ASTM A335 Baja Ringan Seamless MS Carbon Steel Pipe Zinc Coating
Product Details
| Bahan: | Astm A335 P5 P9 Alloy Carbon Steel Pipa Las | Selesai: | Anil, Normalisasi, Normalisasi dan Marah |
|---|---|---|---|
| Aplikasi: | boiler & penukar panas, energi, industri petrokimia, pertambangan, makanan, kertas, gas dan flui | Sertifikat: | ASME, TUV, SGS, CE, ISO9001, |
| Bentuk: | pipa dilas | Teknik: | Hot Rolled, ERW, Cold Drawn |
| Menyoroti |
Pipa Baja Karbon ASTM A335 MS,Pipa Baja Karbon ERW MS,pipa seamless baja ringan ASTM A335 |
||
Product Description
Pipa baja karbon MS panjang standar erw dilas pipa baja karbon bulat dan tabung
Deskripsi Produk Rinci
| STANDAR | ASTM, DIN, JIS, GB, SUS, TP | BAHAN | Menyediakan sesuai dengan kebutuhan dan kegunaan pelanggan |
| TEKNIK | Gulungan panas / Gulungan dingin | PENGEMASAN | Standar pengepakan ekspor |
| PEMBAYARAN | TT(T/T) | UCAPAN | Terima produk yang disesuaikan |
| Berakhir | 1) Polos 2) miring 3) Ulir dengan Kopling atau tutup 4) Membungkuk |
Pengobatan permukaan | 1) Bared 2) Hitam Dicat atau warna lain dicat (lapisan pernis) 3) Galvanis 4) Dengan Diminyaki 5) 3 PE, FBE, lapisan tahan korosi |
| Pengiriman | Kontainer & Pengangkut Massal | Pelindung ujung | 1) Tutup pipa plastik 2) Pelindung besi |
ERW Persegi/Tabung Persegi Panjang:
ASTM A500, API, BS, JIS, GB, DIN16219/10210.Gr.A, Gr.B, Gr.C
BS1387-85 PIPA BAJA KARBON HITAM / PIPA BAJA ERW, seri ringan
Standar Pipa Casing: Pipa oli APL 5CT
Pipa Casing Diameter luar: 73mm hingga 339.7mm (2-7/8" -13-3/8")
panjang : R1,R2,R3
Jenis penyelesaian akhir di Pipa Casing: LTC, STC, BTC, ujung polos
Casing Pipe Packing: dibundel dengan strip baja steel
Aplikasi Casing Pipe: Casing Pipa baja berfungsi sebagai dinding tubing di bidang pengeboran minyak.
Ketebalan Pipa Selubung: 5,51mm hingga 13,84mm (0,217" -1")
Kelas Pipa Casing: K55 J55 N80
Standar Pipa Casing: Pipa oli APL 5CT
Pipa Casing Diameter luar: 73mm hingga 339.7mm (2-7/8" -13-3/8")
Ketebalan Pipa Selubung: 5,51mm hingga 13,84mm (0,217" -1")
Kelas Pipa Casing: K55 J55 N80
panjang : R1,R2,R3
Jenis penyelesaian akhir di Pipa Casing: LTC, STC, BTC, ujung polos
Casing Pipe Packing: dibundel dengan strip baja steel
Aplikasi Casing Pipe: Casing Pipa baja berfungsi sebagai dinding tubing di bidang pengeboran minyak.
| PIPA BAJA ERW | |||||
| OD | toleransi OD | WT | Toleransi Ketebalan | ||
| 21.34—406.4mm | ±0,03 | 0,6—30mm | ±0,02 | ||
| Panjangnya | 2-16m, sesuai dengan kebutuhan pelanggan customers | ||||
| Standar internasional | ISO9001-2000 | ||||
| Standar | ASTM A53 / BS 1387-1985 | ||||
| Bahan | Q195/Q215/Q235/Q345/GR.B, GR.C | ||||
| Kategori Produk | Matallurgi, Mineral & Energi | ||||
| Teknik | Lasan | ||||
| Pengepakan | Dalam bundel atau sesuai permintaan pelanggan customers | ||||
| Pemakaian |
1 Untuk pengiriman cairan bertekanan rendah seperti air, gas, dan minyak 2 Untuk konstruksi, misalnya membangun rumah kaca |
||||
| Pasar utama |
Timur Tengah, Afrika, Amerika Utara dan Selatan, Timur dan Barat Eropa, Selatan dan |
||||
| kode HS | 73063090 | ||||
| Produktifitas | 12000ton/bulan | ||||
| Teknologi pemrosesan tersedia | Threading, kopling dan dengan tutup plastik dilindungi plastic | ||||
| Catatan | 1) Jangka waktu pembayaran: T/T 2) Istilah Perdagangan: FOB/CFR/CIF 3) Jumlah pesanan minimum: 10 MT 4) Periode pengiriman: 10 hingga 30 Hari |
||||
Sifat Mekanik (MPa) (PSL1):
Standar |
Kelas | (MPa) | (MPa) | SEBUAH% | ||
| API SPESIFIKASI 5L |
PSL1 | |||||
| ≥ | ||||||
| psi | MPa | psi | MPa | MIN(%) | ||
| B | 35.000 | 241 | 60.000 | 414 | 21~27 | |
| X42 | 42.000 | 290 | 60.000 | 414 | 21~27 | |
| X46 | 46.000 | 317 | 63.000 | 434 | 20~26 | |
| X52 | 52.000 | 359 | 66.000 | 455 | 20~24 | |
Komposisi Kelas dan Kimia (%)
Standar |
Kelas | (MPa) | (MPa) | SEBUAH% | (J) | ||
| API SPESIFIKASI 5L |
PSL2 | ||||||
| min | Maks | min | Maks | min | |||
| B | 241 | 448 | 414 | 758 | 21~27 | 41(27) | |
| X42 | 290 | 496 | 414 | 758 | 21~27 | 41(27) | |
| X46 | 317 | 524 | 434 | 758 | 20~26 | 41(27) | |
| X52 | 359 | 531 | 455 | 758 | 20~24 | 41(27) | |
Sifat Mekanik (MPa) (PSL2):
Standar |
Kelas | Komposisi kimia(%) | ||||
| C | M N | TI | P | S | ||
| B | 0,24 | 1.20 | 0,04 | 0,025 | 0,015 | |
| X42 | 0,24 | 1.30 | 0,04 | 0,025 | 0,015 | |
| X46,X52 | 0,24 | 1,40 | 0,04 | 0,025 | 0,015 | |
Product Highlights
Pipa baja karbon MS panjang standar erw dilas pipa baja karbon bulat dan tabung Deskripsi Produk Rinci Produk Pipa / Tabung Baja Mulus Standar: ASTM A252,ASTM A53,ASTM A106,GB/T8162-2008;GB/T8163-2008;GB3087-2008;GB/T1396-1998;GB5310-2008;GB/T18984-2003,GOST 8731-74,GOST 8732-78 Bahan Gr.B,X42-X52...
