1 "(25,4) - 0 | +/- 10,0% |
