600000Kkal Ketel Minyak Cairan Termal Organik Vertikal 1.0MPA
Product Details
| Gaya: | Horisontal | Pemakaian: | Industri |
|---|---|---|---|
| Kondisi: | Baru | Kata kunci: | Boiler Pembawa Panas Organik |
| Bahan bakar: | Dipecat dengan gas | Tekanan: | Tekanan rendah |
| Menyoroti |
600000Kcal boiler minyak termal,boiler minyak termal vertikal,boiler fluida termal 1.0MPA |
||
Product Description
600000 Kkal Ketel Pembawa Panas Organik Vertikal, Boiler Minyak Termal, Bahan Bakar Gas Diesel
informasi produk
YY (Q) W series thermal oil boiler mengadopsi struktur tiga koil pembakaran ruang horizontal, dan tubuhnya terdiri dari koil luar, koil tengah, koil dalam dan koil belakang. PENGGUNAAN: industri kimia minyak / industri serat kimia / pengolahan kayu / kertas membuat/bahan bangunan/industri makanan, dll.
(1) Media kerja adalah sirkulasi cairan, tekanan kerja lebih rendah, sehingga tekanan seluruh sistem lebih rendah.
(2) Suhu kerja suhu tinggi, dapat digunakan sebagai sumber termal suhu tinggi.
(3) Pasokan suhu pemanasan yang stabil, dapat disesuaikan akurat, berjalan stabil dan mempertahankan efisiensi termal terbaik selama periode penyesuaian.
(4) Dapat mendeteksi proses pembakaran, menyesuaikan dan mengontrol secara otomatis.
(5) Lebih sedikit perangkat, menghemat biaya, tidak memerlukan pengolahan air, katup pembuangan, perangkat penyimpanan air, pompa pengumpanan air suhu tinggi, dll.
Teknologi inti
1. Struktur api penutup minyak dengan tiga lintasan.
2. Struktur punggung basah.
3. Tabung koil kompak.
4. Lebih dari suhu minyak/lebih dari suhu asap/alarm aliran rendah.
5. Desain dengan pemanas awal udara atau boiler pemulihan panas.
6. Desain pintu terbuka besar depan dan belakang.
Keunggulan Produk
1. Tiga Pipa Coil
2. Struktur Punggung Basah
3. Kotak pengumpul oli eksternal
4. Pintu Mudah Dibongkar
Parameter Teknis
| Model Ketel | YY(Q)W-700Y(Q) | YY(Q)W-1400Y(Q) | YY(Q)W-3000Y(Q) | YY(Q)W-3500Y(Q) | YY(Q)W-4200Y(Q) | YY(Q)W-5600Y(Q) | YY(Q)W-7000Y(Q) | |
| Nilai daya termal (KW) | 700 | 1400 | 3000 | 3500 | 4200 | 5600 | 7000 | |
| Nilai tekanan kerja (Mpa) | 0.8/1.0 | |||||||
| Outlet minyak Thwemal / suhu makan Inlet (℃) | 280/250;320/290 | |||||||
| Efisiensi termal (%) | >96 | |||||||
| Jenis bahan bakar | Gas alam/minyak diesel ringan | |||||||
| Konsumsi bahan bakar | Minyak diesel ringan (Kg / jam) | 61.3 | 122.6 | 249.2 | 305.6 | 367.5 | 489.6 | 612.3 |
| Gas alam (Nm3/jam) | 73.6 | 147.1 | 296.4 | 366.8 | 436.6 | 586,8 | 726.9 | |
| Berat transportasi maks (t) | 3.0 | 4.0 | 10 | 10.2 | 16,5 | 23.6 | 28 | |
Catatan: kami memproduksi berbagai seri boiler minyak thermaml, bahan bakarnya bisa berupa batu bara, biomassa, kayu, minyak, gas, struktur horizontal atau vertikal, operasi otomatis atau manual, kapasitas berbeda, tekanan kerja untuk memenuhi kebutuhan yang berbeda, sambut pertanyaan Anda dan pelajari lebih lanjut tentang pemanas minyak termal / boiler.
