ASTM SA179M Cold Drawn Boiler Steel Tube Ketebalan Dinding Minimum
Product Details
| Nama Produk: | Tabung Boiler Seamless Baja Karbon | Aplikasi: | Penukar panas dan Kondensor Tubular |
|---|---|---|---|
| Inspeksi pihak ketiga: | BV, SGS, ASP | Sertifikat: | ISO9001-2008, API 5L, API 5CT |
| Menyoroti |
Tabung Baja Boiler yang ditarik dingin,Tabung Baja Boiler ASTM SA179M,tabung kondensor ASTM SA179M |
||
Product Description
Penukar panas dan tabung kondensor baja karbon rendah ditarik dingin yang mulus ASTM A179/A179M, ASME SA179/SA179M
ASTM A179 mencakup ketebalan dinding minimum, tabung baja karbon rendah yang ditarik dingin tanpa sambungan untuk penukar panas berbentuk tabung, kondensor, dan peralatan perpindahan panas serupa.Tabung harus dibuat dengan proses yang mulus dan harus ditarik dingin.Analisis panas dan produk harus dilakukan di mana bahan baja harus sesuai dengan komposisi kimia karbon, mangan, fosfor, dan belerang yang dipersyaratkan.Bahan baja juga harus menjalani uji kekerasan, uji perataan, uji flaring, uji flange, dan uji hidrostatik.
Komposisi Kimia:
|
C,%
|
M N, %
|
P, %
|
S, %
|
|
0,06-0,18
|
0,27-0,63
|
0,035 maks
|
0,035 maks
|
Peralatan mekanis:
|
Kekuatan Hasil (Mpa)
|
Kekuatan Tarik (Mpa)
|
Perpanjangan, %
|
Kekerasan, HRB
|
|
180
|
325
|
35 menit
|
72 maks
|
Aplikasi:
Pipa baja seamless A179 banyak digunakan dalam industri seperti minyak bumi, kimia, medis, makanan, industri ringan, mesin, instrumen, termasuk pipa industri dan bagian struktur mekanik, dll.
Standar: ASTM A179
Waktu pengiriman: Segera (Stok) atau 10-40 hari (Produksi) Stok: beberapa Tersedia MTC: Tersedia
Diameter & Toleransi Luar
|
Diameter Luar, mm
|
Toleransi, mm
|
|
3.2≤OD＜25.4
|
±0,10
|
|
25.4≤OD≤38.1
|
± 0,15
|
|
38.1＜OD＜50.8
|
±0,20
|
|
50.8≤OD＜63.5
|
±0,25
|
|
63.5≤OD＜76.2
|
±0,30
|
|
76.2
|
±0,38
|
Ketebalan & Toleransi dinding
|
Diameter Luar, mm
|
Toleransi, %
|
| 3.2≤OD＜38.1 |
+20/-0
|
|
38.1≤OD≤76.2
|
+22/-0
|
Panjang: 5800mm;6000mm;6096mm;7315mm;11800mm;dan seterusnya.
Panjang maksimal: 27000mm, juga U bending dapat ditawarkan.
