ASTM SA213 TP310H SS Tabung Boiler Pipa Stainless Steel Seamless
Product Details
| Bahan: | TP304H, TP310H, TP316H, TP321H, TP347H, TP347HFG | Menyelesaikan: | Solusi Anil & Acar |
|---|---|---|---|
| Aplikasi: | tabung ketel | membentuk: | bulat mulus |
| OD: | 33mm hingga 273mm | WT: | 2mm hingga 20mm |
| Menyoroti |
Pipa Seamless Stainless Steel TP310H,Pipa Seamless Stainless Steel ASTM SA213,Tabung Boiler TP310H SS |
||
Product Description
ASTM SA213 TP310H Ss Tabung Boiler Pipa Stainless Steel Seamless 0.25"MW
Sertifikasi: Layanan Akreditasi Nasional China untuk Sertifikasi CNAS Penilaian Kesesuaian, dengan pengujian standar domestik dan internasional.
Kemampuan: Item pengujian termasuk pengujian kinerja fisik rutin, pengujian analisis kimia, analisis metalografi, korosi intergranular, dan uji dampak suhu tinggi-rendah, dll.
Spesifikasi Standar:
ASTM A213 / A213M - 11a:Spesifikasi Standar untuk Seamless Feritic and Austenitic Alloy-Steel Boiler, Superheater, dan Heat-Exchanger Tubes
ASTM A269 - 10:Spesifikasi Standar untuk Tabung Baja Tahan Karat Austenitik yang Mulus dan Dilas untuk Layanan Umum
ASTM A312 / A312M - 12:Spesifikasi Standar untuk Pipa Baja Tahan Karat Austenitik yang Mulus, Dilas, dan Sangat Dingin
ASTM A511 / A511M - 12: Spesifikasi Standar untuk Tabung Mekanik Stainless Steel Seamless
ASTM A789 / A789M - 10a:Spesifikasi Standar untuk Pipa Stainless Steel Feritik/Austenitik Seamless dan Dilas untuk Layanan Umum
ASTM A790 / A790M - 11: Spesifikasi Standar untuk Pipa Baja Stainless Feritik/Austenitik yang Mulus dan Dilas
DIN 17456-2010: TABUNG STAINLESS STEEL LENGKAP TUJUAN UMUM.
DIN 17458-2010: Edaran Mulus Tabung Baja Tahan Karat Austenitik
EN10216-5 CT 1/2 : Pipa & Tabung Stainless Steel Seamless
GOST 9941-81: TABUNG DINGIN DAN HANGAT YANG MULIH TERBUAT DARI BAJA TAHAN KOROSI.
Lainnya seperti BS, standar JIS atau dapat menyediakan
| Barang | Ukuran standar |
| Tabung & pipa mulus stainless steel | OD: 6-φ813mm, WT: 0,5-40mm |
| tabung-u | OD: 12-φ38mm, WT: 0,5-4mm |
| Tabung & pipa yang dilas | OD: 17.15-φ1828mm, WT: 0.5-45mm |
| Pemasangan Pipa | OD: 1/4”~48”, WT: 5S-40S |
| Nomor barang | Jenis baja | Kelas baja khas |
| 1 | Austenitik |
TP304, TP304L, TP304H, TP316, TP316H, TP316Ti, TP316L, TP321, TP321H, TP347H, TP347HFG, 904L, TP310H, TP310S, TP317, TP317L, TP316LMo≥2.5;dll |
| 2 | Super Austenit | N08904;N08367;S31254 |
| 3 | Dupleks/Super dupleks | S31803;S32205;S31500;S32750；LC65-2506;LC80-2507 |
| 4 | Paduan Ni |
UNS NO2200;NO2201;NO4400;N06600;N06601;NO6690;NO6045; N06625;NO6603;N008800;N08810;N08811;N08020;N08825;N08828; |
| 5 |
Korosi API Paduan Tahan |
LC30-1812;LC65-2205;LC65-2506;LC80-2507;LC30-2242 |
Kelas Bahan:
| Standar Amerika |
Baja Austenitik: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Baja Dupleks: S32101, S32205, S31803, S32304, S32750, S32760 Yang lain:TP405,TP409, TP410, TP430, TP439,... |
| Standar Eropa | 1.4301.1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1,4462, 1,4362, 1,4410, 1.4501 |
| Standar Rusia | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б,10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т,12Х1810,12Х06,12Х |
Penyelesaian Akhir:
Solusi Anil & Acar
ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30, SCH 40S, SCH 60, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS
Aplikasi:
- Peralatan pengolahan makanan, khususnya dalam pembuatan bir, pengolahan susu & pembuatan anggur.
- Bangku dapur, wastafel, bak, peralatan dan peralatan
- Panel arsitektural, pagar & trim
- Wadah bahan kimia, termasuk untuk transportasi
- Penukar panas
- Layar anyaman atau las untuk penambangan, penggalian & penyaringan air
- Pengencang berulir
- mata air
- Pembuatan kapal, di darat, di lepas pantai, Maire.
