ASTM A192 114.3mm Beveled Carbon Steel Seamless Tube Grade A1
Product Details
| Nama Produk: | Pipa Seamless Baja Karbon | Aplikasi: | Pembangkit listrik |
|---|---|---|---|
| Standar: | ANSI, ASTM, GB, DIN, API, JIS, ASME, EN | Kemasan rincian: | Ply-wooden Case / Iron Case / Bundle dengan Cap plastik |
| Menyoroti |
ASTM A192 Carbon Steel Seamless Tube,114.3mm Carbon Steel Seamless Tube,pipa baja seamless ASTM 114.3mm |
||
Product Description
ASTM A192 Carbon Steel Seamless Tube / Pembangkit Listrik Cs Standar Internasional Seamless
ASTM A192 Seamless Carbon Steel Tube, Ketebalan Dinding Pipa Baja Boiler 0.8mm - 15mm
Detail Cepat:
Standar: ASTM A192 (ASME SA192)
Boiler Baja Karbon Menengah dan Tabung Superheater
Ukuran: (mm)
Dimensi Keluar: 12.7mm-114.3mm
Ketebalan Dinding: 0.8mm-15mm
Panjang: 5-25mm
Aplikasi:
Ini digunakan untuk tabung asap boiler dan boiler.Termasuk ujung yang aman, lemari besi dan tabung pendukung dan pemanas super dengan ketebalan dinding minimal tabung baja karbon medium mulus
Persyaratan Kimia:
| STANDAR | KELAS | KOMPOSISI KIMIA | |||||||||
| C | Si | M N | P. | S | Kr | Mo | Cu | Ni | V. | ||
| ASTM A192 | A-1 | ≤0.27 | ≥0.10 | ≤0.93 | ≤0.035 | ≤0.035 | |||||
| C | ≤0.35 | ≥0.10 | 0.291.06 | ≤0.035 | ≤0.035 | ||||||
Peralatan mekanis:
| Kelas | Kekuatan Hasil (Mpa) | Kekuatan Tarik (Mpa) | Perpanjangan (%) |
| A-1 | ≥255 | ≥415 | 30 |
| C | ≥275 | ≥485 | 30 |
Toleransi Ketebalan Dinding
ASME SA-192 |
OD | WT | Toleransi WT |
| <= 38.1 | / | +20%, - 0% | |
| > 38.1 | / | +20%, - 0% |
Deskripsi:
ASTM A210 adalah penutup standar boiler baja karbon menengah mulus dan tabung superheater. ASTM A210 juga mencakup ketebalan dinding minimum, ukuran tabung, cerobong boiler termasuk ujung yang aman, lengkungan dan tabung penahan.ASTM A210 memberikan sifat tarik dan kekerasan tetapi hanya berlaku untuk batasan ukuran tertentu.Pembuatan material harus dimatikan.Tabung harus dibuat dengan proses yang mulus, ditandai sebagai selesai panas atau selesai dingin.Kondisi permukaan harus disebutkan secara spesifik dalam pesanan.Komposisi kimiawi harus sesuai dengan persyaratan.Komposisi unsur selain yang tercantum di sini tidak diizinkan.Uji tegangan, uji perataan, uji pembakaran, uji kekerasan, uji listrik hidrostatis atau tidak rusak harus dilakukan pada benda uji.Tabung superheater harus dibentuk tanpa cacat dan harus tahan terhadap ekspansi, manik-manik, penempaan, pengelasan, dan pembengkokan.
ASTM A192 Seamless Medium-Carbon Steel Boiler Tubes
Boiler Baja Karbon Menengah dan Tabung Superheater
Baja grde:
Kelas A1;Kelas C
Pengepakan:
Miring / lukisan hitam / tutup plastik / dalam bundel / strip baja / pelindung kayu
Inspeksi dan Tes:
Pemeriksaan Komposisi Kimia, Uji Sifat Mekanik (Kekuatan Tarik, Kekuatan Luluh, Pemanjangan, Pembakaran, Perataan, Pembengkokan, Kekerasan, Uji Dampak), Uji Permukaan dan Dimensi, Uji Nodestruktif, Uji Hidrostatis.
Pengobatan permukaan:
Oil-dip, Varnish, Passivation, Phosphating, Shot Blasting
Menandai:
Seperti yang diminta.
Kondisi pengiriman:
Anil, Normalisasi, Normalisasi dan Tempered
